Terrain 04621v Archer Bow Blind Instruction Manual (+ PDF)

Part #	Description	Qty
2020	Nut (10-24 Nut)	50
2021		50
2023		23
3013
3014
6012
6013		51
6014	Nut (10-32 Lock Nut)	23
9000		14
INS-TERRAIN-HANDLE	Door Handle	1
INS-TERRAIN-TURN-BUTTON	Window Latch	22
03867V-A	Archer Sidewall	4
04627V-A	Door/Frame Assembly	1
04630V	Roof Cap	1
03866V-C	Roof Panels	5
INS-COMMON TAB PLEXIGLASS	Window	1
INS-COMMON LIVING HINGE	Window Hinge	1
INS-SHORT BOW TAB PLEXIGLASS		4
INS-SHORT BOW LIVING HINGE		4
INS-TERRAIN-LONG BOW WINDOW		4

Tools Needed

Phillips Screw Driver
Socket Wrench OR Adjustable Crescent Wrench

Storage and Care

Please read the manual in its entirety before assembling or
using this product. If there are any missing or broken components,
do not return to the retailer. Instead, contact the manufacturer at
(989) 575-3122. Make sure to reference the blind model (ARCHER
04621V) and the specific component names from the parts list.

Usage Instructions

1. Carefully read the entire manual before assembling or using
the ARCHER Blind.

2. If there are any missing or broken components, contact the
manufacturer at (989) 575-3122 for replacements. Provide the blind
model number (ARCHER 04621V) and the specific component part number
from the parts list.

3. Use the provided tools (Phillips Screw Driver and Socket
Wrench or Adjustable Crescent Wrench) for assembly.

4. Follow the step-by-step assembly instructions provided in the
manual to assemble the blind.

5. Once assembled, ensure that all parts are securely fastened
and in proper position.

6. When using the blind, make sure to follow all safety
guidelines and warnings included in the manual.

7. For any questions regarding assembly, installation, or usage
of the ARCHER Blind or any other product, contact customer service
at (989) 575-3122. Have the product model number (04621V) and
component part number ready for better assistance.

View Fullscreen

ARCHER BLIND ASSEMBLY INSTRUCTIONS
Part Number: 04621V
www.terrainoutdoor.com (989) 575-3122
1
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

ATTENTION! DO NOT RETURN TO RETAILER. IF THERE ARE ANY MISSING OR BROKEN COMPONENTS
PLEASE CONTACT THE MANUFACTURER AT (989) 575-3122. REFERENCE BLIND MODEL: ARCHER 04621V AND THE SPECIFIC COMPONENTS NAME FROM THE PARTS LIST.

ARCHER BLIND USAGE INSTRUCTIONS AND WARNINGS

Thank you for your purchase of this Terrain Outdoor® Hunting Blind product. To ensure your personal safety, please take a moment to carefully read this Instruction Manual in its entirety before attempting to set-up, install, remove and/or otherwise use this Terrain Outdoor® Hunting Blind product(s). Failure to follow these instructions may result in serious injury or death!
If you have any questions about the installation, removal, and/or use of this product, or any other Terrain Outdoor® product(s) do not hesitate to call one of our customer service representatives at (989) 575-3122 or feel free to visit us online at www.terrainoutdoor.com. Our customer service representatives will answer any questions you may have about any of the complete line of Terrain Outdoor® products.
If you find damaged or missing parts in a newly purchased product, please contact the manufacturer at (989) 575-3122 for replacements.
Please note that WARNING! Statements have been placed throughout this Instruction Manual. These statements point out important safety information and instructions, which, if not followed could endanger the personal safety and/or property of the operator(s). It is imperative that the operator(s) of this product, or any other Terrain Outdoor® product(s) read and follow all the instructions and warnings contained in this Instruction Manual prior to attempting to use this Terrain Outdoor® product(s), or any other Terrain Outdoor® product(s). Failure to comply with these instructions and/or warnings may result in serious personal injury or death!
WARNING! Failure to read and strictly comply with the instructions contained in this Instruction Manual may result in serious injury or death! WARNING! Prior to each hunt, you must inform someone of your hunting location, including the specific location of your blind and the expected duration of your hunt. Failure to follow these instructions may result in serious injury or death! WARNING! The safe use and operation of this product(s) is the sole responsibility of the user. It is also the sole responsibility of the owner to provide any person(s) who borrow or purchase this product(s) with these instructions. Failure to follow these instructions may result in serious injury or death! WARNING! Prior to each hunt, make sure that you have a signaling device (e.g., mobile phone, radio, whistle, signal flare or Personal Locator Device (PLD) in your possession and in an operable condition. This device must be within easy access shall you

experience the need to contact emergency assistance. Failure to follow these instructions may result in serious injury or death! WARNING! This product(s) is designed for adult use only. No one under the age of 16 shall attempt to use this or any other product(s) without direct adult supervision. Failure to follow these instructions may result in serious injury or death! WARNING! DO NOT modify, fix/repair, alter, bend, cut, weld, drill, or heat the blind in any way without explicit authorized and written instructions from the manufacturer. Additionally, do not attach anything to your blind without explicit authorized and written instructions from the manufacturer. Failure to follow these instructions may result in voided warranty, serious injury, or death! WARNING! Never use any kind of fuel-burning products (heaters, lanterns, etc.) inside this enclosure. Use of fuel burning products can result in dangerous concentrations of carbon monoxide, a colorless and odorless gas. Breathing carbon monoxide will cause serious injury or death. WARNING! Always use hearing protection when discharging firearms, especially within an enclosed space. WARNING! This product is not fireproof. The plastic will burn if it comes into contact with an open flame or fuel source. Keep product away from direct flame. Failure to follow these instructions may result in serious injury or death! WARNING! This product is for hunting purposes only! It is not to be used as a camping tent or for any other function. Failure to follow this warning may result in serious injury or death! WARNING! Practice safe and proper firearms handling while using this product. Keep firearm or weapon unloaded until seated in the blind and no further movement is expected. Unload the firearm or weapon prior to exiting the blind. Failure to follow this warning may result in serious injury or death! WARNING! Practice safe and proper firearms handling while using this product. Keep firearm pointed in the direction of least consequence with the safety ON in SAFE position at all times. Failure to follow this warning may result in serious injury or death!
California Prop 65 Warning: This product may contain a chemical known to the state of California to cause cancer, birth defects, or other reproductive harm.
If you have any questions about the assembly, installation or use of this product, or any other product, please do not hesitate to call one of our customer service representatives at (989) 575-3122 and they will answer all questions you may have about any of the complete line of products. Please have the product model number (04621V) and component part number ready before calling to better assist you.

READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

PARTS LIST

Part #

Description

Qty

2020

Bolt (¼-20 x 1¼”)

2021

Bolt (10-24 X ½)

2023

Bolt (10-32 X ¾)

3013

Washer (¼ID Rubber) 11

3014

Washer (¼ ID OD) 51

6012

Nut (10-24 Nut)

6013

Wing Nut (¼-20)

6014

Nut (10-32 Lock Nut) 23

9000

Hinge (1 X 1 ½”)

INS-TERRAIN-HANDLE

Door Handle

INS-TERRAIN-TURN-BUTTON Window Latch

03867V-A

Archer sidewall

04627V-A

Door/Frame Assembly 1

04630V

Roof Cap

03866V-C

Roof Panels

INS-COMMON TAB PLEXIGLASS Window

INS-COMMON LIVING HINGE Window Hinge

INS-SHORT BOW TAB PLEXIGLASS

INS-SHORT BOW LIVING HINGE

INS-TERRAIN-LONG BOW WINDOW

SPECS
Size: 73″x73″x85″ (LxWxH) Weight: 128 lbs Maximum Occupancy: One adult with gear Color: Olive drab exterior, black interior

TOOLS NEEDED
Phillips Screw Driver ” Socket Wrench OR Adjustable Crescent Wrench
STORAGE AND CARE
All Terrain Outdoor® hunting blinds are made with an
industrial grade UV Protected High Density Polyethylene material. All components and hardware is resistant to sun, moisture, and normal temperature fluctuation. This product has a 1 year limited warranty against defects in materials and workmanship. To extend the life of this product, keep out of prolonged exposure to sunlight in a shaded area. Keep in an area away from high winds. Make sure that all windows and the door are closed tightly when not in use. To remove surface blemishes and stains use a wet rag and mild detergent as needed. Rinse well. Bleach based cleaners may be used sparingly on the wall, roof, and door panels to remove stains – AVOID WINDOWS. Use only a non-abrasive cloth and a cleaner labeled for use with Acrylic or Plexiglass to clean the windows.

3
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

INCLUDED ITEMS AND HARDWARE LIST

Check to make sure you have all the required parts and hardware. If you find damaged or missing parts in a newly purchased product,
please contact the manufacturer at (989) 575-3122 for replacements.

Part # 2020

Description

Qty

Bolt (¼-20 x 1 ¼”)

Part # 6014

Description

Qty

Nut (10-32 Lock Nut) 23

2021 2023 3013
3014 6012

Bolt (10-24 X ½)

9000

Hinge (1 X 1 ½”)

Bolt (10-32 X ¾”)

INS-TERRAIN-HANDLE

Door Handle

Washer (¼ID Rubber) 11

INS-TERRAIN-TURN-BUTTON Window Latch

Washer (¼ ID OD) 51

03867V-A

Archer Sidewall

Nut (10-24 Nut)

6013

Wing Nut (¼-20)

4
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

INCLUDED ITEMS AND HARDWARE LIST

Check to make sure you have all the required parts and hardware. If you find damaged or missing parts in a newly purchased product,
please contact the manufacturer at (989) 575-3122 for replacements

Part # 04627V-A

Description

Qty

Part #

Description

Qty

Door/Frame Assembly 1

INS-SHORT BOW TAB PLEXIGLASS

03866V-C 04630V

Roof Panels Roof Cap

INS-TERRAIN-LONG BOW WINDOW

INS-SHORT BOW LIVING HINGE

INS-COMMON TAB PLEXIGLASS

Window

INS-COMMON LIVING HINGE

Window Hinge 1

5
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

03867V-A

STEP 1: Attach (2) Archer sidewall [03867V-A] panels together using (5) Bolt ¼-20 x 1 ¼” [2020], (5) Washer ¼ ID OD [3014], and (5) Wing Nut ¼-20 [6013].
NOTE: When assembling, be sure that the bolt is inserted from the exterior and the washer and wingnut are from the interior. Make sure window openings are all towards the top of the assembly.
DETAILED VIEW
3014, 6013

2020 FIG 1

(4x) 03867V-A

STEP 2: Repeat STEP 1 to attach the remaining Archer sidewall [03867V-A].

FIG 2

(10x) 3014, 6013, 2020

6
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

03867V-A 03867V-A

STEP 3: Attach (1) Door/Frame Assembly [004627V-A] panels to the assembly using (5) Bolt ¼-20 x 1 ¼” [2020], (5) Washer ¼ ID OD [3014], and (5) Wing Nut ¼-20 [6013].

FIG 3 03867V-A
(4x) 03867V-A

04627V-A 03867V-A

DETAILED VIEW

2020

3014, 6013

04627V-A

STEP 4: Finish fastening the Door/Frame Assembly [04627V-A] panels to the assembly using (5) Bolt ¼-20 x 1 ¼” [2020], (5) Washer ¼ ID OD [3014], and (5) Wing Nut ¼-20 [6013].

NOTE: When assembling, be sure that the bolt is inserted from the exterior and the washer and wingnut are from the interior.

FIG 4

(10x) 3014, 6013, 2022

7
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

FIG 5
(x5) 2020, 3013, 6013

STEP 5: Locate all 5 roof sections [3866V-C]. Lay each section so they overlap each other with the holes lined up, small ribs inside large ribs. Using a Phillips screw driver, attach the roof section together at the Outside holes only, using the 2022 bolts provided, the rubber washers, and the wingnuts. Do not tighten all the way.

DETAILED VIEW

2022, 3013

6013, not shown

FIG 6
(x5) 2020, 3013, 6013

STEP 6: Locate roof cap [04630]. Align the roof cap over the center of the roof assembly. This step will require standing the roof up to attach it. With the roof on its side, attach the roof cap with the black bolts [2022], rubber washer [3013], and wing nuts [6013]. Once all the bolts are in place, tighten down.

8
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

FIG 7

STEP 7: Fasten the Roof to the assembly using (4) Bolt ¼-20 x ” [2022], (4) Washer ¼ ID OD [3014], and (4) Wing Nut ¼-20 [6013]. Fasten only through the MIDDLE HOLES on each side.

DETAILED VIEW

Roof Support Note (optional): This product is not designed for sustained snow load. If the product will be unattended for any period of time through the winter months we recommend a 2×4 support being placed in the center of the structure. We recommend a 83″ length. Cut a 2×4 to this measurement. Lodge the support between the floor and the roof when blind is not in use. This will help support the roof under heavy snowfall. NOTE: If your roof does collapse it can be reset by disconnecting the roof and placing it on the ground. Once it is on the ground, stand on the roof to push the dent out and back into shape.

6013, 3014

2022

NOTE: When assembling, be sure that the bolt is inserted from the exterior and the washer and wingnut are from the interior. Make sure that the roof panel is resting ON and OVER the sidewall panels.

9
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

FIG 8

STEP 8: Finish fastening the Roof to the assembly with (8) Bolt ¼-20 x ” [2022], (8) Washer ¼ ID OD [3014], and (8) Wing Nut ¼-20 [6013]. Fasten through the holes on the Roof and the slots on the wall/door panels.
NOTE: When assembling, be sure that the bolt is inserted from the exterior and the washer and wingnut (NOT SHOWN IN PICTURES) are from the interior.

DETAILED VIEW
(2x) 6013, 3014 (NOT SHOWN)

2020

FIG 9

STEP 9: Install the Door Handle [INS-TERRAIN-HANDLE] into the Door/Frame Assembly [04627V-A] panel. This step does not require any additional hardware.
NOTE: When assembling, be sure the handle is in the correct orientation as shown. The TERRAIN text faces up, the LATCH faces towards the frame, and the WEATHER COVER is on the exterior.

Interior Facing Exterior Facing

LATCH: Faces Frame

10
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

FIG 10 STEP 10a

STEP 10a: Install the Door Handle [INS-TERRAINHANDLE] into the Door/Frame Assembly [04627V-A] from the exterior of the panel. Insert the tabs near the latch on the Door Handle into the slot as shown. Slide the partially installed handle towards the door frame.

STEP 10b: Push the back set of tabs on the Door Handle through the slot. This is a tight fit, designed to be a snap fit. The tabs are angled to assist with installation.

STEP 10b

STEP 10c

STEP 10c: While applying pressure in on the handle to keep the tabs in the slot, slide the handle towards the door frame.
NOTE: While the handle is removable, it is designed to be installed only once. Refrain from removing and reinstalling the handle more than needed.

DETAILED VIEW – INTERIOR

11
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

FIG 11

STEP 11: Install (2) Window Latches [INS-TERRAIN-TURNBUTTON] into the Door/Frame Assembly [04627V-A] and (20) Window Latches into Common Sidewall Panels [03867V-A]. Use (22) Bolts (10-32 X ¾”) [2023] and (22) Nuts (10-32 Lock Nut) [6014].

NOTE: Install using Bolt and Window Latch from the interior and the Nut from the exterior. Tighten just enough to keep latches open or closed – DO NOT OVERTIGHTEN.

For Each Side Panel: (X5) 2023 (X5) 6014
(X5) INS-TERRAIN-TURN-BUTTON

Detailed View

6014 04627V-A
INS-TERRAIN-TURN-BUTTON 2023

12
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

FIG 12

STEP 12a: Using 2 bolts (2021), a hinge, and 2 nuts (6012) attach the hinge to the long window as shown (RED IN PHOTO BELOW). Using 2 more bolts (2021) and 2 nuts (6012) attach the hinge to the blind wall (BLACK IN PHOTO BELOW). Make sure the nuts are on the outside of the blind wall and window as shown.
STEP 12b: Repeat the above step for all three hinges on every tall window (4 windows total).

Detailed View

13
READ THIS MANUAL IN ITS ENTIRETY BEFORE ASSEMBLING OR USING THIS PRODUCT.

FIG 13

STEP 13: Attach (1) Windows [INS-COMMON TAB PLEXIGLASS] to (1) Window Hinges [INS-COMMON LIVING HINGE]. Attach (4) Small windows [INS-SHORT BOW TAB PLEXIGLASS] to (4) Short window hinges [INS-SHORT BOW LIVING HINGE]. Groove in Window must snap into place on tab of Window Hinge. If installed correctly and fully, a small snapping noise can be heard.
NOTE: Window Hinges may be loose in the box OR connected to the wall/door panels.
Detailed View
Groove Facing UP

FIG 14

Tab on Hinge
STEP 14: Attach (1) assembled Window/Hinge to the Door panel. Attach (4) assembled small Window/hinges to the side walls. Install from the interior of the blind, and keep the Tab on the Hinge and the Groove on the Window facing UP. Press fully over edge of window cut out. If installed correctly and fully, a small snapping noise can be heard.
NOTE: Window is designed to fold open completely. If Hinge binds on itself during opening or closing it is installed incorrectly.
Detailed View

Groove and TAB facing UP
14
