C100 100W CO2 Laser Tube
Product Information
The C100 100W CO2 Laser Tube is a professional-grade glass laser
tube designed to be used as a spare part for laser engraving and
cutting machines. It is suitable for engraving and cutting
non-metal materials like acrylic, cloth, leather, bamboo, wood,
paper, and more. This CO2 laser tube model#C100 100W (1450mm*80mm)
uses German Schott discharge tube and special coating technology to
improve its performance.
Features & Details
- Professional-grade
- Main spare part for CO2 laser engraving and cutting
machines - Supplies strong energy laser during engraving and cutting
- Adopts German Schott discharge tube and special coating
technology to improve performance
Technical Parameters
- Rated power output: 100W
- Length: 1450mm
- Beam diameter: 5mm
- Wavelength: 10.6um
- Material: Boron Silicate Glass
- Outer diameter: 80mm
- Trigger voltage: 24KV
- Working voltage: 17KV
- Optimal operating current: 23mA
- Gross Weight: 6.1kg(13.45lbs)
- Package Size: 160.8 x 17.5 x 20.5cm/63.31 x 6.89 x
8.07inch
Product Usage
To use the C100 100W CO2 Laser Tube, follow these
instructions:
- Make sure the laser engraving or cutting machine is turned off
and unplugged. - Locate the laser tube on the machine and carefully remove the
old laser tube if necessary. - Install the C100 100W CO2 Laser Tube in the same position as
the old tube. - Connect the wires to the laser tube according to the machine’s
user manual. - Turn on the machine and follow the instructions in the user
manual to start engraving or cutting.
Note: It is recommended to wear appropriate protective gear,
such as safety glasses, when using the laser machine with the CO2
laser tube to avoid eye damage from the laser beam.
User Manual
Product ModelC100 100W CO2 Laser Tube
Product Instruction
Professional co2 glass laser tube, mainly used in laser engraving machine, laser cutting machine. It is a spare part for laser machines that can engrave and cut acrylic, cloth, leather, bamboo, wood ,paper and most of other non metal materials. Our CO2 laser tube in model#C100 100W
(1450mm*80mm) adopts the uses German Schott discharge tube and special coating technology to improve the performance of the laser tube. It is definitely your best choice.
Features & Details
1HIGH TEMPERATURE RESISTANCE- This co2 laser tube is made of the boron silicate glass that is also applied on the solar tubes. It is resistant to high temperature and high pressure. 2TEMOO MODE- This co2 laser tube adopts the TEMOO mode, which is characterized by high spot concentration, high energy density as well as good and stable spot. At the same time, the use of output mirrors further enhances the mode. 3SPECIAL COATING TECHNOLOGY- The inside of the discharge tube (imported German Schott tube)uses the special coating technology. The coating is a reduction catalyst mixed with materials such as rare earth and gold. 4LONGER SERVICE LIFE- Our service life of discharge tubes coated with special catalysts is much improved. Compared with other same kind laser cutting tubes, our 100W co2 laser can last longer.
5VARIOUS APPLICATION- Model#C100 100W co2 laser tube is very Professional, as the main spare parts of co2 laser engraving and cutting machine, it supplies for the strong energy “laser” during engraving and cutting.
Technical Parameters
Rated power output: 100W Length: 1450mm Beam diameter: 5mm Wavelength: 10.6um Material: Boron Silicate Glass Outer diameter: 80mm Trigger voltage: 24KV Working voltage: 17KV Optimal operating current: 23mA Gross Weight: 6.1kg(13.45lbs) Package Size: 160.8 x 17.5 x 20.5cm/63.31 x 6.89 x 8.07inch
Installation Drawing
