TA-MB-04-005R DFS Test Setup
Product Information:
Product Name: RF Test Setup
Model Number: TA-MB-04-005R
Test Frequency Range: 9kHz-30MHz, 30MHz-1GHz, 1GHz-18GHz,
18GHz-26.5GHz
Manufacturer: TA Technology (Shanghai) Co., Ltd.
Product Usage Instructions:
Radiated Emission Test Setup:
1. Connect the RF test setup to the device under test (DUT)
using appropriate cables and connectors.
2. Set the test frequency range to 18GHz – 26.5GHz.
3. Ensure that the RF test setup is properly grounded to
minimize interference.
4. Place the DUT in the designated test area.
5. Power on the RF test setup and the DUT.
6. Start the radiated emission test according to the specified
procedure.
Conducted Emission Test Setup:
1. Connect the RF test setup to the DUT using suitable cables
and connectors.
2. Set the test frequency range to 1GHz-18GHz.
3. Ensure that the RF test setup is adequately grounded to
reduce external noise.
4. Place the DUT in the specified test environment.
5. Power on the RF test setup and the DUT.
6. Initiate the conducted emission test following the prescribed
procedure.
Note: Always refer to the user manual provided by TA Technology
(Shanghai) Co., Ltd. for detailed instructions and safety
precautions.
