IL008009ZU Moeller
Electric current! Danger to life!
Only skilled or instructed persons may carry out the following operations.
 | |
| P3” | 13.5 mm (0.53”) |
| HI11-P1/P3 | 7.5 mm (0.3”) |
| Iu (IEC) | Iu (UL/CSA) | |
| P3-63/N | 63 A | 63 A |
| P3-100/N | 100 A | 90 A |
| HI11-P1/P3 | tightening torque | |
 | 0.5 – 1.5 mm² | 1 Nm (8.85 lb-in) |
 | 0.75 – 2.5 mm² | |
| AWG 18 – AWG 14 |
| P3 | tightening torque | |
| 1 x 1.5 – 25 mm² 2 x 1.5 – 6 mm² | 3 Nm (26.55 lb-in) |
| 1 x 2.5 – 35 mm² 2 x 2.5 – 10 mm² | |
| AWG 14 – AWG 2 |
75 °C Cu wire only
UL-File: E 36 332
Suitable For Use As Motor Disconnecting Means With Suffix SVB
Break All Lines
