CC-RVC-TMQ7001 7 Inch TFT Digital Monitor
Product Information: Model: CC-RVC-TMQ7001 Screen size: 7 inches
Aspect Ratio: 16:9 image Video Input: 4 channels
(SplidCVBS/AHD720P/1080P) Audio Input: 4 channels Speaker: 1
channel (Options) Trigger: 4 channels Resolution: 1024 x 3(RGB) x
600 Brightness: 520cd/m2 Contrast ratio: 700:1 Viewing Angle:
H:85°, V:85° External Dimensions: 188.3*132.1*80.2mm (W)*(H)*(T)
Operating Voltage: 12-36V DC Power Consumption: 2.6W (No cameras)
Operation Temperature: -30~+85°C, RH95% Max Storage Temperature:
-40~+90°C, RH95% Max Waterproof: IP65 Options: Speaker, remote
control Product Usage Instructions: 1. Mounting the Display: – Use
the BR-BK03-H Bracket to securely mount the display. – Ensure the
display is placed in a suitable location within your vehicle for
optimal visibility. 2. Power Connection: – Connect the display to a
power source using a 12-36V DC power supply. – Ensure that the
power supply is compatible with the display’s voltage requirements.
3. Video and Audio Input Connection: – Connect up to 4 video
sources (SplidCVBS/AHD720P/1080P) to the corresponding video input
channels on the display. – Connect up to 4 audio sources to the
audio input channels on the display. – If desired, connect an
optional speaker to the speaker channel. 4. Trigger Connection: –
Connect up to 4 trigger sources to the trigger channels on the
display. – This allows the display to automatically switch to the
corresponding video source when a trigger signal is received. 5.
Display Settings: – Adjust the brightness and contrast settings of
the display to your preference. – Use the remote control (if
available) to access additional settings and features. 6. Operating
and Storage Conditions: – Ensure that the display is operated
within the specified temperature range of -30~+85°C. – When not in
use, store the display within the specified temperature range of
-40~+90°C. – Avoid exposing the display to excessive moisture or
extreme temperatures. 7. Optional Accessories: – The remote control
can be used for convenient operation of the display. – Additional
accessories, such as cables, may be required for proper
installation and usage. Note: For more detailed instructions or
troubleshooting, please refer to the complete user manual provided
with the product.
CC-RVC-TMQ7001
Parameter
MODEL
Screen size Aspect Ratio Video Input Audio Input
Speaker Trigger Resolution
Brightness
CC-RVC-TMQ7001
7″ IPS Super TFT panel 16:9 image
4 channels SplidCVBS/AHD720P/1080P 4 Channels
1 Channel(Options) 4 channels
1024 x 3(RGB) x 600 520cd/m2
Contrast radio Viewing Angle External Dimensions Operating Voltage
Power Operation Temperature: Storage Temperature:
Waterproof Options
700:1 H:85 V:85 188.3*132.1*80.2mm (W)*(H)* (T) 12-36V DC 2.6W(No cameras) -30~+85.RH95% Max -40~+90.RH95% Max
IP65 Speakerremote control
Accessory
BR-BK03-H Bracket
cable
Options
Remote control
Speaker
