HFW-CEM-02 Wireless Conventional System Expander Module
General Description
The HFW-CEM-02 Wireless Conventional System Expander Module
(928r/01) is a device designed to add a wireless sub-system to a
conventional fire security installation. This device is connected
directly to the conventional control panel zone line and is part of
it. It allows wireless sounders silencing by being controlled by
the control panel’s sounder output line.
Technical Specifications
- Communication range between expander and wireless devices
- Operating frequency: FSK
- Operating frequency channels: 7
- Radiated power: 5 dBm (3 mW)
- Power supply voltage range: 9 VDC – 30 VDC (12 VDC
typical) - Power supply lower fault threshold: 9 VDC
- Conventional zone line applied voltage: Same as device’s power
supply applied voltage - Sounder’s line maximum voltage: 27 VDC
- Expander maximum current consumption: 60 mA at 12 VDC
(alarm) - Operating temperature range
- Dimensions (without antennas): 120 mm x 160 mm x 51 mm
- Weight: 330 grams
What to Check Before Installation
Before installing the conventional system expander module, check
the following items:
- Ingress protection rating: IP 51C
- Required programming software: Wirelex-Fire revision 5.0 and
successive - Check the latest version of document TDS-SGCWE for further
data, obtainable from your supplier. - Power source type: ES1, PS2
- This device must be installed following your national and/or
international codes of practice and standards. Check them before
performing the installation of this device. - This device is compatible with most of the conventional control
panels. Check that the control panel is equipped with a power
supply output through which you can, if desired, power the
conventional system expander module. Check if the panel is provided
with a sounder output. Check that control panel’s specifications
are suitable. For all this, consult your control panel’s
documentation or consult your control panel’s supplier for more
information.
Device Positioning for Radio Communication Performance and
Stability
The conventional expander module must have good radio
communication with its wireless system’s child devices. In order to
achieve this, before positioning and installing it, apply
scrupulously the following points:
- Avoid installing the module close to:
- If there are other wireless translators or wireless modules,
keep a distance between them of at least 2 meters. In general,
every installed radio device (child devices included) must have a
minimum distance of at least 2 meters from each other. - It is recommended to install the conventional expander at a
height from the floor of at least 2-2.5 meters. - Install the conventional expander perfectly flat on the
wall. - The conventional expander must be installed perfectly straight
on the wall; this means that the antenna under the device must be
perpendicular to the floor and the antenna on the right of the
device must be parallel to the floor. - Environmental parameters (temperature, humidity, etc.) must be
in the ranges specified in the conventional expander’s technical
specifications, which can be found at the beginning of this manual.
This point applies, obviously, to all other wireless devices. - After having installed the conventional expander, make sure
that its child devices (sensors, call points, etc.) are reached by
a good, strong signal.
Product Usage Instructions
To use the HFW-CEM-02 Wireless Conventional System Expander
Module, follow these steps:
- Check the ingress protection rating and required programming
software before installation. - Check the compatibility of the control panel and ensure that it
has a power supply output and a sounder output. - Install the module in a suitable location, following the
guidelines for device positioning for radio communication
performance and stability. - Ensure that environmental parameters are within the specified
ranges. - After installation, ensure that child devices (sensors, call
points, etc.) are reached by a strong signal. - Note that the latest release of the wireless system
configuration software is available from the manufacturer’s
website.
GENERAL DESCRIPTION
HFW-CEM-02
WIRELESS CONVENTIONAL SYSTEM EXPANDER MODULE
928r/01
The wireless conventional system expander module is a device permitting to add a wireless sub-system to a conventional fire security installation. This device is connected directly to the conventional control panel zone line and is actually part of it. This device allows wireless
sounders silencing by being controlled by the control panel’s sounder output line. Note: The latest release of the wireless system configuration software is available from the manufacturer’s website.
TECHNICAL SPECIFICATIONS * Communication range between expander and wireless devices
Operating frequency
200 meters (in open space) 868.15 MHz 869.85 Mhz
Modulation type
FSK
Operating frequency channels
7
Radiated power
Power supply voltage range **
5 dBm (3 mW) 9 VDC – 30 VDC 12 VDC typical
Power supply lower fault threshold
9 VDC
Picture 1 – Device overview
Conventional zone line applied voltage Sounder’s line maximum voltage Expander maximum current consumption
Same as device’s power supply applied voltage 27 VDC
60 mA at 12 VDC (alarm)
Operating temperature range
-30 °C to +50 °C
Dimensions (without antennas)
120 mm x 160 mm x 51 mm
Weight
330 grams
WHAT TO CHECK BEFORE INSTALLATION
Before installing the conventional system expander module check these following items:
Ingress protection rating Required programming software
IP 51C
“Wirelex-Fire” revision 5.0 and successive
* Check latest version of document TDS-SGCWE for further data, obtainable from your supplier.
* * Power source type ES1, PS2
– This device must be installed following your national and / or international codes of practice and standards: check them before performing the installation of this device.
– This device is compatible with most of the conventional control panels; check that the control panel is equipped with a power supply output through which you can, if desired, power the conventional system expander module; check if the panel is provided with a sounder output;
check that control panel’s specifications are suitable; for all this, consult your control panel’s documentation or consult your control panel’s supplier for more information.
DEVICE POSITIONING FOR RADIO COMMUNICATION PERFORMANCE AND STABILITY
The conventional expander module must have a good radio communication with its wireless system’s child devices. In order to achieve this, before positioning it and installing it, apply scrupulously the following points:
– Avoid installing the module close to:
· equipment using large amounts of electrical current · large metal objects, structures or metal ceiling structures
· fluorescent lighting fixings · computers, their cabling and network cabling.
– If there are other wireless translators or wireless modules, keep a distance between them of at least 2 meters. In general every installed radio device (child devices included) must have a minimum distance of at least 2 meters from each other.
– It is recommended to install the conventional expander at a height from the floor of at least 2 – 2.5 meters. – Install the conventional expander perfectly flat on the wall.
– The conventional expander must be installed perfectly straight on the wall; this means that the antenna under the device must be perpendicular to the floor and the antenna on the right of the device must be parallel to the floor.
Environmental parameters (temperature, humidity and so on) must be in the ranges specified in the conventional expander’s technical specifications, which can be found at the beginning of this manual; this point applies, obviously, to all other wireless devices. – After having installed the conventional expander, make sure that its child devices (sensors, call points, etc.) are reached by a good, strong
signal (refer to the single device’s manuals) in their position of installation. Radio transmission ranges for the conventional expander can found in the technical specifications at the beginning of this manual.
– Use the personal computer’s “Wirelex-fire” software for configuring and administering the system.
PLACEMENT AND FIXING
The conventional system expander module’s lodgement box is designed with four 20 mm breakable, “knock-out” entry holes (two at the top
and two on the upper side of the rear of the box), allowing sealed, cable gland fitted, cables to be connected to the device. To place and fix the module perform in sequence the following steps:
– Find a suitable location for the device’s box. – Prepare the cable openings on the box.
– Securely and adequately fix the device’s box to the wall with adequate screws. – Fit the cable’s gland (or glands) into the “knocked out” device box’s cable entry; check gland’s IP rating: it must be equal or greater than the
IP rating of the expander module: see the TECHNICAL SPECIFICATIONS table. – Feed the cables into the box, giving them sufficient length for a secure connection.
Picture 2 – Wall fixing screw holes, their distances from each other and the maximum allowed screw diameter
Picture 3 – Breakable holes for cable entry
96 mm
146 mm
DEVICE WIRING – POWER SUPPLY
The conventional system expander module must be power
–
supplied either:
POWER SUPPLY
+
– directly by the control panel or
– from an external power source or
– from an external power source with a power backup unit.
Use the scheme at the right for connecting the power supply to the device.
This terminal wiring scheme is always applied.
If you want to use an external power source with a power backup unit, two additional module’s terminal blocks come in use: “MAIN MONITORING” and “BACKUP MONITORING”.
“MAIN MONITORING” is a terminal that supervises the main power supply of an external power supply unit.
Picture 5 – Power supply connection scheme
“BACKUP MONITORING” is a terminal that supervises the backup power supply of an external power supply unit.
Let’s have two examples of power supply units:
Picture 6 & 7 – Power supply unit example schemes
“MAIN MONITORING” and “BACKUP MONITORING” lines will be connected to the module as in the following scheme:
MAIN MONITORING
BACKUP MONITORING
Picture 8 – Power supply monitoring lines wiring
WARNING! “POWER SUPPLY -” AND “POWER SUPPLY +” WIRES MUST PASS INTO THE SUPPLIED FERRITE RING.
Picture 9 – Ferrite ring installation DEVICE WIRING – CONVENTIONAL ZONE LINE In order to connect this device to the conventional zone line, two types of schemes can be used, depending on the positioning of the expander module on the line: – the expander module is positioned at the beginning or in the middle of the zone line (conventional devices follow the device on the line or are positioned before and after it); therefore the zone line EOL resistor must be fitted externally as is normally done, but not into the device’s terminal blocks: Picture 10 – Conventional line wiring (zone line EOL resistor outside of the device)
4 mm
Picture 4 – An example of a conventional – wireless system
IMPORTANT: Please note that with this wiring arrangement, if a fault occurs on the wireless sub-system, the remaining conventional zone after the expander may be isolated until the fault has been cleared. This will apply unless each detector on the circuit is equipped with a Schottky diode that the panel can use for continuity purposes. Please refer to your applicable codes of practice and to your conventional control panel documentation.
WIRING CONNECTIONS The conventional system expander module’s wiring phase of the installation has the following objectives: – Connect the power supply cables (either from the control panel of from an independent source). – Connect main and backup power supply monitoring inputs (optional). – Connect the conventional zone line. – Connect the control panel’s sounder output (optional). – Install the end of line (EOL) resistors required as specified in this manual; their values must be chosen according to the control panel’s specification and literature. WIRING WARNINGS Three warnings about wiring: – Perform any wiring operation with the power supply source and the control panel inactive. – Electrostatic sensitive device: observe precautions when handling and making connections. – Connections to the terminals are polarity sensitive, thus, please, check them by referring to the wiring instructions of this manual. IMPORTANT NOTE Check and apply the “ZONE ALARM EOL” and the “CHECKING THE POSITIONING OF THE ELECTRICAL BRIDGES” paragraphs before using the expander module.
– the expander module is positioned at the end of the zone line (all conventional devices are positioned before it); therefore the zone line EOL resistor must be fitted to the device’s terminals and not externally as normally is done.
Picture 11 – Conventional line wiring (zone line EOL resistor inside of the device)
Hyfire Wireless Fire Solutions Limited – Unit B12a, Holly Farm Business Park, Honiley, Warwickshire, CV8 1NP – United Kingdom
www.hyfirewireless.com
L20-SGCWE-1400 (vA.6)
DEVICE WIRING – CONTROL PANEL SOUNDER OUTPUT LINE
Conventional sounders are installed on the sounders line and the voltage level applied to their terminals by the control panel controls their functioning by activating or deactivating them (silencing). Wireless sounders are controlled in the same exact way through the wireless expander module; this means that this kind of radio outputs respond indirectly to the voltage level applied by the control panel to the sounders line positive and negative terminals of the expander module. In order to connect the module to the sounders line, two types of schemes can be used, depending on the positioning of the expander module on this line:
– the expander module is positioned at the beginning or in the middle of the sounders line (sounder devices follow the module on the line or are positioned before and after it); therefore the sounders line EOL resistor must be fitted externally as is normally done, but not into the device’s terminal blocks:
Picture 12 – Sounders line wiring (sounders line EOL resistor outside of the device)
TESTING THE WIRELESS CONVENTIONAL SYSTEM EXPANDER MODULE Testing needs the fire security system to be wired, programmed and armed. Trigger an alarm on the wireless sub-system: as a consequence the conventional control panel must set into alarm. After the test reset the whole system from the control panel. SEALING THE DEVICE WITH ITS COVER After testing you can install the device’s cover onto the module and, safely and securely, close it by using the screws provided.
IMPORTANT: Please note that with this wiring arrangement, if a fault occurs on the wireless sub-system, the remaining sounders line after the expander may be isolated until the fault has been cleared. This will apply unless each sounder on the sounders line is equipped with a Schottky diode that the panel can use for continuity purposes. Please refer to your applicable codes of practice and to your conventional control panel documentation.
– the expander module is positioned at the end of the sounders line (all sounders are positioned before it); therefore the sounders line EOL resistor must be fitted to the device’s terminals and not externally as normally is done.
Picture 13 – Sounders line wiring (sounders line
EOL resistor inside of the device)
ZONE ALARM EOL The zone alarm end of line (EOL) resistor must ALWAYS be installed on the expander; to have its value refer to your control panel’s literature.
Picture 14 – Zone alarm EOL installation terminal blocks on the expander device
CHECKING THE POSITIONING OF THE ELECTICAL BRIDGES In order to function, the wireless expander module needs to have two electrical bridges fitted on the pins on its PCB in the way illustrated in the following picture:
Picture 15 – Electrical bridges correct positioning
VISUAL LED INDICATOR
The conventional expander module is equipped with a three-colour LED (red, green and amber) that provides visual indication for power supply conditions; this indicator is positioned on the internal PCB of the device and it’s light is visible through a slit on the device’s cover.
The table 1 illustrates the possible LED visual signals and their meaning.
Device Status Normal Primary power supply fault Backup power supply fault
PROGRAMMING THE WIRELESS SUB-SYSTEM
Green LED Continuous glowing
Red LED –
–
Continuous glowing
Sequential green – red blinks Table 1
The wireless sub-system is created and programmed through the use of a “Wirelex Fire” program installed on a personal computer that is connected via RS232 serial port to the wireless conventional system expander module.
Hyfire Wireless Fire Solutions Limited – Unit B12a, Holly Farm Business Park, Honiley, Warwickshire, CV8 1NP – United Kingdom
www.hyfirewireless.com
WARNINGS AND LIMITATIONS
Our devices use high quality electronic components and plastic materials that are highly resistant to environmental deterioration. However, after 10 years of continuous operation, it is advisable to replace the devices in order to minimize the risk of reduced performance caused by external factors. Ensure that this device is only used with compatible control panels. Detection systems must be checked, serviced and maintained on a regular basis to confirm correct operation. Smoke sensors may respond differently to various kinds of smoke particles, thus application advice should be sought for special risks. Sensors cannot respond correctly if barriers exist between them and the fire location and may be affected by special environmental conditions. Refer to and follow national codes of practice and other internationally recognized fire engineering standards. Appropriate risk assessment should be carried out initially to determine correct design criteria and updated periodically.
WARRANTY
2831/0051/0681 11
HF-20-017CPR
0832 21
HF-20-017UK
Hyfire Wireless Fire Solutions Limited – Unit B12a, Holly Farm Business Park, Honiley,
Warwickshire, CV8 1NP – United Kingdom
All devices are supplied with the benefit of a limited 5 years warranty relating to faulty materials or manufacturing defects, effective from the production date indicated on each product. This warranty is invalidated by mechanical or electrical damage caused in the field by incorrect
handling or usage. Product must be returned via your authorized supplier for repair or replacement together with
full information on any problem identified.
EN 54-25:2008 EN 54-18:2005 HFW-CEM-02
Full details on our warranty and product return policy can be obtained upon request.
For use in compatible fire detection and alarm system
L20-SGCWE-1400 (vA.6)
