34111504 Gate Framing Kit

Product Information: Gate Framing Kit for Linden and Acadia
Panels

The Gate Framing Kit is designed for use with Linden and Acadia
Panels. It includes all the necessary components to install a gate,
including gate uprights, upright caps, screws, vinyl cement,
hinges, latch, gate stop, U-channel, top rail boards, and bottom
rail.

It is important to note that vinyl gate posts require an
internal support system for weight-bearing purposes, so a post
stiffener needs to be purchased separately. The user manual
provides detailed instructions on how to install the product safely
and securely.

For warranty information or to register your product, please
visit barretteoutdoorliving.com or contact the customer service
team at 1-877-279-4496 or
[email protected]

Product Usage Instructions

1. Apply vinyl cement to all inside surfaces of the first upright
   where the rails will be inserted.
2. Insert both rails into one upright assembly.
3. 1. Place the U-channels on the end boards, then slide boards into
      rails, locking them together.
   2. Apply vinyl cement to all inside surfaces of the second upright
      where rails will be inserted.
   3. Attach the remaining upright assembly to the rails making sure
      boards fit snug.
4. Measure diagonally from top of left corner rail (A) to bottom
   of right corner rail (B) and note the length. Then, measure
   diagonally from top of right corner rail (C) to bottom of left
   corner rail (D). Note the length. Make sure both measurements are
   the same before installing screws into uprights.
5. Install two 6 screws (provided) through each upright insert and
   into the rail using the molded grooves on the insert as a
   guide.
6. Install upright caps onto the top of each upright with provided
   vinyl cement.

Note: Before starting the installation process, read all
instructions carefully and refer to manufacturers safety
instructions when operating any tools. Use the tools and materials
listed in the user manual, including a Phillips screwdriver, safety
glasses, line level, tape measure, drill, #2 square drive bit, 2
wood blocks, 3/32 bit square pencil.

34111504
Gate Framing Kit
For use with Linden and Acadia Panels
INSTALLATION INSTRUCTIONS
Read all instructions prior to installing product. Refer to manufacturers safety instructions when operating any tools.
To register your product, please visit: barretteoutdoorliving.com

WARNING:
· Improper installation of this product can result in personal injury. Always wear safety goggles when cutting, drilling and assembling the product.
· Incorrect installation may cause harm to the product or individual. · Not pool code approved.
NOTICE:
· DO NOT attempt to assemble the kit if parts are missing or damaged. · DO NOT return the product to the store, for assistance or replacement parts call: (877) 265-2220.

BEFORE YOU BEGIN:
Vinyl gate posts require an internal support system for weight-bearing purposes therefore a post stiffener is required. Post stiffener needs to be purchased separately.

Fence

Purchased Stiffener

Top View of Routed Post

TOOLS/MATERIALS NEEDED:
Linden Panel Phillips Screwdriver Safety Glasses Line Level Tape Measure Drill #2 Square Drive Bit 2″ Wood Blocks 3/32″ Bit Square Pencil

Linden Gate Component list:
Description Gate Uprights Upright Caps Screws Vinyl Cement Hinges Latch Gate Stop

U-Channel

Top Rail Boards

Hinges Screws

Bottom Rail
Vinyl Cement

Upright Cap
Latch Gate Upright
Gate Stop

To obtain and review a copy of the warranty please visit: barretteoutdoorliving.com. You may also contact us at 1-877-279-4496 or email [email protected]
2

1.

Apply vinyl cement to all inside surfaces of the first upright where the rails will be inserted (Fig. 1).

Vinyl Cement

Fig. 1

Upright Assembly

2.

Insert both rails into one upright assembly (Fig. 2).

Upright Assembly

Fig. 2 Rails

3.

a. Place the U-channels on the end boards, then slide boards into rails, locking them together (Fig. 3).
b. Apply vinyl cement to all inside surfaces of the second upright where rails will be inserted.
c. Attach the remaining upright assembly to the rails making sure boards fit snug.

U-Channel

Boards Fig. 3

U-Channel

4.

Measure diagonally from top of left corner rail (A) to bottom of right corner rail (B) and note the length. Then, measure diagonally from top of right

A

Fig. 4
C

corner rail (C) to bottom of left corner rail (D). Note

the length. Make sure both measurements are the

same before installing screws into uprights (Fig. 4).

D

B

3

Fig. 5

5.

Install two 6″ screws (provided) through each upright insert and into the rail using the molded

grooves on the insert as a guide (Fig. 5).

6.

Install upright caps onto the top of each upright with provided vinyl cement (Fig. 6).

Fig. 6

7.

Check the included Barrette Outdoor Living® hinge, latch and gate stop kit for hardware instructions or visit barretteoutdoorliving.com to obtain a copy.

Barrette Outdoor Living 7830 Freeway Circle, Middleburg Heights, OH. 44130
barretteoutdoorliving.com · (877) 265-2220

REV 5.22
