Art No: 254811
WebCode EARTHA
Technical Data
| Mechanical Data | |
| Material incl. surface coating | Nickel-plated brass |
| Construction type | CMP earthing ring |
| Length | 141.5 mm |
| Outer diameter | 95.4 mm |
| Thread (outer) | M75 |
| Inner diameter | M13 |
| Nominal length | 73 mm |
| Gauge | 1.5 mm |
| Weight | 0.07 kg |
| Weight | 0.15 lb |
Dimensional Drawings
(All Dimensions in mm [inches]) – Subject to Alterations
- L = Length
- d2 = Outer diameter
- d1 = Thread (outer)
- D = Inner diameter
- F = Nominal length
We reserve the right to make alterations to the technical data, dimensions, weights, designs and products available without notice. The illustrations cannot be considered binding.
