Zyerch Az001 6 In 1 Hub Instruction Manual

AZ001 6 in 1 Hub

Product Information

Product Name: 6 in 1 HUB

Product Model: AZ001

Date: 2022-10-14

Version: V1.0

Product Usage Instructions

1. Electrical Specification

• Product Features:

  This product is a docking station developed based on the
  LT8711UX for computers or similar terminal devices with a Type-C
  interface. It can provide high-power charging of 20V/5A/100W to the
  upstream terminal device even under ultra-high resolution.
  Additionally, it can expand a USBHUB with USBGEN1.5G speed (with a
  1000M wired network card under the USBHUB). The product is
  compatible with and can be driven and used on Windows, macOS,
  Android, and Linux systems.

• Product Standard:

  6 in 1 USB3.1 Type-C TO USB3.0 + HDMI + PD + RJ45 Docking
  Station

  Input: USB3.1 Type-C Male

  Output:

  • 3*USB3.0 (5Gbps)
  • 1*HDMI (4K 60Hz)
  • 1*RJ45 (1000Mbps W/LED)
  • 1*Type-c (PD100W)

2. Outside View Drawing

Product Interface Description:

• The product features a wired network card port (supporting
  1000Mbps speed and downward compatibility with 100M and 10M
  speeds).
• The product also includes an HDMI display port (supporting a
  maximum output resolution of 3840*2160@60Hz).
• The product is equipped with a PD charging port (supporting a
  maximum power output of 20V/5A/100W).
• The product also has a USB3.0-A port (supporting USB3.0GEN1
  speed read/write and compatible with USB2.0).
• The product has an additional USB3.0-A port (supporting
  USB3.0GEN1 speed read/write and compatible with USB2.0).
• The product also features another USB3.0-A port (supporting
  USB3.0GEN1 speed read/write and compatible with USB2.0).
• The product includes a Source soldering port (for soldering an
  OPEN wire to the Type-C port).

3. Product Size

4. Packing

Specification for Approval

Product Name:

6 in 1 HUB

Product Model: AZ001

Date : Version:

2022-10-14 V1.0

CONTENTS
1. Electrical Specification …………………………………………………………..
1.1 Product Description…………………………………………………………… 1.2 Product Standard ……………………………………………………………………………………
2. Outside View Drawing………………………………………………………….
2.1Product interface desription………………………………………………………….. 2.2 Product ID ………………………………………………………………………………………..
3. Product Size…………………………………………………………………… 4. Packing…………………………………………………………………………………….. 5. BOM…………………………………………………………………………………. 6. Inspection Specification…………………………………………

Data of Release October 14th, 2022 Model No. F148193V Page No

1

1. ELECTRIC SPECIALITY 1.1 PRODUCT FEATURES
This product is a docking station developed based on the LT8711UX for computers or similar terminal devices with a Type-C interface. It can provide high-power charging of 20V/5A/100W to the upstream terminal device even under ultra-high resolution. Additionally, it can expand a USBHUB with USBGEN1.5G speed (with a 1000M wired network card under the USBHUB). The product is compatible with and can be driven and used on Windows, macOS, Android, and Linux systems.
1.2 PRODUCT STANDARD
6 in 1 USB3.1 Type-C TO USB3.0 +HDMI +PD+RJ45Docking Station
Input: USB3.1 Type-C Male Output: 3*USB3.0 (5Gbps)
1*HDMI (4K 60Hz) 1*RJ45 (1000Mbps W/LED 1*Type-c (PD100W)

Data of Release October 14th, 2022

Model No. AZ001

Page No

2

2.OUTSIDE VIEW DRAWING
2.1Product interface desription

1The pr oduct f eat ur es a wi r ed net wor k car d por t ( suppor t i ng 1000Mbps speed and
downwar d compat i bi l i t y wi t h 100M and 10M speeds) .
2The pr oduct al so i ncl udes an HDMI di spl ay por t ( suppor t i ng a maxi mum out put
r esol ut i on of 3840* 2160@60Hz) .
3The pr oduct i s equi pped wi t h a PD char gi ng por t ( suppor t i ng a maxi mum power
out put of 20V/ 5A_100W) .
4The pr oduct al so has a USB3. 0- A por t ( suppor t i ng USB3. 0GEN1 speed r ead/ wr i t e
and compat i bl e wi t h USB2. 0) .
5The pr oduct has an addi t i onal USB3. 0- A por t ( suppor t i ng USB3. 0GEN1 speed
r ead/ wr i t e and compat i bl e wi t h USB2. 0) .
6The pr oduct al so f eat ur es anot her USB3. 0- A por t ( suppor t i ng USB3. 0GEN1 speed
r ead/ wr i t e and compat i bl e wi t h USB2. 0) .
7The pr oduct i ncl udes a Sour ce sol der i ng por t ( f or sol der i ng an OPEN wi r e t o
t he Type- C por t ) .

Data of Release October 14th, 2022 Model No. AZ001

Page No

3

2.2 Product ID

Data of Release October 14th, 2022 Model No. AZ001

Page No

4

3.Product Size(

Data of Release October 14th, 2022 Model No. AZ001

Page No

5

3. Packing

1.The product should be packed in a flat frosted PE bag, placed inside a cardboard box with the logo facing upward. The instruction manual should be placed on top, facing upward and in a fixed position to prevent it from moving inside the packaging.
2. Each outer box should contain 80 units and be separated by a paper divider placed on top of the units inside the box.

Data of Release October 14th, 2022

Model No. AZ001

Page No

6

5. BOM

No

Material

Material requirement description

Dimension

name

specifications

1

Wire

USB Type-c 3.1Aluminum alloy

15cm

1pcs

small enclosure, black PVC.

2

SR

3

Wire clip

Black

/

1pcs

/

1pcs

4

Main body Gray and laser-engraved white port function labels.

/

1pcs

5

PCBA

F148193V PCBA

/

1pcs

6

PD circuit boardBlack acrylic, with USB-C PD port function label.

39.5*24.3*2.2mm 1pcs

7

RJ45

Black acrylic, without port function label.

39.5*24.3*2.2mm 1pcs

8

Paper box

Paper box

155*108*38mm

1pcs

9

Silicone strip 1

Front diamond-shaped anti-slip adhesive strip

10*98*1.15mm

1pcs

10

Silicone strip 2

Front diamond-shaped short anti-slip adhesive strip

15*31*1.15mm

2pcs

11

Silicone strip 3

Smooth anti-slip adhesive strip on the bottom.

8*84.5*1.15mm

2pcs

12

Manual

Manual

140*90mm

1pcs

13

PE

Flat matte PE bag

14

Out er box

K=K80pcs/box

/ 56.6*32.5*32.5cm

1pcs 1/80pcs

15

Paper divider

Sealing paper divider

/

1/80pcs

16

Sticker

Sticker

/

1pcs
