KB-M2-W35 Fixed Wall Mount Keyboard

Product Information

The KB-M2-W35- _ _, KB-R2-W35- _ _, and KB-R3-W35- _ _ Series
Fixed Wall Mount Keyboard is a wall mount keyboard designed for
easy installation and ergonomic usage. It comes with a collar,
screws, washers, and a gasket to ensure secure mounting and
minimize vibration. The keyboard is compatible with panels up to 14
mm thick.

Product Usage Instructions

Cut or drill the mounting pattern in the panel according to the
dimensions provided in Figure 1. Ensure a tolerance of +/- 0.8 mm
(0.03) on all dimensions unless otherwise noted.
If using clearance holes, make sure the panel thickness does
not exceed 14 mm (9/16). For thicker panels, longer screws than
those provided are required.
Install the collar from the rear using the four provided M6
screws and washers. Make sure to tighten all screws until the
gasket is compressed to a thickness of 1/16 to 3/32.
Ensure the keyboard is mounted at a height that is
ergonomically suitable for most users, approximately 45 off the
floor.

View Fullscreen

Installation Instructions
KB-M2-W35- _ _ , KB-R2-W35- _ _ , and KB-R3-W35- _ _ Series Fixed Wall Mount Keyboard
1. Cut or drill mounting pattern in panel. Refer to Figure 1 for the cutout dimensions. NOTE: +/- 0.8 mm (0.03″) tolerance on all dimensions unless otherwise noted. The provided hardware is for use with panels that have a maximum thickness of 14 mm (9/16″) if using clearance holes. Thicker panels can be used but require longer screws than those provided.

18.3 mm (0.72″)

177.8 mm (7.00″)

Ø 8 mm (5/16″) DIAMETER
(4 PLACES)

36.7 mm (1.44″)

355.6 mm (14.00″)

Ø 19.1 mm (0.75″)
DIAMETER

PLACE 45″ OFF FLOOR FOR MOST UNIVERSAL ERGONOMIC HEIGHT

FIGURE 1 WALL MOUNT CUTOUT PATTERN
2. Install the collar from the rear using the four provided M6 screws and washers as shown. Tighten all screws until the gasket is compressed to 1/16″ to 3/32″ thick.

M6 HEX HEAD NYLON

SCREW

WASHER

GASKET

15 FT COLLAR
FIGURE 2 SIDE VIEW OF KEYBOARD
99170A · December 20, 2022 · www.HopeIndustrial.com · International: +1 (678) 762-9790 · UK: +44 (0) 20 7193 2618 · © 2023 Hope Industrial Systems, Inc.
