SC-2 Safetymix Valve
Product Information
The Safetymix valve is a plumbing fixture that controls the
temperature of water. It consists of individual parts such as flow
control spindle, spindle assembly, plaster shield, lever handle,
cap, renewable seat, packing nut with o-rings, cold washer
retainer, hot washer screw, hot and cold washers, escutcheon,
escutcheon screw, dome cover, handle screw, packing, cap gasket,
top seat o-ring & bottom seat gasket, limit stop with o-ring,
escutcheon gasket, washer & gasket kit-B, renewable seat unit
complete, renewable seat socket wrench, and repair units. It can be
installed in fiberglass or panel walls and allows for infinite
temperature adjustments to suit user requirements.
Product Usage
To install the Safetymix valve in fiberglass or panel walls and
sandwich the wall between the valve body and escutcheon, cut a hole
in the wall as shown in Figure 4 and mount the valve from the rear.
It is recommended to secure valve piping to rough construction and
not depend on fiberglass wall for valve mounting security. For
panel walls over 1 inch thick, install in conventional manner (See
figure 1).
The main handle of the Safetymix valve is for control of
temperature only. From the OFF position, the handle is turned
counter-clockwise through a minimum cold position, through a warm
and hot position for a maximum turn of approximately one
revolution. This allows for infinite temperature adjustments to
suit the requirements of any user.
To clean the finish of the Safetymix valve, wipe gently with a
soft damp cloth and blot dry with a soft towel. Use only a mild
soap solution if required. DO NOT USE ABRASIVE CLEANERS. USE OF
POLISH, ABRASIVE CLEANERS, SOLVENTS OR ACID CLEANERS WILL DAMAGE
THE FINISH AND VOID THE SYMMONS WARRANTY.
INDIVIDUAL PARTS
C-5
Flow control spindle
C-32-11 Spindle assembly
C-32B-11 Plaster shield
VT-112 Lever handle
SC-2
Cap
SC-3
Renewable seat
SC-7
Packing nut with o-rings
SC-9
Cold washer retainer
SC-10A Hot washer screw
SC-10/11 Hot and cold washers
SC-144 Escutcheon
SC-12D Escutcheon screw
SC-13/18 Dome cover
SC-15A Handle screw
SC-17
Packing
SC-19
Cap gasket
SC-20A/21 Top seat o-ring & bottom
seat gasket
SC-26
Limit stop with o-ring
SC-126 Plaster shield
SC-130 Dome cover gasket
T-149
Escutcheon Gasket
WO-20A Escutcheon screw
SC-144
T-149
WO-20A VT-104
COMPOSITE PARTS
Washer & Gasket KIT-B
SC-9
Cold washer retainer
SC-10A Hot washer screw
SC-10/11 Hot and cold washers
SC-15
Handle screw
SC-17
Packing
SC-19
Cap gasket
Repair units
SC-3
Renewable seat unit complete
C-50
Renewable seat socket wrench
C-5
Spindle
C-32-11 SC-3 C-32B-11
SC-9
SC-130
SC-20A/21 SC-10A SC-10/11
SC-19
C-5
SC-2
SC-26
SC-17 SC-7
WO-20A SC-13/18
VT-112 SC-15A
SC-126 TO BE DISCARDED BEFORE INST ALLING TRIM
FIBERGLASS WALL INSTALLATION
When installing Safetymix in fiberglass or panel walls and it is desired to sandwich wall between valve body and escutcheon, cut hole in wall as shown in Figure 4 and mount valve from rear. Note: It is always recommended to secure valve piping to rough construction and not depend on fiberglass wall for valve mounting security. On panel walls over 1″ thick, install in conventional manner. (See figure 1).
OPERATION OF VALVE
The main handle of the Safetymix valve is for control of temperature only. From the OFF position, the handle is turned counter-clockwise through a minimum cold position, through a warm and hot position for a maximum turn of approximately one revolution. This allows for infinite temperature adjustments to suit the requirements of any user.
CARE AND CLEANING
The lustrous finish on your Safetymix valve should be treated with care. It can be readily damaged by improper handling or abusive treatment. To clean the finish wipe gently with a soft damp cloth and blot dry with a soft towel. Use only a mild soap solution if required. DO NOT USE ABRASIVE CLEANERS. USE OF POLISH, ABRASIVE CLEANERS, SOLVENTS OR ACID CLEANERS WILL DAMAGE THE FINISH AND VOID THE SYMMONS WARRANTY.
