NAUGAHYDE® UPHOLSTERY OPTIONS
FUSION OPERATORY PACKAGE – DENTAL CHAIR SELECTION
| STEP 1 | STEP 1: SELECT YOUR CHAIR – Select 1 chair | ||||||
| Description | Part # | Retail Price | Qty. | Total Price | Comments. color | ||
| c | 3800 Patient Chair, non-tubed | 3800 | $7,250 | Forest Grey w/Shadow baseplate only | |||
| c | 3800 Patient Chair, pre-tubed | 3800PT | $7,770 | Forest Grey w/Shadow baseplate only | |||
| STEP 2 | STEP 2: SELECT YOUR UPHOLSTERY – Select 1 option and 1 upholstery color | |||||
|
c | Standard Naugahyde® Upholstery, Seamless (Included) |
N/A |
N/C | c Black c Deep Sapphire c Sand | c Cocoa c Saddle c Taupe | |
| Standard Ultraleather Colors | ||||||
|
c |
Upgrade to standard Ultraleather® color, Seamless |
$3807-999-UL |
$1,035 | c Autumn Leaf c Boysenberry c Diplomat Blue c Dove Grey c Parrot c St. John | c Baltic c Charcoal c Doe c Papyrus c Raven Wing c Stone | |
| Standard Pearlized Ultraleather Colors | ||||||
| c Midnight c Oz c Tin Man | c Pewter c Pharaoh | |||||
| c | Upgrade, special color Ultraleather, Seamless | 3807-999-UP-UL-SP | $1,390 | Specify Color: | ||
| STEP 3 | STEP 3: ADDITIONAL UPHOLSTERY OPTIONS – Select at least 1 of the below options | ||||||
| Description | Part # | Retail Price | Qty. | Total Price | Comments, color | ||
| c | No Additional Options | N/A | |||||
| c | Neck Pillow (only available in Ultraleather) | 3907-318 | $160 | Color: | |||
| c | Knee Pillow (only available in Ultraleather) | 3907-317 | $490 | Color (inner if dual color): | |||
| c | Dual Color Upholstery, Knee Pillow | 3907-317-DC | $110 | Outer Color: | |||
| c | Contrast Stitch Upholstery, Knee Pillow | 3907-317-DS | $110 | Thread Color: | |||
| c | Pedo Booster Seat (only available in Ultraleather) | 3907-180 | $460 | Color: | |||
| STEP 4 | STEP 4: UTILITY CENTER OPTIONS | ||||||
| Description | Part # | Retail Price | Qty. | Total Price | Comments, color | ||
| c | No Utility Center* | N/A | N/C | Select this option if you are buying a chair-mounted delivery unit | |||
| c | Deluxe Utility Center Housing & Cover, Rear Umbilical Access, Forest Grey | 1115-007-G | $305 | ||||
| c | Deluxe Utility Center Housing & Cover, Right Umbilical Access, Forest Grey | 1115-009-G | $305 | ||||
| *If you are ordering a chair-mounted delivery unit then select “No Utility Center” because one will be included with your delivery unit | |||||||
| STEP 5 | STEP 5: CHAIR CONTROL LOCATION – Select at least 1 chair control | |||||
| Maximum of 1 control can be mounted to the delivery unit, maximum of 2 on the chair (left and right), 4 total maximum number of controls per operatory | ||||||
| c | First Chair Control (Required) First control included with chair purchase | 3914-998-CS | N/C | c Delivery Unit c Chair, right side | c Footswitch c Chair, left side | |
| c | Second Chair Control (Optional) | 3914-999-CS | $650 | c Delivery Unit c Chair, right side | c Footswitch c Chair, left side | |
FUSION OPERATORY PACKAGE – FUSION DELIVERY UNIT
STEP 6: SELECT YOUR DELIVERY SYSTEM – Select 1 delivery system
| c | Fusion Delivery Head, Pivot Chair Mount | 4296PI | $7,310 | Forest Grey paint & plastics only |
| c | Fusion Delivery Head, Fixed Chair Mount with Sidebox | 4295SI | $8,830 | Forest Grey paint & plastics only |
STEP 7: CONFIGURE YOUR DELIVERY SYSTEM
| Description | Part # | Retail Price | Qty. | Total Price | 0 | 1 | 2 | 3 | 4 | 5 | 6 | |
| c | Air/Water Syringe (included standard) | N/C | ||||||||||
| c | 4-hole handpiece tubing (included standard) | N/C | ||||||||||
| c | 5-hole system (1 tubing included, system accomodates a 2nd tubing) | 1700-021-CS | $930 | |||||||||
| c | – Second 5-hole tubing | 0017-615-CS | $360 | |||||||||
| c | 6-pin system (1 tubing included, system accomodates a 2nd tubing) | 1700-019-CS | $930 | |||||||||
| c | – Second 6-pin tubing | 0017-603-CS | $255 | |||||||||
| c | Star® ETorque Electric System, Factory Installed* | STAR-ETORQUE | $5,705 | |||||||||
| c | Star Blis-sonic™ SW Scaler (with 4 line swivel)* | STAR-BLIS-SW | $1,835 | |||||||||
| c | Star Blis-sonic K Scaler (with fixed back-end)* | STAR-BLIS-K | $1,565 | |||||||||
| c | Satelec SP Scaler* | SATELEC-S | $3,000 | |||||||||
| c | Satelec SP LED Scaler* | SATELEC-S-LED | $3,750 | |||||||||
| c | Cavitron Scaler* | CAVITRON | $5,270 | |||||||||
| c | Additional Handpiece Position, Wet | 1100-189-CS | $540 | |||||||||
| c | Additional Handpiece Position, Air Drive Only | 1100-190-CS | $270 | |||||||||
| c | Assistant’s hygiene instrumentation, control head-mounted Select 1 position for the SE and 1 position for the HVE | 1408-CS | $485 | SE | ||||||||
| HVE | ||||||||||||
| c | Star Handpiece Bundle (Write-in PN and price) | |||
| c | Quick Disconnect w/Flow Control, 1/4” (for water) | 0016-454-CS | $190 | Included with 4295SI |
| c | Quick Disconnect w/Flow Control, 3/8” (for air) | 0016-456-CS | $190 | Included with 4295SI |
| c | Swivel Tray | 1110-468 | $440 | |
| c | Less sidebox telescoping assistant’s instrumentation | 1400-000-CS | -$350 | 4295SI only |
| c | Chrome Accents | 9000-998-CS | $180 | |
| c | Additional Umbilical, Per Foot (max of 9 feet) | 1115-999-CS | $45 | |
| c | Routing Valve Kit w/Water shutoff & Regulator, Factory inst. | 1115-315-CS | $385 | Included with 4295SI |
| c | Routing Valve Kit for Cuspidor, Factory Installed | 1115-316-CS | $185 | |
| *Ancillaries utilize an existing handpiece position | ||||
| STEP 8 | STEP 8: ASSISTANT’S INSTRUMENTATION AND CUSPIDORS – Must select 1 option for order to be valid | ||||
| c | No Assistant’s Instrumentation or Cuspidor* | N/A | N/C | ||
| c | Rear Pivot Instrumentation, Quad Holder Bar | 1295 | $1,785 | Not available with 4295SI | |
| c | Rear Pivot Instrumentation with Integrated Touchpad | 1296 | $1,785 | Not available with 4295SI | |
| c | Rear Pivot Instrumentation with Deluxe Cuspidor | 1592 | $4,000 | Not available with 4295SI | |
| c | Deluxe Cuspidor only, Rear Pivot | 1582 | $3,515 | Not available with 4295SI | |
| c | Basic Cuspidor, Sidebox Mounted | 1679 | $1,220 | Only available with 4295SI | |
| c | Deluxe Cuspidor, Sidebox Mounted | 1577 | $2,030 | Only available with 4295SI | |
| *Sidebox mounted telescoping assistant’s instrumentation included standard with 4295SI | |||||
| STEP 9 | STEP 9: ASSISTANT’S INSTRUMENTATION AND CUSPIDOR OPTIONS | ||||
| c | Quick Disconnect w/Flow Control, 1/4” (For 1095 instrumentation) | 0016-455-CS | $190 | Specify One c Air c Water | |
| c | Additional Autoclavable HVE with 5’ Tubing & Dry Oral Cup | 1400-113-CS | $125 | ||
| c | Hands-Free HVE Holder with HVE and 5’ Tubing | 1400-279-STG | $470 | ||
| c | Self-Contained Clean Water System w/Quick Disconnect, 1.5L bottle (For 1095 Instrumentation only) | 1700-319 | $360 | ||
| c | Tray Assembly (For 1095 Instrumentation only) | 1110-680 | $730 | ||
| c | Deluxe Cuspidor Unit-Mounted Activation (For 1577, 1582, 1592) | 1100-480-CS | $345 | ||
| c | Chair Control Touchpad – Mounted to 1095 Instrumentation | 1700-088-CS | $650 | ||
OPERATORY PACKAGE – OPERATORY LIGHT SELECTION
| 9083 Halogen | 9078 LED | Total Price | |||||
| Lights with Fusion packages come in Forest Grey Only | Part # | Retail Price | Qty | Part # | Retail Price | Qty | |
| Chair Mount | c 9083 | $2,790 | c 9078 | $3,455 | |||
| Ceiling Mount | c 9083-C | $3,600 | c 9078-C | $4,720 | |||
| Wall Mount | c 9093W | $4,260 | c 9079W | $5,530 | |||
| Cabinet Mount | c 9093C | $4,260 | c 9079C | $5,530 | |||
| Track Mount | c 9083T | $5,200 | c 9078T | $6,335 | |||
| STEP 11: OPERATORY LIGHT CONFIGURATION AND OPTIONS | ||||||
| STEP 11 | Chair Mounted Light Options (Pivot, Sidebox, and Fixed) | |||||
| Description | Part # | Retail Price | Qty | Total Price | ||
| c | 20” Rigid Arm in Lieu of Standard 32” Arm | 1110-227-CS | N/C | |||
| Light Posts (Select 1) | ||||||
| c | Sidebox, 44” Post | 1110-900 | $275 | |||
| c | Sidebox w/Monitor Cord slot, 44” | 1110-170 | $275 | |||
| c | Pivot without chair adapter (adapter included with unit purchase) | 1113-654 | $760 | |||
| c | Pivot with 3800/3900 chair adapter (when chair-mounted unit not ordered) | 1113-654-CA | $1,510 | |||
| Monitor Mount Assemblies | ||||||
| c | Ring Post Mount Assembly (Must pair with either PN 1110-170 or 1110-045 above) This option allows you to have both a light and monitor mounted to your chair | 1300RM | N/C | |||
| c | Top Post Mount Assembly (Must pair with one of the post options below) This option allows a monitor instead of a light on your chair | 1300TPM | N/C | |||
| c | Sidebox: Monitor Post, Dual Slot, Fixed Sidebox Mount, 30” | 1331-998 | $275 | |||
| c | Pivot: Monitor in Lieu of Light Post, Pivot | 1331-654 | $760 | |||
| c | Pivot: Monitor in Lieu of Light Post, Pivot with Chair Adapter | 1331-654-CA | $1,510 | |||
| Ceiling Mounted Light Configuration (Select Mounting Height and Post Length) | ||||||
| Mounting Height (Required) c 8’ c 8’6” c 9’ c 9’6” c 10’ c 1 | 0’6” c 11’ c | Custom Height, Sp | ecify: | |||
| Post Length (Required) c 12” c 18” c 24” c 30” c 36” c 42 | ” c 48” c | Custom Length (ma | x 48”), | Specify: | ||
| Cabinet and Wall Mounted Light Configuration and Options | ||||||
| Description | Part # | Retail Price | Qty | Total Price | ||
| Arm Height (Required): c Standard c Tall | N/A | N/A | ||||
| Specify Cabinet or Wall Mounting Height (write-in): | N/A | N/A | ||||
| c | Horizontal Top Cabinet Mount in Lieu of Internal Mount | 1110-881-CS | N/C | |||
| c | Vertical Exterior Cabinet Mount in Lieu of Internal Mount | 1110-886-CS | N/C | |||
| Track Mounted Light Configuration and Options | ||||||
| c | Monitor Mount Assembly (specify monitor post length in next section) | 1305T | $2,960 | |||
| c | S Video Cable, Pre-Installed | 0014-282 | $65 | |||
| c | RCA Cable, Pre-Installed | 0014-283 | $65 | |||
| Select Track Mount Light Post Lengths | ||||||
| Mounting Height (Required) c 8’ c 8’6” c 9’ c 9’6” c 10’ c 10’6” | c 11’ c Cu | stom Height, Specif | y: | |||
| Light Post Length (Required) c 8.25” c 14.25” c 20.25” c 26.25” c 32.25” c 38.25 | ” c 44.25” c Cu | stom Length (max 44 | .25”), Spe | cify: | ||
| Monitor Post Length c 20.25” c 26.25” c 32.25” c 38.25” c 44.25” c 50.25 (Required if 1305T selected) | ” c 56.25” c Cu | stom Length (max 56. | 25”), Spe | cify: | ||
