207-5 Sport Special Needs Trike
Product Information
The product is a tricycle model 207-5 SPORT. It has a maximum
capacity load of 100 kg (220.4 lb) and weighs 24 kg (52.9 lb). The
tricycle is available in four different frame colors: White, Blue,
Red, and Pink. It comes with optional components such as
three-speed gears, disc brake, cranks adjustable in length,
adjustable ergonomic handles, pedal cages with strap or foot
imprints, trunk/pelvic support with tight or wide strap, long or
short pole for trunk/pelvic support, ergonomic narrow saddle with
flat backrest, forearm support, ankle support with calf adjustment,
steering limiter, steering limiter with spring, and additional
assistant push handle.
Product Usage Instructions
- Before using the tricycle, please read the user and maintenance
manual carefully. - Check the order form and make sure all the interested products
are marked with an “X”. - Select the desired frame color for the tricycle (White, Blue,
Red, or Pink). - Choose the configuration of the tricycle based on the available
options: Fixed pinion, Free Wheel, Differential and fixed pinion,
or Differential and free wheel. - If applicable, select optional components such as three-speed
gears (only for Free Wheel models), disc brake (only for
Differential models), cranks adjustable in length (to decrease the
distance between saddle and pedal), and adjustable ergonomic
handles. - Choose the position of the brake on the Standard Handlebar
(Left or Right). - If desired, select additional optional components separately
such as pedal cages with strap or foot imprints, trunk/pelvic
support with tight or wide strap, long or short pole for
trunk/pelvic support, ergonomic narrow saddle with flat backrest,
forearm support, ankle support with calf adjustment, steering
limiter, steering limiter with spring, or additional assistant push
handle. - Fill in the necessary details on the order form and download
it. - Send the completed order form to [email protected].
DISTRIBUTOR/AGENT:
DATE OF ORDER: DATE OF DELIVERY: NAME OF THE ADDRESSEE/USER:
ORDER FORM
TRICYCLE
207-5 SPORT
F · Ergonomic and modular tricycle that helps the user to keep a
E A T
proper posture and makes the ride easier thanks to its design and components. · Folding frame to reduce the encumbrance during transport. · Bell.
U · Front brake that can be operated by the lever either on the right
R
or on the left side of the handlebar. The distance between the
E S
brake lever and the handlebar is adjustable by screw. · Locking mechanism of the tricycle (it blocks the tricycle when
the User climbs on/off).
· Ergonomic saddle.
· Basket.
· Mudguards.
· Wheels run on ball bearings. A mechanism on the rear wheels allows easy adjustment of the tension of the chain.
Please check off the interested products: X
M FRAME COLOUR:
E
White
A
Blue
S
Red
U
Pink
R
E
S
A
842/842W
Trunk/Pelvic support
17,5 cm 6,8 in
35 cm – 13,7 in
Product marked Attention! Read carefully the user and maintenance manual
*841 Pedal cage with foot imprint and fastening strap
A
C
B
size 3
841 foot imprint size
AB C
8,2 cm 20 cm 10,4 cm
3,2 in 7,8 in
4 in
size 4-5
9,4 cm 22,5 cm 3,7 in 8,8 in
12 cm 4,7 in
D
user shoe lenght
D
from 21 to 24 cm from 8,2 to 9,4 in
from 24 cm from 9,4 in
INGLESE – cod.220512 – 28/10/22
C
F
I
H
D
B
E
G
207-5
Max Cap Load
kg. 100 lb. 220,4
Aid Weight
kg. 24 lb. 52,9
A
B
C*
D
E
F
G
I
User Height (H)
cm 60 cm 77 cm 73-87 cm 40 cm 175 cm 114-128 cm 105 cm 115 cm 155-185 in 23,6 in 30,3 in 28,7-34,2 in 15,7 in 68,8 in 44,8-50,3 in 41,3 in 45,2 in 61-72,8
*see 847 Cracks
download and send the form to [email protected]
Foligno (PG) Italy · Tel. +39 0742 22927 · Fax +39 0742 22637 · www.ormesa.com
ORDER FORM
TRICYCLE
207-5 SPORT
CHOOSE THE CONFIGURATION >
Fixed pinion
Free Wheel
Differential and fixed pinion
Differential and free wheel
OPTIONAL COMPONENTS, ONLY CHOOSABLE WHEN ORDERING THE TRYCICLE
862 Three speed gears (it
eliminates the possibility of cycling backwards). ONLY FOR FREE WHEEL MODELS.
864 Disc brake. ONLY FOR
DIFFERENTIAL MODELS.
847 Cranks adjustable in length
further decreases the distance between saddle and pedal of 3,5 cm and 5 cm (1,3 in and 1,9 in).
Please choose the position of the brake on Standard Handlebar
Left
Right
OPTIONAL COMPONENTS, ALSO CHOOSABLE SEPARATELY
880 Adjustable Ergonomic
Handles (1 pair). Same size as the Handlebar. Please choose the position of the brake on Ergonomic Handles:
840 Pedal cages with
strap (1 pair).
841 Pedal cages with foot imprints
and fastening straps (1 pair). size 3
Left
Right
size 4-5
for the size please refer to the tab at page 1*
841, 842, 842W, 883, 845, 846: you can choose smaller size
842 Trunk/Pelvic support with
tight strap. Please choose the pole.
size 3
size 4-5
842W Trunk/Pelvic support with
wide strap. Please choose the pole.
883 Long pole for Trunk support
(842/842W). Please choose the support.
size 3
size 4-5
size 3
size 4-5
884 Short pole for Pelvic support
(842/842W). Please choose the support.
843 Ergonomic narrow saddle
with flat backrest
843 + 842/842W
Ergonomic narrow saddle + Trunk/Pelvic support (please select above)
845 Forearm support.
Left
size 3
Right
size 4-5
846 Ankle support with calf
adjustment. Only with 841.
Left
size 3
Right
size 4-5
881 Steering limiter
882 Steering limiter with spring
923 Additional assistant push
handle
Notes: ——————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————-
