Nvent Ccs2rblg Compact Series 2 Rotational Base Instruction Manual

CCS2RBLG Compact Series 2 Rotational Base

Product Information:

Product Name: Compact

Model Number: 901.2087.000

Revision: I

Product Usage Instructions:

1. Torque Specification: 7.38-8.85 ft-lbs or 10-12 NM
2. Base Mounting Cutout: Refer to the provided diagrams for the
   dimensions and shape of the base mounting cutout.
3. For continuous conductivity, it is recommended to place a
   serrated lock washer according to DIN 6798-A 8,4 (part not
   included) under the fastening screw head.
4. Ensure that the serrated lock washer is properly positioned
   before tightening the fastening screw.
5. Refer to the provided diagrams for proper placement of the
   serrated lock washer.

Compact
Pendant Arm Series 2 Tragarmsystem Serie 2 Système de suspension série Sistema de suspensión

901.2087.000

Rev. I

© 2020 Hoffman Enclosures Inc.

PH 763 422 2211 · nVent.com/HOFFMAN P/N 21360001

87567800

7.38-8.85 ft-lbs 10 – 12 NM
7.38-8.85 ft-lbs 10 – 12 NM
7.38-8.85 ft-lbs 10 – 12 NM

– 2 –

© 2020 Hoffman Enclosures Inc.

PH 763 422 2211 · nVent.com/HOFFMAN

87567800

Base Mounting Cutout Niedriger Montage-Ausschnitt Coupe-circuit Bas De Support
Recorte Bajo Del Montaje
For continuous conductivity please place serrated lock washer according DIN 6798-A 8,4 (part not included) under fastening screw head.
Für durchgängige Leitfähigkeit Fächerscheibe DIN 6798-A 8,4 (nicht im Lieferumfang enthalten) unter BefestigungsSchraubenkopf legen.
Pour la conductivité continue, placer la rondelle dentelée selon DIN 6798-A 8,4 (pièce non incluse) sous la tête de la vis de fixation.
Para conductividad continua, coloque la arandela de seguridad dentada según el DIN 6798-A 8,4 (no incluído) debajo de la cabeza del tornillo de fijación

Base Mounting Cutout Niedriger Montage-Ausschnitt Coupe-circuit Bas De Support
Recorte Bajo Del Montaje

For continuous conductivity please place serrated lock washer according DIN 6798-A 8,4 (part not included) under fastening screw head.
Für durchgängige Leitfähigkeit Fächerscheibe DIN 6798-A 8,4 (nicht im Lieferumfang enthalten) unter BefestigungsSchraubenkopf legen.
Pour la conductivité continue, placer la rondelle dentelée selon DIN 6798-A 8,4 (pièce non incluse) sous la tête de la vis de fixation.
Para conductividad continua, coloque la arandela de seguridad dentada según el DIN 6798-A 8,4 (no incluído) debajo de la cabeza del tornillo de fijación

87567800

© 2020 Hoffman Enclosures Inc.

PH 763 422 2211 · nVent.com/HOFFMAN

– 3 –

Rev. I

© 2020 Hoffman Enclosures Inc.

PH 763 422 2211 · nVent.com/HOFFMAN P/N 21360001

87567800
