00810129314953 3 Light 19 In Matte Black and Polished Gold LED Semi Flush Mount Light
Product Information: – Item Number: A05044 – Maximum
Voltage: 120V – Maximum Wattage per Bulb: 40W (Type B) – Parts
Included: Mounting plate (1), Green ground screw (1), Canopy (1),
Knob nut (2), Arm (3), Socket (3), Glass shade (3) – Accessories
Included: Plastic wire connector (3), Mounting screw (2) Product
Usage Instructions: 1. Preparation: Before starting
assembly and installation, gather the following tools (not
included): Ladder, Philips Head or Flat Blade Screwdriver,
Electrical Tape, Pliers, Wire Cutter/Stripper. 2. Installation
Safety: To reduce the risk of fire, electric shock, or personal
injury, follow these precautions: – We suggest installation by a
licensed electrician. – Read the instruction manual carefully and
save it for future reference. – NEVER attempt any work without
shutting off the electricity until the work is done. – Ensure the
mounting surface is clean, dry, flat, strong enough, and 1/4 larger
than the canopy on all sides. Correct any gaps exceeding 3/16 as
required. – Check if the ceiling or wall can support the weight of
the lamp before installation. – Use a voltage of 120V and ensure
that the maximum wattage per bulb does not exceed 40W (Type B). –
Keep the lamp away from acidic and alkaline substances to avoid
damaging the surface. – When replacing bulbs, turn off or unplug
the lamp and wait until it is cool as bulbs can get hot quickly. –
Use common sense, caution, and care when dealing with electrical
products. 3. Assembly and Installation: – Carefully remove
the fixture from the carton and ensure all parts and accessories
are included. – Turn off the power before starting the
installation. – Remove the mounting plate (C). – Connect the wires
as shown in the wire connection chart. Note that the ground wire is
a bare copper wire and should not be connected to other wires. –
Connect the ground wires according to the chart. – Connect the
black or red supply wire to the designated outlet box ground or
fixture ground. – Connect the white supply wire to the designated
outlet box ground. – Use cupped washers when using parallel cords
(round & smooth or square & ridged) and follow the
instructions in the illustration. – Ensure proper connection of
neutral wires as described in the illustration. Please refer to the
user manual for additional instructions and illustrations. For
further assistance, you can contact our customer care team at +1
850 296 2377 during working hours (Mon – Fri 9:00 – 16:00 EST) or
email us at [email protected].
+1 850 296 2377 Working hours : Mon – Fri 9:00 – 16:00 EST
Item Number: A05044
WARNING (To reduce the risk of fire, electric shock, or personal injury): 1. We suggest installation by a licensed electrician. 2. Please read the instruction carefully and save it as you may need it at a later time. 3. Before you start, NEVER attempt any work without shutting off the electricity until the work is done.
» Go to the main fuse, or circuit breaker, box in your home. Place the main power switch in the “OFF” position.
» Place the wall switch in the “OFF” position.
4. Mounting surface should be clean, dry, flat, strong enough and 1/4″ larger than the canopy on all sides. Any gaps between the mounting surface and canopy exceeding 3/16″ should be corrected as required.
5. Make sure that the ceiling or wall can stand the weight of the lamp before installation. 6. Make sure the voltage you are using is 120V. The maximum wattage is Type B, Max 40W per blub. 7. Keep the lamp away from acidic and alkaline substances in case of damaging the surface of the lamp. 8. When replacing bulbs, you should turn off or unplug the lamp and you must wait until it is cool as bulbs get hot
quickly. 9. The safety instructions appearing in this manual are not meant to cover all possible conditions that may occur. It
must be understood that common sense, caution and care must be used with any electrical products.
IMAGE FOR FINISHED PRODUCT:
TOOLS REQUIRED Before starting assembly and installation please prepare the needed (NOT INCLUDED): tools as below picture
Ladder
Philips Head or Flat Blade Screwdriver
Electrical Tape
Pliers
Wire Cutter/Stripper
Page: – 1 – / 4
+1 850 296 2377 Working hours : Mon – Fri 9:00 – 16:00 EST
PARTS TYPE & QTY INCLUDING: (C) Mounting plate (1) (D) Green ground screw (1) (E) Canopy (1) (F) Knob nut (2) (G) Arm (3) (H) Socket (3) (I) Glass shade (3)
ACCESSORIES & QTY ENCLOSED: (A) Plastic wire connector (3) (B) Mounting screw (2)
ASSEMBLY & INSTALLATION INSTRUCTIONS: 1. Carefully remove the fixture from the carton and check that all parts and accessories are
included as shown in the above illustration. 2. Turn off power
Before you start the installation, NEVER attempt any work without shutting off the electricity until the work is done.
» Go to the main fuse, or circuit breaker, box in your home. Place the main power switch in the “OFF” position.
» Place the wall switch in the “OFF” position. 3 » Unscrew knob nuts (F) from canopy (E).
Remove mounting plate (C).
Page: – 2 – / 4
+1 850 296 2377 Working hours : Mon – Fri 9:00 – 16:00 EST 4 » Adjust arms (G) to proper position as shown in the
illustration.
5 » Attach mounting plate (C) to the outlet box with mounting
screws (B).
6 » Make wire connections
Connect wires as below wires connection shown. PLEASE NOTE THAT GROUND WIRE IS BARE COPPER WIRE, NEVER CONNECT OTHER WIRES TO GROUND WIRES.
Connect ground wires according to the below chart
A
B
Connect wires according to the below chart
Connect Black or Red Supply Wire to:
Connect White Supply Wire to:
OUTLET BOX GROUND GREEN GROUND SCREW
OUTLET BOX GROUND
FIXTURE GROUND
DIMPLES
GREEN GROUND SCREW
Black
White
*Parallel cord (round & smooth)
*Parallel cord (square & ridged)
FIXTURE GROUND
Clear, Brown, Gold or Black without tracer
Insulated wire(other than green) with copper conductor
Clear, Brown, Gold or Black with tracer
Insulated wire(other than green) with silver conductor
CUPPED WASHER
* Note: When parallel wires (SPT I& SPT ll) are used. The neutral wire is square shaped or ridged and the other wire will be round in shape or smooth (see illus.)
Neutral Wire
· Twist wires together with plastic wire connectors until tightly joined. · Wrap each connector with approved electrical tape. · Be sure that no wire strands are exposed and then carefully tuck all wires into the outlet box.
Page: – 3 – / 4
+1 850 296 2377 Working hours : Mon – Fri 9:00 – 16:00 EST
7 » Raise canopy (E) to the ceiling and secure canopy (E) in
place by tightening knob nuts (F) onto the pre-assembled screws in mounting plate (C).
Note: canopy (E) should be snug against the ceiling and knob nuts (F). If not, adjust the threaded length on mounting plate (C): · Unscrew the pre-assembled hex nuts. · Screw the pre-assembled screws in or out of
mounting plate (C). · When the secure length is achieved, tighten the hex
nuts and back to step 7.
8 » 1) Install bulbs (not included) (Please do not
exceed the maximum wattage recommended on the socket.)
2) Screw glass shades (I) to sockets (H) as shown in the illustration.
9. Check everything is already installed properly, then you could turn on the light. Enjoy!
ORDERING PARTS
Keep this sheet for future reference in case you need to order replacement parts. All parts for this fixture can be ordered from the place of purchase. Be sure to use exact wording from illustration when ordering parts.
CLEANING
To clean, wipe the fixture with a soft cloth. Do not use abrasive materials such as scouring pads or powders, steel wool or abrasive paper.
