120VAC 60Hz Ceiling Fixture
Product Information
The Ceiling Fixture is a product with a 120VAC/60Hz input that
is dimmable. It comes with a mounting plate, wall anchors, mounting
screws, wire nuts, anchor screws, and a lampshade. The product must
be installed and serviced with caution to prevent possible injury
from electric shock. All electrical connections must be in
accordance with local and National Electrical Code (N.E.C.)
standards. If you are unfamiliar with proper electrical wiring
connections, obtain the services of a qualified electrician.
Product Usage Instructions
- Turn off the main power at the circuit breaker before
installing and servicing the fixture. - Center the mounting plate over the outlet box and mark the
location of the holes for the wall anchors. - Drill a hole at each marked location and insert a wall anchor
into each hole. - Attach the black supply wire to the black fixture wire by using
the wire nut. Attach the white supply wire to the white fixture
wire by using the wire nut. Connect the fixture ground wire to the
supply ground wire using a wire nut. - Align the mounting screw with the lock hole of the fixture,
twist the fixture body until it is securely hung, and tighten the
mounting screw through the hole in the plate using a screwdriver as
needed to secure the fixture body. - Insert an anchor screw into each wall anchor.
- Align the slot on the glass with the stud on the ceiling and
the jig body, and twist the lampshade cover until it is securely
hung. - Restore electrical power when complete.
Note: The outlet box is not included with the product and all
electrical connections must be in accordance with local and
National Electrical Code (N.E.C.) standards. If you are unfamiliar
with proper electrical wiring connections, obtain the services of a
qualified electrician.
INSTALLATION INSTRUCTIONS
CEILING FIXTURE
120VAC/60Hz Input, Dimmable
READ AND FOLLOW SAFETY INFORMATON
1 4
CAUTION – Turn off the main power at the circuit breaker before
installing and servicing the fixture to prevent possible injury from electric shock.
3 2
All electrical connecons must be in accordance with local and Naonal
Electrical Code (N.E.C.) standards. If you are unfamiliar with proper
electrical wiring connecons, obtain the services of a qualified
electrician.
INSTALLATION & ASSEMBLEY
1.Center the mounting plate (5) over the outlet box (1) and mark the
6
location of the holes for the wall anchors (2).
7
2. Drill a hole at three marked locations, and then insert a wall anchor (2)
into each hole.
3.Attach the black supply wire to the black fixture wire by using the wire nut (4). Attach the white supply wire to the white fixture wire by using the wire nut (4). Connect the fixture ground wire to the supply ground wire using a wire nut (4).
4. Align the mounting screw (3) with the lock hole of the fixture, twist the fixture body until the fixture body is securely hung, and tighten the mounting screw through the hole in the plate using a screwdriver as needed to secure the fixture body.
5.Insert an anchor screw (3) into each wall anchor (2).
6. Align the slot on the glass with the stud on the ceiling and the jig body, and twist the lampshade(7) cover until it is securely hung.
7.Restore electrical power when complete.
1. OUTLET BOX (NOT INCLUDED) 2. WALL ANCHOR 3. MOUNTING SCREW 4. WIRE NUT 5. MOUNTING PLATE 6. ANCHOR SCREW 7. LAMPSHADE
