JSC-D23036-BB Ceramic Hob
Product Information:
Product: Jessier Touch control Ceramic Hob
Model: JSC-D23036-BB
Date: 20230306A0
Product Overview:
- 1. 200mm/1800W
- 2. 165mm/1200W
- 3. Glass
- 4. Control panel
Features:
- Stop&go function
- Heating zone selection controls
- Timer control
- Child lock control
- Power / Timer regulating controls
- ON/OFF control
Product Usage Instructions:
1. Choosing the Right Cookware:
To ensure proper functioning of the ceramic hob, it is important
to use the right cookware. Use flat-bottomed cookware with a smooth
and clean surface. Avoid using cookware with uneven or damaged
bases.
2. Using Your Ceramic Hob:
To use the ceramic hob, follow these steps:
- Ensure the hob is properly installed and connected to the power
supply. - Place the suitable cookware on the desired heating zone.
- Turn on the hob by pressing the ON/OFF control.
- Select the desired heating zone by using the heating zone
selection controls. - Adjust the power level or set a timer using the power/timer
regulating controls. - Monitor the cooking process and make necessary adjustments as
needed. - After cooking, turn off the hob by pressing the ON/OFF
control. - Allow the hob to cool down before cleaning.
3. Locking the Controls:
To lock the controls and prevent accidental changes, activate
the child lock control. Refer to the instruction manual for
detailed steps on how to lock and unlock the controls.
4. Using the Timer:
The ceramic hob features a timer control for precise cooking.
Set the desired cooking time using the timer control. The hob will
automatically turn off once the set time has elapsed. Refer to the
instruction manual for detailed steps on how to use the timer
function.
5. Care and Cleaning:
After each use, ensure the hob is turned off and cool before
cleaning. Clean the hob using a soft cloth or sponge with mild
detergent. Avoid using abrasive cleaners or sharp objects that may
scratch the surface. Refer to the instruction manual for detailed
cleaning instructions.
Note: For troubleshooting assistance or further
inquiries, please contact Jessier customer service at
[email protected].
Disclaimer: Weight and dimensions are
approximate. Specifications and designs may be subject to change
without prior notice as we continually strive to improve our
products.
Jessier
Instruction Manual / Installation Manual Touch control Ceramic Hob
Model : JSC-D23036-BB
20230306A0
SAFETY WARNINGS INSTALLATION
OPERATION AND MAINTENANCE
1
2
3
4
INTRODUCTION
PRODUCT OVERVIEW
1 2 3
4 2
14 5 36
1.200mm/1800W 2.165mm/1200W 3.Glass 4.Control panel
1.Stop&go 2.Heating zone selection controls 3. Timer control 4.Child lock control 5.Power / Timer regulating controls 6.ON/OFF control
5
PRODUCT INFORMATION
CHOOSING THE RIGHT COOKWARE
6
USING YOUR CERAMIC HOB
7
LOCKING THE CONTROLS
8
9
USING THE TIMER
30
6
30
00
—
36
6
—
10
6 3
03
05
—
0
–
H
TROUBLESHOOTING
Jessier_service@out look.com Jessier_service@out look.com 11
COOKING GUIDELINES FOR REFERENCE ONLY
°
12
HEAT SETTINGS
13
CARE AND CLEANING
14
HINTS AND TIPS
TECHNICAL SPECIFICATION
Cooking Hob
JSC-D23036-BB
Cooking Zones
2 Zones
Supply Voltage
240V~, 60Hz
Installed Electric Power
3000W
Product Size
L×W×H(mm)
290X520X44
Building-in Dimensions A×B (mm)
270X490
Weight and Dimensions are approximate. Because we continually strive to improve our products we may change specifications and designs without prior notice.
15
INSTALLATION
Under any circumstances, make sure the Induction cooker hob is well ventilated and the air inlet and outlet are not blocked. Ensure the Induction cooker hob is in good work state. As shown below
!
16
17
32A 3X1.5mm²
110-127V~ 16A
L1
N
220-240V~32A
L1
L2
L2
N
220-240V~16A
L1 L2
110-127V~16A
18
19
