MF 5350 Clifford 18 Inch Sculpted Hanging Shade
Product Information
Product Name: Clifford 18 Sculpted Hanging
Shade
Item Number: MF 5350
Package Contents: The package includes the
hanging shade (M), canopy (G), collar loop (D), collar ring (H),
mounting plate (B), junction box mounting screws (C), chain (I),
quick links (E and J), wire nut (A), screws (L), and assembly
instructions.
Bulbs: Bulbs are not included in the
package.
Important Notice: This light fixture should be
installed by a person familiar with its construction and operation,
as well as the hazards involved. It should be installed in
accordance with all applicable local installation codes. Inspect
the item and its contents carefully before installation. If any
damage or defect is found, do not install. Retain all packaging
material until installation is complete and approved.
Tools Required (Not Included):
- Phillips Screwdriver
- Slotted Screwdriver
- Slip Joint Pliers
- Measuring Tape
- Wire Strippers
- Scissors
- Chain Pliers Wire Cutters
Product Usage Instructions
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Loosen screw (F) on quick link (E) and remove collar loop (D)
from the chain (I). - Install the mounting plate (B) to the junction box and secure
it with the provided mounting screws (C). - Secure the collar loop (D) to the mounting plate (B) using
pliers to tighten the locknut. - Attach the canopy (G) to the collar loop (D) and secure it with
the collar ring (H). - Determine the desired overall length and amount of chain (I)
needed. Use chain pliers to shorten the chain. Keep any extra chain
for future use. - Loosen screw (F) on quick link (J) and attach the chain (I) to
the collar loop (D). - Wrap the fixture ground wire (bare copper) around the green
grounding screw as shown in diagram 3, then tighten it. Connect the
fixture ground wire to the supply ground wire (usually green or
bare copper) using the wire nut (A). Ensure proper grounding. - Connect the fixture neutral wire (ribbed) to the supply neutral
wire (usually white) using the wire nut (A). - Connect the fixture hot wire (smooth with markings) to the
supply hot wire (usually black) using the wire nut (A). Be cautious
not to reverse the hot and neutral connections. - Make sure all wire connections are tight, then carefully tuck
them into the junction box. - Install the canopy (G) to the collar loop (D) and secure it
with the collar ring (H). - Install light bulbs into the sockets.
- Remove shade (M) from packaging and attach it to the fixture
(K) using the provided screws (L). If there is additional packaging
inside the shade, carefully cut it off to avoid damages.
Care Instructions:
Clean the product only with a soft dry cloth or feather duster.
Do not use abrasive or chemical agents.
ASSEMBLY INSTRUCTIONS
Diagram 3 E
F Diagram 1
J F Diagram 2
A
C
B D
E F
G H
I
J F
K
Bulbs not included
L M (Packaged separately)
Clifford 18″ Sculpted Hanging Shade
Item # MF 5350
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Slip Joint Pliers
Measuring Tape
Wire Strippers
Scissors
Chain Pliers Wire Cutters
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Loosen screw (F) on quick link (E), then remove collar loop (D) from
chain (I). 3. Install mounting plate (B) to the junction box and secure with
mounting screws (C). 4. Secure collar loop (D) to mounting plate (B) using pliers to tighten
locknut. 5. Install canopy (G) to collar loop (D) and secure with collar ring (H). 6. Determine desired overall length, and amount of chain (I) needed.
Shorten chain using chain pliers. (Keep extra chain) 7. Loosen screw (F) on quick link (J), then attach chain (I) to collar
loop (D) and fixture (K) using quick links (E & J). Tighten with screws (F). See diagram 1 & 2. 8. Thread fixture wire and ground wire through chain (I). NOTE: When you reach the collar loop (D), ensure there is no tension on the wires. Cut excess wires, being sure to leave enough to reach the junction box. 9. Separate two sides of molded wire, and strip insulation on each 5/8″. 10. Loosen collar ring (H) and let canopy (G) slip down chain (I) carefully. 11. Twist all fixture wires together. Slip through center hole of collar loop (D). NOTE: Untwist wires and separate to prepare for connection.
M
LI ST ED
US
ASSEMBLY INSTRUCTIONS
Diagram 3 E
F Diagram 1
J F Diagram 2
A
C
B D
E F
G H
I
J F
K
Bulbs not included
L M (Packaged separately)
Clifford 18″ Sculpted Hanging Shade
Item # MF 5350
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
12. Wrap fixture ground wire (bare copper) around the green grounding screw (see diagram 3). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (A). NOTE: It is imperative that the fixture is grounded.
13. Connect fixture neutral wire (ribbed) to the supply neutral wire (usually white) using wire nut (A).
14. Connect fixture hot wire (smooth with markings) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
15. Make sure all wire connections are tight, then carefully tuck into the junction box.
16. Install canopy (G) to collar loop (D) and secure with collar ring (H). 17. Install light bulbs into the sockets. 18. Remove shade (M) from packaging, then attach shade (M) to
fixture (K) and secure with screws (L). NOTE: If shade has additional packaging, carefully cut off from interior of shade to avoid damages.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do Not use abrasive or chemical agents.
M
LI ST ED
US
