N3 IMU GNSS Receiver
Product Information
- Product Name: N3 IMU GNSS Receiver
- Product Series: N Series GNSS Receiver
- Version: 2022.01.30
- Dimensions: 7.3 cm (height), 15.5 cm (width)
The N3 IMU GNSS Receiver is an ultra-reliable and compact
receiver designed to track all current and planned Global GNSS
constellations. It is equipped with the QUANTUMTM algorithm and a
second-generation SinoGNSS ASIC chip, which greatly enhances
positioning reliability and stability, especially in obstacle-rich
environments. The receiver also has L-Band capability.
It features cutting-edge IMU tilt performance and offers
flexibility for field use. The receiver is powered by two 3400mAh
hot swap batteries, allowing for extended working hours. The smart
battery design enables fluent workflow in the field. Battery
shortage is indicated by flashing battery LEDs, and users can
easily replace the batteries or charge them directly in the N3 IMU
receiver using external power.
The N3 IMU GNSS Receiver is manufactured by ComNav Technology
Ltd., a company that holds the official trademark registered in the
People’s Republic of China, EU, USA, and Canada. Please note that
all other trademarks mentioned in this manual belong to their
respective owners.
Product Usage Instructions
To use the N3 IMU GNSS Receiver:
- Ensure that the receiver is placed in an open area with a clear
view of the sky for optimal signal reception. - Power on the receiver by pressing the power button.
- Wait for the receiver to initialize. The initialization time
may vary. - Once initialized, the receiver will start tracking signals from
GPS, BeiDou, GLONASS, Galileo, QZSS, IRNSS, and L-Band
constellations. - Monitor the battery status using the LED indicators. If the
battery LEDs flash, it indicates a battery shortage. - To replace the batteries, follow the instructions provided in
the user manual. - If needed, you can charge the batteries directly in the N3 IMU
receiver using external power.
For more detailed instructions and performance specifications,
please refer to the complete user manual provided with the
product.
N3 IMU GNSS Receiver
N Series GNSS Receiver
Ver.2022.01.30
7.3 cm
N3 IMU
GNSS Receiver
Size: 15.5 cm × 7.3 cm Weight: 1.2kg with two batteries
15.5 cm
Features
GPS L1/L2/L5, BeiDou B1/B2/B3, GLONASS L1/L2/L3, Galileo E1/E5a/E5b/ AltBOC/E6,SBAS, QZSS, IRNSS BeiDou Global Signal B1C, B2a, B2b WIFI/UHF/4G Module Built-in IMU supports tilt compensation up to 60° Two 3400 mAh hot swap Batteries Low Power Consumption Support PPP and L-Band
ULTRA-RELIABLE GNSS
SinoGNSS N3 IMU GNSS Receiver is an extremely compact designed receiver, tracking all current and planned Global GNSS constellations, as well as L-Band capability. With the QUANTUMTM algorithm and second generation SinoGNSS ASIC chip inside, it largely improves positioning reliability and stability, especially in obstacle environments.
CUTTING EDGE IMU TILT PERFORMANCE
Up to 60 ° tilting compensation, no need to center the Bubble, enables N3 IMU GNSS Receiver to measure quickly and acquire the precise position easily. With in-built IMU and adopted selfdeveloped core algorithm, the N3 IMU GNSS Receiver is free of magnetic interference and calibration, and can bring accurate and reliable coordinates. One-time adjustment for successive tilting measurement with centimeter-level accuracy increases work efficiency.
FLEXIBILITY FOR FIELD USE
Featuring full-constellation tracking capability, built-in IMU, 4G/WiFi/Bluetooth® connection, and easy survey workflow with Android-based Survey Master Software, the N3 IMU GNSS receiver is one of the most reliable choices for your demanding surveying tasks. Collect more accurate data easier and faster no matter for beginners or professional surveyors. The rugged Al-mg alloy housing with IP67 Dustproof & Waterproof design makes the N3 IMU receiver perfectly and effectively work even in harsh environments.
SMART BATTERY DESIGN
With two 3400mAh hot swap batteries, the N3 IMU GNSS Receiver helps to extend working hours and ensures you fluent workflow in the field. The battery LEDs flash when battery shortage, then you can replace batteries or directly charge in N3 IMU receiver through external power.
2020, ComNav Technology Ltd. All rights reserved.
is the official trade mark of ComNav Technology Ltd., registered in People’s Republic of China, EU, USA
and Canada. All other trademarks are the property of their respective owners. (November, 2020).
N3 IMU GNSS Receiver
N Series GNSS Receiver
Ver.2022.01.30
Signal Tracking
Channels GPS BeiDou BeiDou Global Signal GLONASS Galileo QZSS IRNSS L-Band
SBAS
1198 L1 C/A, L1C, L1P, L2C, L2P, L5 B1, B2, B3 B1C, B2a, B2b L1 C/A, L1P, L2 C/A, L2P, L3 E1, E5a, E5b, AltBOC, E6 L1 C/A, L1C, L2 C, L5, LEX L5 B2b WAAS, EGNOS, MSAS, GAGAN,SDCM
Performance Specifications
Cold start Warm start Hot start Initialization time Signal re-acquisition Initialization reliability Bridging of RTK outages
<50 s <30 s <15 s <10 s <1.5 s >99.9% RTK-KEEP, works up to 20 minutes
Positioning Specifications
Static and Fast Static
Long Observations Static
2.5 mm + 0.5 ppm Horizontal 5 mm + 0.5 ppm Vertical
2.5 mm + 0.1 ppm Horizontal 3.5 mm + 0.4 ppm Vertical
Real Time KINEMATIC(<30KM) NETWORK RTK DGPS SBAS Standalone
PPP
5 mm + 0.5 ppm Horizontal 10 mm + 0.5ppm Vertical
<0.4m RMS 1 m 3D RMS 1.5m 3D RMS
10cm Horizontal and 20cm Vertical
Communications
1 Serial port (7 pin Lemo)
Baud rates up to 921,600 bps
UHF modem1: Tx/Rx with full frequency range from 410-470 MHz2
902.4-928MHz Range: 15 km3
WIFI/4G modem 4G Bands: 800/900/1800/2100/2600 MHz 3G Bands: 900/2100 MHz 2G Bands: 900/1800 MHz Support GSM, Point to Point/Points and NTRIP
Position data output rates: 1 Hz, 2 Hz, 5 Hz, 10 Hz, 20 Hz
5 LEDs (indicating Power, Satellite Tracking, GPRS Status and Differential Data)
Bluetooth® : V 4.0 protocol, compatible with Windows OS and Android OS
Calibration-free IMU integrated for Tilt Survey
Up to 60°tilt with 2.5 cm accuracy
Data Format
Correction data I/O
Position data output
RTCM 2.x, 3.x formats, CMR(GPS only),CMR+(GPS only)
ASCII: NMEA-0183 GSV, RMC, HDT, VHD, GGA, GSA, ZDA, VTG, GST; PTNL, PJK; PTNL, AVR; PTNL, GGK
ComNav Binary update to 20 Hz
Physical
Size(L × W ) Weight
15.5 cm × 7.3 cm 1.2 kg with two batteries
Environmental
Operating temperature Storage temperature Humidity Waterproof and dustproof
Shock
-40 °C to + 65 °C -40 °C to + 85 °C 100% non-condensing IP67
protected from temporary immersion to depth of 1 m Designed to Survive a 2 m drop onto concrete
Electrical and Memory
Input voltage Power consumption Li-ion battery capacity Memory
5-27 VDC 1.7 W4 2 ×3400 mAh, up to 24hours typically 8 GB B and 32 GB optional5
Software
Survey Master Android-based data collection software MicroSurvey FieldGenius field data collection software (optional)
1. UHF modem is default configuration and it can be removed according to your specific needs.
2. IIntegrated UHF ranges from 410 to 470 MHz and optional 902.4-928 MHz. 3. Working distance of internal UHF varies in different environments, the
maximum distance is 15 Km in ideal situation. 4. Power consumption will increase if transmitting corrections via internal UHF. 5. 8GB is the default internal memory and optional 16GB, 32GB is available to
order. Please clarify when placing the order.
Specifications subject to change without notice.
