APAQ C130TC Programmable 2 Wire Transmitter for Thermocouple
Product Information
The APAQ C130TC is a programmable 2-wire transmitter designed
for thermocouple input. It is a low-cost, non-isolated device that
is easy to use and intended for industrial environments. The
transmitter can be configured using the INOR Connect app via NFC
communication. The app is available for free download on App Store,
Google Play Store, and Huawei AppGallery.
The transmitter supports various types of thermocouples
including type B, E, J, K, N, R, S, and T according to the IEC
60584 standard. It has a maximum input impedance of 10 MΩ and
provides cold junction compensation. The output is a temperature
linear 4-20 mA signal with upscale or downscale sensor failure
indication. The transmitter complies with NAMUR NE 43 standards and
offers adjustable filtering level and warm-up time.
The APAQ C130TC requires a mobile device with NFC communication
activated for configuration. The app allows users to customize
sensor type, measuring range, sensor error indication, filter
level, TAG number, and password. The configuration can be
transferred to the transmitter by holding the mobile device against
it until a green check box appears confirming the completion of the
transfer.
Product Usage Instructions
- Ensure that you have a mobile device with NFC communication
activated. - Download the INOR Connect app from App Store (for iOS) or
Google Play Store (for Android). - Launch the app by clicking on the App icon or holding your
mobile device against the transmitter where NFC is located (only
possible with Android). - Click on “Read Configuration” in the app and hold your mobile
device against the transmitter as explained in the first
section. - In the app, you can edit the following settings:
- Sensor type
- Measuring range
- Upscale or downscale sensor error indication
- Filter level
- TAG number
- Password
- Once you have set the desired values in the app, transfer the
configuration to the transmitter by clicking the transfer button
and holding the mobile device against the transmitter until a green
check box appears confirming the completion of the transfer.
USER INSTRUCTIONS
Programmable 2-wire Transmitter for Thermocouple
C130TC
The user instruction must be read prior to adjustment and/or installation. All information subject to change without notice. MEASURE OF SUCCESS
INOR Process AB, PO Box 9125, SE-200 39 Malmö, Sweden, Phone: +46 40 312 560, Fax: +46 40 312 570, E-mail: [email protected]
INOR Transmitter OY, Unikkotie 13, FI-01300 Vantaa, Finland, Phone:+358 10 421 7900, Fax: +358 10 421 7901, E-mail: [email protected]
INOR Transmitter GmbH, Am See 24, D-47279 Duisburg, Germany, Phone: +49-203 7382 762 0, Fax: +49-203 7382 762 2, E-mail: [email protected]
KROHNE Temperature Division INOR, 55 Cherry Hill Drive, Beverly, MA 01915, United States
Phone: +1 978 826 6900, Fax: +1 978 535 1720, E-mail: [email protected]
www.inor.com, www.inor.se
This product should not be mixed with other kind of scrap, after usage. It should be handled as an electronic/electric device. MEASURE OF SUCCESS
© INOR 10/2021 – 4008975501 – MA APAQ C130 TC R01 en
GENERAL INFORMATION
APAQ C130TC is a low cost, non-isolated, easy-to-use 2-wire transmitter, for thermocouple input, intended to be used in industrial environment.
The transmitter is configured from a mobile device via NFC communication, by using the app INOR Connect. Inor Connect is available for free download on App Store, Google Play Store and Huawei AppGallery.
DATA (short form)
Input
2-wire connection
TC type B – Pt30Rh-Pt6Rh (IEC 60584) TC type E – NiCr-CuNi (IEC 60584) TC type J – Fe-CuNi (IEC 60584) TC type K – NiCr-NiAl (IEC 60584) TC type N – NiCrSi-NiSi (IEC 60584) TC type R – Pt13Rh-Pt (IEC 60584) TC type S – Pt10Rh-Pt (IEC 60584) TC type T – Cu-CuNi (IEC 60584)
Input impedance Maximum wire loop resistance Cold Junction Compensation Output
Sensor failure indication
NAMUR Compliance
0…+1820 °C / +32…+3308 °F -270…+1000 °C / -454…+1832 °F -210…+1200 °C / -346…+2192 °F -270…+1300 °C / -454…+2372 °F -270…+1300 °C / -454…+2372 °F -50…+1750 °C / -58…+3182 °F
-50…+1750 °C / -58…+3182 °F -270…+400 °C / -454…+752 °F
10 M In-head transmitter (TC sensor): 5 k Internal or fixed 4-20 mA, temperature linear
Upscale (21.0 mA) or downscale (3.6 mA) Current limitations and failure currents acc.
Adjustable filtering level Warm-up time
Ambient temperature
to NAMUR NE 43 0.4 to 26 sec.
After a max. 20 minutes the accuracy specifications are reached (due to the internal cold junction)
Storage and operation Galvanic isolation Power supply Accuracy TC type B TC type R, S, T
-40 to +85 °C / -40 to +185 °F None 6 to 32 VDC
See Data Sheet Max. of ±2.0 °C or ±0.2% of span
TC type E, J, K
TC type N (-100…+1300 °C )
TC type N (-270…-100 °C ) CJC accuracy
Mounting Configuration
Max. of ±3.6 °F or ±0.2% of span Max. of ±1 °C or ±0.2% of span
Max. of ±1.8 °F or ±0.2% of span
Max. of ±1 °C or ±0.2% of span
Max. of ±1.8 °F or ±0.2% of span
±2.0 °C / ±3.6 °F Typical ±1 °C / ±1.8 °F (max ±3 °C / ±5.4 °F) within ambient temperature range
DIN B-head or larger App INOR Connect via NFCTM
Terminal RoHS, China RoHS
Factory settings Input Output Sensor error indication
Single/stranded wires: max 1.5 mm², max 0.5 Nm torque
Directive: 2011/65/EU and 2015/863/EU Harmonized standard: EN IEC 63000 China RoHS 2 Type K 0 to 1000 °C
4 to 20 mA Upscale
CONFIGURATION
Before making a configuration of APAQ C130TC you need to do following: Make sure that you have a mobile device with NFC communication activated. Download the app INOR Connect to your mobile device.
Required versions:
iOS: iOS 13 or later and Iphone 7 or later for NFC
Android: Android 4.4 or later
Configuration procedure: 1. Launch the app by clicking on the App icon or holding
your mobile device against the transmitter on the part
of the device where NFC is located (only possible with Android).
2. Click on “Read Configuration” and hold your mobile device against the transmitter as explained in the first section.
3. In the app you can edit the following: a. Sensor type b. Measuring range c. Upscale or downscale sensor error indication d. Filter level e. TAG-number f. Password
4. Once you have set the desired values in the app, you transfer it to the transmitter by clicking the transfer button and holding the mobile device against the transmitter until a green check box appears confirming that the transfer has been completed.
OUTPUT LOAD DIAGRAM
Maximum load depending on power supply Formula for the max. permissible output load for APAQ C130TC: RLoad =(U-6)/0.022
DIMENSIONS
DIN-rail Adapter
I NSTALLATION APAQ C130TC is designed to fit inside connection heads type DIN B or larger. The larger center hole, diameter 7 mm/0.28 inch, facilitates the pulling through of the sensor leads or an insert tube, greatly simplifying the mounting procedure.
! Connect input, output and power supply acc. to
“CONNECTIONS”. A convinient way to install the transmitter is to use the INOR mounting kits for in-head and DIN rail mounting. In order to minimize measuring errors make sure the connecting screws are tightened enough, 0.5-0.6 Nm.
MOUNTING How to mount on DIN-rail Adapter Step 1
Head mounting kit
53/2.08
Step 2
mm/inches
10/0.39
LIMITED WARRANTY
INOR Process AB, or any other affiliated company within the Inor Group (hereinafter jointly referred to as “Inor”), hereby warrants that the Product will be free from defects in materials or workmanship for a period of five (5) years from the date of delivery (“Limited Warranty”). This Limited Warranty is limited to repair or replacement at Inor’s option and is effective only for the first end-user of the Product. Upon receipt of a warranty claim, Inor shall respond within a reasonable time period as to its decision concerning:
1 Whether Inor acknowledges its responsibility for any asserted defect in materials or workmanship; and, if so,
2 the appropriate cause of action to be taken (i.e. whether a defective product should be replaced or repaired by Inor).
This Limited Warranty applies only if the Product: 1 is installed according to the instructions furnished by Inor; 2 is connected to a proper power supply; 3 is not misused or abused; and 4 there is no evidence of tampering, mishandling, neglect, accidental damage, modification or repair without the approval of Inor or damage done to the Product by anyone other than Inor.
This Limited Warranty is provided by Inor and contains the only express warranty provided. INOR SPECIFICALLY DISCLAIMS ANY EXPRESS WARRANTY NOT PROVIDED HEREIN AND ANY IMPLIED WARRANTY, GUARANTEE OR REPRESENTATION AS TO SUITABILITY FOR ANY PARTICULAR PURPOSE, PERFORMANCE, QUALITY AND ABSENCE OF ANY HIDDEN DEFECTS, AND ANY REMEDY FOR BREACH OF CONTRACT, WHICH BUT FOR THIS PROVISION, MIGHT ARISE BY IMPLICATION, OPERATION OF LAW, CUSTOM OF TRADE OR COURSE OF DEALING, INCLUDING IMPLIED WARRANTIES OF MER-CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. EXCEPT AS PROVIDED HEREIN, INOR FURTHER DISCLAIMS ANY RESPONSIBILITY FOR LOSSES, EXPENSES, INCONVENIENCES, SPECIAL, DIRECT, SECONDARY OR CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE OF THE PRODUCT.
Products that are covered by the Limited Warranty will either be repaired or replaced at the option of Inor. Customer pays freight to Inor, and Inor will pay the return freight by post or other “normal” way of transport. If any other type of return freight is requested, customer pays the whole return cost.
CONNECTIONS
Input Output
T/C
TC Connection
ORDERING INFORMATION
APAQ C130TC
Head mounting kit DIN-rail Adapter + Screw (10 pcs)
70C1300211 70ADA00017 70ADA00027
The transmitters are delivered with either a default factory setting or configured according to customer’s specification.
