3850 Thermoplastic Box with Card Guides and Cover

Product Information

The Model 3850 Thermoplastic Box With Card Guides & Cover is
a product designed for various applications. It has a compact size
and is made of thermoplastic material, making it durable and
lightweight. The box features card guides and a cover for added
protection.

Dimensions: 2.43″ (61.72mm) x 1.56″ (39.62mm) x 2.69″
(68.33mm)
Card Guide Thickness: 0.076″ (1.96mm)
Internal Height: 1.82″ (45.97mm)
Internal Width: 0.910″ (23.11mm)
Internal Depth: 0.07″ (1.78mm)
Wall Thickness: 0.080″ (2.03mm)
Cover Thickness: 0.072″ (1.83mm)
Card Guide Slot Width: 0.440″ (11.18mm)
Card Guide Slot Depth: 0.370″ (9.39mm)
Overall Height: 1.37″ (34.80mm)
Overall Width: 1.24″ (31.50mm)

The Model 3850 is available in different colors:

Model 3850-0 (Black)
Model 3850-6 (Blue)

Product Usage Instructions

Ensure that the Model 3850 is suitable for your intended
application.
Choose the desired color variant: Model 3850-0 (Black) or Model
3850-6 (Blue).
Identify the dimensions required for your project:

Internal Height: 1.82″ (45.97mm)
Internal Width: 0.910″ (23.11mm)
Internal Depth: 0.07″ (1.78mm)

Make sure the card guides and cover are included in the
package.

Assemble the product by following these steps:

Insert the cards or components into the card guides.
Place the cover over the card guides.

Ensure that all components fit securely and are properly
aligned.

If necessary, fasten the cover using appropriate screws or
fasteners.

Verify that the assembled Model 3850 meets your
requirements.

If you have any questions or need technical support, contact our
Technical Support team at [email protected] or call
Sales at 800-490-2361. For purchasing information, visit our
website at www.pomonaelectronics.com.

View Fullscreen

2.43″ (61,72mm)

Model 3850 Thermoplastic Box With Card Guides & Cover
.076″ (1,96mm)

1.56″ (39,62mm)

2.69″ (68,33mm)

1.82″ (45,97mm)

.910″ (23,11mm)

.07″ (1,78mm)

.080″ (2.03mm)

.072″ (1,83mm)
.440″ (11,18mm)
.370″ (9,39mm)

1.37″ (34,80mm)

1.24″ 31,50mm)

MATERIALS: Molded Housing and Cover: Glass filled nylon. Screws: Steel, 4 each, #2-32 x ¼, Pan Head, self-tapping
RATINGS: Operating Temperature: +216°F ( +102°C)
ORDERING INFORMATION: Model 3850-Color Model 3850-0 (Black) Model 3850-6 (Blue)

.060″ (1,53mm)

.036″ (,91mm)

All dimensions are in inches. Tolerances (except noted): .xx = ±.02″ (,51 mm), .xxx = ± .005″ (,127 mm). All specifications are to the latest revisions. Specifications are subject to change without notice. Registered trademarks are the property of their respective companies.
Sales: 800-490-2361 Fax: 425-446-5844 Technical Support: [email protected] For “Where to Buy” information, visit the Pomona web site at www.pomonaelectronics.com

Downloaded from Arrow.com.

Page 1 of 1
D1094121 Rev. 101
