36 Par Lights User Manual
Thank you for using our LED PAR light, For your safety, please read the User’s Manual carefully before operation.
Note: Please keep the manual for any unexpected requirements.
Please remove the power cord when you don’t use the light.
LCD Digital display function:
| Key-press | Mode | Description |
| [MENU] | Function | DMX control/colors selection/colors pulse/colors transition/sound control/amnual set |
| [UP] | Up | Increase values |
| [DOWN] | Down | Decrease values |
| [ENTER) | Enter | Confirmation button. After pressing this button, all setting values will be saved |
Operation Instructions
| MENU | Description |
| D001-D512 | DMX mode, change the numerical value by up and down |
| CCO1-CC64 | Colors selection, select different colors up and down |
| RBOI-RB16 | Colors shade, change speed by up and down, the bigger values, the faster |
| PLO 1-PL16 | Colors pulse transform, change speed by up and down, the bigger values, the faster |
| DOI-SD16 | Colors transition, change speed by up and down, the bigger values, the faster |
| FLO 1-FL 16 | Colors Strobe flash, change speed by up and down, the bigger values, the faster |
| Sound | Sound control mode |
| R000-R255 | Manual set R,Red color brightness setting,change brightness by up and down |
| 0000-G255 | Manual set G, Green color brightness setting, change the brightness by up and down |
| B000-B255 | Manual set B, Blue color brightness setting, change brightness by up and down |
DMX Control Parameter Chart
| Channels | Value | Function |
| CIII | 0-255 | Color brightness control(this change should use together with CH2,CH3 or CH4) |
| CH2 | 0 | Red light off |
| 1-255 | Red brightness from dark to bright | |
| CI-13 | 0 | Green light off |
| 1-255 | Green brightness from dark to bright | |
| CH4 | 0 | Blue light off |
| 1-255 | Blue brightness from dark to bright | |
| CH5 | 0-7 | No strobe flash |
| 8-255 | Strobe flash(from slow to fast), the bigger values, the faster | |
| CH6 | 0-10 | Manual control(CH1-CH5) |
| 11-60 | Colors selection(colors contorted by CH7) | |
| 61-110 | Colors shade(colors contorted by CH7), the bigger values, the faster | |
| 111-160 | Colors pulse transform(speed contorted by GH7)the bigger values, the faster | |
| 161-210 | Colors transition(speed contorted by CH7)the bigger values,the faster | |
| 211-255 | Sound control | |
| CI 17 | 0-255 | Colors selection/colors shade(the bigger values,the faster) |
