KEN-8304-BF Kendal Four Light Pendant
Product Information:
The Crystorama Lighting Fixture Model KEN-8304-BF is a
high-quality lighting fixture designed to provide illumination and
enhance the aesthetic appeal of any space. With over sixty years of
experience, Crystorama is a trusted brand in the lighting
industry.
This fixture features a durable metal frame, glass panels, and a
glass diffuser. It is designed to accommodate four medium base
bulbs with a recommended wattage of 60 watts (maximum 100 watts).
LED bulbs are recommended for extended use. The fixture is damp
rated, making it suitable for use in areas with high humidity.
It is important to note that all electrical components must be
installed by a licensed electrician in accordance with the National
Electric Code and the appropriate local electrical codes.
This product may contain Lead, which is known to the state of
California to cause cancer and/or birth defects or reproductive
harm. For more information, please visit www.P65Warnings.ca.gov.
Product Usage Instructions:
- Slide the glass diffuser onto the bottom of the metal frame and
secure it with clips. - Slide the glass panels inside the metal frame and secure them
with clips. - Slip the center rod assembly along the wire and thread it onto
the nipple located on the top of the light cluster. - Insert the hanging rod into the side holes of the top box on
the center rod and secure it from the top with screws. - Put the top metal ring over the metal frame. Line up the hole
on the bottom of the hanging rod with the hole on the top metal
ring and the bracket on the metal frame, and secure it with
screws. - Separate the mounting plate from the canopy kit by removing the
screws. - Install the mounting plate to the outlet box using two outlet
box screws. - Determine the preferred hanging height and adjust the required
rods. - Feed the wires through the rods and connect them together.
- Slip the canopy kit along the wire and thread it into the top
of the rod assembly. - Install the canopy onto the mounting plate and secure it with
the mounting screws. - Install the bulb (not included) into the socket.
Part Numbers:
- A. (1)-Mounting hardware
- B. (1)-Mounting plate
- C. (1)-Canopy kit W5-7/8”xH1” #XRF8303BFCAN5.875IN
- D. (2)-Mounting screw
- E. (1)-Rod D5/8”xL6” #XRF8303BFROD6IN
- F. (3)-Rod D5/8”xL12” #XRF8303BFROD12IN
- G. (1)-Coupler
- H. (4)-Screw
- I. (1)-Center rod assembly #XRF8304BFSTEM
- J. (4)-Hanging rod D3/8”xH12-1/8” #XRF8304BFSIDEROD
- K. (1)-Light cluster
- L. (1)-Top metal ring
- M. (4)-Glass panel
- N. (1)-Glass diffuser #XRF8304DIFF20.625IN
- O. (1)-Metal frame
- P. (4)-Screw
CRYST RAMA
LIGHTING THE WAY FOR SIXTY YEARS
ASSEMBLY INSTRUCTION MODEL#KEN-8304-BF
Crystorama.com
COUPLER
ROD
WARNING:
SCREW
Electrical Danger Turn Power off
LIGHT CLUSTER
CENTER ROD
HANGING ROD
SOCKET
TOP METAL RING
GLASS PANEL (4PCS)
CLIP
GLASS DIFFUSER BRACKET
CLIP SCREWS METAL FRAME
5-7/8”
ROD 1
1” ROD 1=
ROD 2
ROD 2=
1Pc
6″ 3Pcs
12″
All electrical components must be installed by a licensed electrician in accordance with the National Electric Code and the appropriate local electrical codes.
You will need 4-Medium Base Bulb
60 Watts Recommended 100 Watts Max.
USE LED BULBS FOR EXTENDED USE This fixture is Damp rated
How to install
1.Slide the glass diffuser onto the bottom of metal frame and secure it with clips.
2.Slide the glass panels inside the metal frame and secure it with clips.
3.Slip the center rod assembly along wire and thread onto the nipple located on the top of the light cluster.
4.Insert the hanging rod into the side holes of top box on the center rod, and secure the hanging rod from the top with the screws.
5.Put the top metal ring over the metal frame. Line up the hole on the bottom of hanging rod with the hole on the top metal ring and the bracket on the metal frame, and secure it with screws.
6.Separate the mounting plate from the canopy kit by removing the screws.
7.Install the mounting plate to the outlet box using two outlet box screws.
8.Determine the preferred hanging height and adjust the required rods.
9.Feed the wires through the rods and connect them together.
10.Slip canopy kit along wire and thread it into the top of the rod assembly.
11.Install canopy onto the mounting plate, and secure with the mounting screws.
12.Install the bulb(not included) into the socket.
15-1/4”
3-7/8” 3-1/8”
GLASS PANEL
62-1/2”
18-1/4”
20-5/8”
GLASS DIFFUSER
22-1/2”
WARNING: This product can expose you to Lead which is known to the state of California to cause cancer and/or birth defects or reproductive harm. For more information go to www.P65Warnings.ca.gov
A D
G
CRYST RAMA
LIGHTING THE WAY FOR SIXTY YEARS
ASSEMBLY INSTRUCTION MODEL#KEN-8304-BF
Crystorama.com
B C E
F
Part Number
Part Numbers A. (1)-Mounting hardware B. (1)-Mounting plate C. (1)-Canopy kit W5-7/8”xH1” #XRF8303BFCAN5.875IN D. (2)-Mounting screw E. (1)-Rod D5/8”xL6” #XRF8303BFROD6IN F. (3)-Rod D5/8”xL12” #XRF8303BFROD12IN G. (1)-Coupler H. (4)-Screw I. (1)-Center rod assembly #XRF8304BFSTEM J. (4)-Hanging rod D3/8”xH12-1/8” #XRF8304BFSIDEROD K. (1)-Light cluster L. (1)-Top metal ring M. (4)-Glass panel N. (1)-Glass diffuser #XRF8304DIFF20.625IN O. (1)-Metal frame P. (4)-Screw
H
J
I K
L
M
N O P
