ASTM F963 Battery Ride On Bubble Scooter
Product Information
The H-Bub eScooter 07-06-22 m0597 AU is a battery-powered
ride-on bubble scooter. It comes with an owner’s manual that
contains important safety, assembly, operation, and maintenance
information. The product is covered by a limited warranty that
covers defects in workmanship and materials for all parts of the
product.
Safety and Warnings
Always wear an approved helmet and safety equipment when using
this product. The user manual that comes with your helmet should be
read to ensure it is fitted and attached properly to the wearer’s
head according to the fitting instructions described in the user
manual. Before using the unit for the first time, the battery needs
to be charged for at least 8 to 12 hours but no more than 20 hours.
Only an adult who has read and understands the safety warnings
should handle, charge or recharge the battery (see Maintenance).
The product should not be used for any other purposes than what is
described in the manual.
Assembly
The assembly instructions can be found on the following website:
https://www.huffybikes.com/global-contacts/.
If you need further assembly help, contact customer service.
Operation
Please read and fully understand the owner’s manual before
operating the product. Always wear an approved helmet and safety
equipment when using this product.
Maintenance and Repair
Regular maintenance is required to keep the product in good
condition. Please refer to the owner’s manual for maintenance
instructions. If you encounter any issues with the product, contact
customer service.
Troubleshooting
If you encounter any issues with the product, refer to the
troubleshooting section of the owner’s manual for help. If you are
unable to resolve the issue, contact customer service.
Warranty
The product is covered by a limited warranty that covers defects
in workmanship and materials for all parts of the product. The
warranty extends only to the original consumer and is not
transferable to anyone else. Warranty registration is not
required.
Contact Information
If you encounter any issues with the product or need further
assistance, contact customer service at the following:
Hunter Products Pty Ltd
Phone: 1800 224 094
Email: [email protected]
Address: 233 Bay Street, Brighton Victoria, 3186, Australia
For warranty claims or reporting a problem with the product,
contact customer service.
Date Code Label: AU
Owner’s Manual Index:
Safety
Assembly
Operation
Maintenance Repair and Service
Troubleshooting (pages 16-17)
Warranty
Contact Information (Back Cover)
WARNING: Always wear your helmet when riding this product!
ATTENTION!
For Any Issues with this Product, Contact Customer Service.
We are glad to assist you with any parts or assembly problems you might have!
For Any Issues with this Product, Contact Customer Service.
Hunter Products Pty Ltd Phone: 1800 224 094
233 Bay Street, Brighton Victoria, 3186, Australia
Email: [email protected]
ALWAYS WEAR YOUR HELMET WHEN RIDING THIS PRODUCT!
Always read the user manual that comes with your helmet to make sure it is fitted and
attached properly to the wearer’s head according to the fitting instructions described in the
user manual.
For ASSEMBLY Help:
https://www.huffybikes.com/ global-contacts/
Please REGISTER your Product: for current contact information
https://www.huffybikes.com/global-contacts/
H-Bub eScooter 07-06-22 m0597 AU
Date Code Label
AU
Here
Owner’s Manual
Battery Ride-On Bubble Scooter
© Copyright Huffy Corporation 2022
This manual contains important safety, assembly, operation and maintenance information. Please read and fully understand this manual before operation. Save this manual for future reference.
Always wear approved helmet and safety equipment when using this product.
See back page for Customer Service Information
Owner’s Manual Index
Safety
· User and Battery Warnings…………………………………………………………………………………..3-4 · Radio Frequency ……………………………………………………………………………………………………..4 · Charging Drive Motor Warnings……………………………………………………………………………5
Assembly
· Parts Assembly……………………………………………………………………………………………………….6-7 · Introduction to Assembly and Tools Needed ……………………………………………………..8 · Charging Port Location…………………………………………………………………………………………..8 · Vehicle Assembly ………………………………………………………………………………………………….9-11
Operation
· How to Operate your Vehicle………………………………………………………………………………….12
Maintenance Repair and Service
· General …………………………………………………………………………………………………………………….13 · Battery Replacement, Storage and Disposal………………………………………………………14 · Drive Motor and Battery Fuse ………………………………………………………………………………15 · Battery Recharge Time…………………………………………………………………………………………..15
Troubleshooting ………………………………………………………………………………………. 16-17
Warranty
· Limited Warranty…………………………………………………………………………………………………….18
Contact Information………………………………………………………………………………………… Back Cover
WARNING:
· CHOKING HAZARD: Small parts. Not for children under 3 years. Keep small children away when assembling.
· To reduce the risk of injury, adult supervision is required. · Never use in roadways, near motor vehicles, on or near steep inclines or steps, swimming
pools or other bodies of water; always wear shoes, and never allow more than one rider. · Protective equipment should be worn. · The user must be 3-5 years. Not for children with a body mass more than 44 lbs (20 kgs).
IMPORTANT! Before using the unit for the first time the battery needs to be charged for at least 8 to 12 hours – no more than 20 hours. Only an adult who has read and understands the safety warnings should handle, charge or recharge the battery (see Maintenance).
Warranty Safety and Warnings
Limited Warranty (Australia)
General:
· Ridden by more than one person at a time
Part or model specifications are subject to change · Rented, sold, or given away
without notice.
· Used in a manner contrary to the instructions
This Limited Warranty is the only warranty for the and warnings in this Owner’s Manual
product. ALL WARRANTIES OTHER THAN STATED What will The Manufacturer do?
HEREIN ARE DISCLAIMED INCLUDING IMPLIED Manufacturer’s sole and exclusive obligation
WARRANTIES OF MERCHANTABILITY AND
under this Limited Warranty is to repair and/or
FITNESS FOR A PARTICULAR PURPOSE, TO THE replace, at its sole option, any covered defect in
EXTENT ALLOWABLE BY APPLICABLE LAW. ALL workmanship or materials.
LIABILITY FOR INCIDENTAL, PUNITIVE, SPECIAL, How do you report a problem with this
OR CONSEQUENTIAL DAMAGES ARE EXPRESSLY product or submit a warranty claim?
DISCLAIMED, TO THE EXTENT ALLOWABLE BY · Contact Customer Service in Australia or New
APPLICABLE LAW.
Zealand (See included list for Customer Contact
The only uses for this product are described in this information).
manual.
· Warranty claims can be submitted to;
Warranty registration is not required.
Hunter Products Pty Ltd – PH: 1800 224 094
The Limited Warranty extends only to the original Email: [email protected] – Level
consumer and is not transferable to anyone else. 2, 424 Warrigal Road, Moorabbin, Victoria 3189
What does this Limited Warranty cover?
Australia.
This Limited Warranty covers defects in
The following text is incorporated into this Limited
workmanship and materials for all parts of the Warranty if this product was purchased in Australia
product except those indicated below as not
(but it is not incorporated if such product was
warranted.
purchased in New Zealand):
What must you do to keep the Limited
· Our goods come with guarantees that cannot
Warranty in effect?
be excluded under the Australian Consumer
This Limited Warranty is effective only if:
Law. You are entitled to a replacement or
· Product is completely and correctly assembled. refund for a major failure and for compensation
· Product is used under normal conditions for its for any other reasonably foreseeable loss or
intended purpose (see the following section for damage. You are also entitled to have the
excluded activities).
goods repaired or replaced if the goods fail to
· Product receives all necessary maintenance and be of acceptable quality and the failure does
adjustments.
not amount to a major failure.
· Product is used for general transportation and What rights do you have?
recreational use only.
This Limited Warranty gives you specific legal
What is not covered by this Limited
rights. You may also have other rights which vary
Warranty?
from State to State.
This product is designed for recreational use only. For how long does this Limited Warranty
This Limited Warranty does not cover normal
last?
wear and tear, normal maintenance items, or any · When used in this Limited Warranty, the phrase
damage, failure, or loss that is caused by improper “for life” means for as long as the original con-
assembly, maintenance, adjustment, storage, or
sumer owns the product.
use of the product. This Limited Warranty does not · Drive Battery – 90 days
extend to future performance.
· Electronics – 90 days
This Limited Warranty will be void if the · All other Components – 6 months
product is ever:
· Used in any competitive sport
· Used for stunt riding, jumping, aerobatics or
similar activity
18 · Modified in any way
· Modified with the addition of a motor
WARNING: TO AVOID SERIOUS INJURY:
· It is the responsibility of the adult to educate Never place a body part near a moving
the child and determine if they are capable of part or wear loose clothing while using the
operating the vehicle safely.
vehicle.
· Before using the vehicle the child must
· Always use vehicle in a safe, secure environ-
understand the controls and safety issues.
ment on flat, smooth paved surfaces only.
They must also demonstrate the capability · Do not use the vehicle in an unsafe man-
and skill to handle the vehicle and operate its ner or at an unsafe speed.
controls to avoid falls or collisions.
Examples include but are not limited to:
· After complete assembly, remove and dis-
· Do not pull or push the vehicle with an-
pose of all protective material and poly bags. other vehicle or similar device.
Keep poly bags away from child. Be sure to · Do not tow anything behind the vehicle.
remove all packaging materials and parts
· Do not drive into fixed objects, which may
from underneath the vehicle body.
cause the wheels to spin, causing the mo-
· Ensure child uses common sense and safe
tor to overheat.
practices when using the vehicle.
· Never use near streets, water, swimming
· All of these safety rules and guidelines
pools, hills, steps, drop-offs, sloped sur-
must be followed or serious injury or
faces or driveways, wet areas, flammable
death may occur to the user:
vapors, in alleys, at night or in the dark.
· Adult assembly required. Choking hazard · Do not use the vehicle in unsafe conditions
to children under the age of 3 years – con-
such as snow, rain, loose dirt, mud sand or
tains small parts. Keep small children away
fine gravel. This may result in unexpected
when assembling.
action such as tip over and skidding. Using
· To reduce the risk of injury, adult supervi-
the vehicle in loose dirt, mud, sand, or fine
sion is required. Never use in roadways,
gravel may damage the electronics and
near motor vehicles, on or near steep
gear box inside the vehicle.
inclines or steps, swimming pools or other · Vehicle Cautions: Do not overload the
bodies of water; always wear shoes, and vehicle. Do not drive in very hot weather,
never allow more than one (1) rider.
components may overheat. Do not allow wa-
· RISK OF FIRE. Do not bypass fuse. Replace ter or other liquids to come in contact with
only with size and type.
the battery or other electric components. Do
· Continuous adult supervision required while not tamper with the electrical system. Doing
using the vehicle.
so may create a short, causing the fuse to trip
· Protective Equipment must be worn: Always wear safety equipment such as a helmet that meets CPSC (or equivalent standard for your country) with chinstrap securely fastened, knee pads, elbow pads,
or other damage including fire. ·· TThHeIrSe VarEeHadICdLitEionHaAl hSazNaOrdBs oRfAuKsinEg. tWhehen
veenhgiaclgeeidn,amreoatsoor tfhriecrtitohnanwpillrigvraatedugarolluynsdtos.p · Fthoeotu/nFiet.nder Brake can become hot after
use. Do Not touch with hand.
wrist guards, gloves and shoes.
· Body parts such as hands, legs, hair and
clothing can get caught in moving parts.
This product meets ASTM F963 and CPSIA requirements for electric vehicles.
3
Safety & Warnings Troubleshooting
Helmet Warning Information
ALWAYS WEAR YOUR HELMET WHEN RIDING THIS PRODUCT!
Always read the user manual that comes with your helmet to make sure it is fitted and attached properly to the wearer’s head according to the fitting instructions described in the user manual.
Troubleshooting Guide – continued
BEFORE YOU CALL SUPPORT:
1. What is the model and date code? 2. When was the product purchased? 3. Has the product ever worked for a time or has never worked at all since purchase?
· Yes, When did the product last operate correctly? · No, were the battery wires connected? 4. How long was the battery charged? 5. Is the charger plugged into the unit when you try to operate the product? · (The unit will not operate with charger plugged in) 6. Do any lights or sounds come on when you power the product on? · Yes, Does the lights and sounds go away when you press the drive switch? 7. When you press the drive switch, does an electric motor start? · Yes, Did you check that the correct drive wheel was installed? · Yes, Does the insert in the gearbox rotate?
Radio Frequency Information (if applicable)
CAUTION: Changes or modifications to and used in accordance with the instructions,
this unit not expressly approved by the party may cause harmful interference to radio
responsible for compliance could void the communications.
user’s authority to operate the equipment. However, there is no guarantee that
This device complies with Part 15 of the FCC interference will not occur in a particular
Rules. Operation is subject to the following installation. If this equipment does cause
two conditions:
harmful interference to radio or television
(1) this device may not cause harmful
reception, which can be determined by
interference, and (2) this device must
turning the equipment off and on, the user is
accept any interference received, including encouraged to try to correct the interference
interference that may cause undesired
by one or more of the following measures:
operation.
· Reorient or relocate the receiving antenna.
NOTE: This equipment has been tested and · Increase the separation between the equip-
found to comply with the limits for a Class B ment and receiver.
digital device, pursuant to Part 15 of the FCC · Connect the equipment into an outlet on
Rules. These limits are designed to provide a circuit different from that to which the
reasonable protection against harmful
receiver is connected.
interference in a residential installation. This · Consult the dealer or an experienced radio/
equipment generates, uses and can radiate TV technician for help.
radio frequency energy and, if not installed
4
Troubleshooting Bubble Blower:
Problem
Possible Cause
Solution
Not producing Bubbles:
Power Switch OFF Bubble Solution empty
Ensure Power Switch is ON Fill Bubble Solution Tray
Bubble Outlet clogged
Clean Outlet with water and cotton swab
Run clear water through Bubble Solution Tray until system is clean.
Bubble Motor not run- Contact Customer Service. ning.
SEE OPERATION SECTION FOR OPERATING INSTRUCTIONS
17
Troubleshooting Safety & Warnings
Troubleshooting Guide
The following are examples of potential problems. Completely read through this manual and the troubleshooting guide table before calling. If you still need help resolving the problem please contact Customer Service.
NOTE: Vehicle should be turned off and fully charged before doing troubleshooting.
Problem
Possible Cause
Solution
Vehicle does not run when switch is activated
Battery wires not connected or are loose
Connect battery wires according to assembly instructions, Check that the battery connectors are firmly plugged into each other. If wires are loose around the motor call Customer Service.
Battery low on power
Recharge battery (see Battery: Recharge interval and time)
Battery Charger still plugged Unplug Battery Charger from unit and wall in
Thermal fuse has tripped Let Fuse reset
Battery is dead
Replace battery (see Battery: Replacement and Disposal)
Electrical system or motor is Call Customer Service. damaged
Vehicle does not run Battery is undercharged. very long or runs sluggishly
Check that the battery connectors are firmly plugged into each other when recharging (see Battery: Recharge interval and Time)
Battery is old and cannot be Replace battery (see Battery: Replacement
fully charged
and Disposal)
Vehicle is overloaded
Reduce weight on vehicle (see user requirements and Safety Warnings)
Vehicle is being used in harsh conditions
Avoid using vehicle in harsh conditions (see User Requirements and Safety Warnings)
Vehicle makes loud noise when in use
Chain is dry (on chain drive Lubricate chain with light oil. models)
Loud grinding or clicking noises coming from motor or gear box
Motor or gears are damaged
Drive Wheel is partially engaged
Call Customer Service. Check drive wheel – to motor engagement.
Battery will not recharge
Battery connector or
Check that the battery connectors are
adapter connector is loose firmly plugged into each other.
Charger is not working
Check that the battery charger is plugged into a working wall outlet.
Battery is dead
Replace battery.
Charger feels warm when recharging 16
This is normal and not a cause for concern
If excessively hot, unplug and replace.
BATTERY & CHARGER WARNINGS:
The following safety hazards may result in serious injury or death to the user of the vehicle:
· Only allow children at least 8 years old to use the battery charger. Give sufficient instruction so that the child is able to use the battery charger in a safe way and explain that it is not a toy and must not be played with.
· Battery Charger for Indoor use only. · Use of a battery or charger other than the supplied rechargeable battery and charger
may cause a fire or explosion. Only use the supplied rechargeable battery (or lead-acid or lithium suitable replacement) and charger with the vehicle. · Using the rechargeable battery and charger for any other product may result in overheating, fire or explosion. Never use the rechargeable battery and charger with another product. · Explosive gases are created during charging. Charge the battery in a well ventilated area. Do not charge the battery near heat or flammable materials. · Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact between the terminals. Picking up the battery by the wires or charger can cause damage to the battery and may result in a fire. Always pick up the battery by its case or handles. · Battery must be handled by adults only. Liquids on the battery may cause fire or electric shock. Always keep all liquids away from the battery and keep the battery dry. · Contact or exposure to battery leakage (lead acid) may cause serious injury. If contact or
exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes, flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water or milk. Do not give water or milk if the patient is vomiting or has a decreased level of alertness. Do not induce vomiting. · Battery Posts, terminals and related accessories contain lead and lead compounds (acid), chemicals known to cause cancer, reproductive harm and are toxic and corrosive. Never open the battery. · Tampering or modifying the electric circuit system may case a shock, fire or explosion and permanently damage the system. Exposed wiring and circuitry in the charger may cause electric shock. Always keep the charger housing closed. · Children should be instructed not to try and recharge non-rechargeable batteries because of the danger of eruption. · Batteries are to be inserted with the correct polarity. · The supply terminals are not to be short-circuited. · The battery chargers used are to be regularly examined for damage, especially the cord, plug, enclosure and other parts. In the event of such damage, they must not be used until the damage has been repaired. · Do not mix old and new batteries. · Do not mix alkaline, standard (Carbon-Zinc) or rechargeable batteries. · Non-Drive rechargeable batteries are to be removed from the unit before being charged.
5
NOTE: All features, components and accessories are not included on all models.
14 15 17 19
Parts View
1 20
2 34
Parts View
6
18 16
14 15
5
6
11
9
12
7
10 13
8
Drive Motor Battery
Only an adult who has read and understands the safety warnings should handle, charge or recharge the battery. Failure to comply with all safety warnings may result in serious injury or death.
Battery Fuse
The drive motor circuit features a thermal fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded. The fuse will reset and power will be restored after a short time. If the thermal fuse trips repeatedly during normal use, the vehicle may need repair.
WARNING:DO NOT BYPASS THE FUSE – RISK OF FIRE. This may overload
and damage the electrical system.
Battery Re-charge Interval and Time IMPORTANT!
Check the drive battery and charger (supply cord, connector) for wear and damage before charging. Do not charge the battery if damage has occurred. Only replace with the same type and voltage rechargeable battery and charger supplied by the manufacturer. · Only use the rechargeable battery (or equivalent replacement) and charger supplied with
your vehicle. · Before first use, charge battery 8 to 12 hours – never longer than 20 hours. · Once battery is depleted, recharge for 8 to 12 hours – never longer than 20 hours. · Do not short circuit the battery: Do NOT connect red and black wires together or connect
positive and negative terminals on the battery together. · When battery is fully charged, un-plug charger from the wall outlet and disconnect from
charger port. The drive battery should be charged when depleted, or if not used regularly, once a month. Failure to charge the battery as directed will cause permanent damage to the battery and will void the warranty.
15
Maintenance
Parts List
Maintenance
· with motor and Bubble blower
19 Body/Frame Assembly
20 Charger
18 Rear Axle
17 Left Drive Wheel
16 Right Rear Wheel (non-drive)
15 Washer (x2)
14 Locknut (x2)
13 Battery Cover w/Screws
Drive Battery Replacement: STEPS:
1. Turn Scooter on it’s Side.
2. Remove the Battery Cover
B and Screws .
3. Remove the Battery Bracket
C and Screws .
A
4. Disconnect the Red and Black
D
D Battery Terminals .
5. Carefully remove the Battery.
· Depending on the condition
of the battery (leakage or damage) you may want to
C
wear protective rubber gloves
before removal.
· Do not lift the battery by its
connectors or cables.
6. Place the dead battery in a
B
plastic bag.
7. Install replacement battery
and reconnect the connectors: Red to Red Terminal, Black to Black Terminal.
C 8. Replace the battery bracket . B 9. Replace the Battery Cover .
NOTE: The Thermal Fuse is attached to the red power wire and resets if Battery is overloaded.
Battery Storage and Disposal
The drive battery should be charged when
be recycled or disposed of in an
depleted, or if not used regularly, once a
environmentally sound manner.
month. Failure to charge the battery as
· Do not dispose of battery in a fire. The
directed will cause permanent damage to the battery may explode or leak acid.
battery and will void the warranty.
· Do not dispose of the battery in household
Follow these guidelines if the battery is
trash. The incineration, land filling or
removed:
mixing of sealed lead-acid batteries with
· Do not store battery in extreme hot or cold household trash is prohibited by law.
temperatures.
· Return an exhausted battery to a federal
· Wipe the battery clean with a dry cloth
or state approved lead-acid battery
prior to storage. Wash cloth separate from recycler, such as a local seller of automotive
other clothes.
batteries (check local battery disposal
BATTERY DISPOSAL:
regulations).
· The sealed lead-acid battery must
Description
#
Description
11 Battery
Parts List
12 Battery Brace
10 Front Wheel
7 Fork Threaded Screw Set
6 Axle Threaded Screw Set
5 Head Set bushings
4 Handlebar Clamp w/Hardware
3 Head Cover w/Screws
2 Handlebar Assembly
9 Fender
8 Fork
1 Grips (x2)
#
14
7
Assembly Maintenance
Introduction to Assembly
This Owner’s Manual may be made for several different style products. · Some illustrations may vary slightly from the actual product. · Follow instructions completely. · If the product has any parts that are not described in this manual, look for separate “Special Instructions” that are supplied with the unit. · All features, components and accessories are not included on all models. · Use the Index page to locate specific sections of this manual. · Please read through this entire manual before beginning assembly or maintenance. · If you are not confident with assembling this unit, contact customer service.
WARNING: Keep small parts away from children during assembly.
NOTE: All of the directions (right, left, front, rear, etc.) in this manual are as seen by the rider while seated.
Do not dispose of the carton and packaging until you complete the assembly of the product. This can prevent accidentally discarding parts of the unit.
Tools Needed (supplied)
Allen/Phillips Wrenches
CHARGING PORT LOCATION:
A NOTE: Charging Port is located on the
front LEFT side of the deck, next to the
B Bubble ON/OFF switch .
T-Axle Wrenches (x2)
A
B
8
Maintenance Repair and Service
GENERAL: The vehicle should be checked · Check the tightness of the wheels:
for damage, missing or badly worn parts
NOTE: If the drive wheel is not tight, it will not
before each use. If any part of the product engage the gears and the vehicle will not run.
does not operate properly discontinue use. · Ensure the battery bracket is securely in place
· Check the tightness of the fasteners before
before use.
each use. Replace any fasteners that are
· Prolonged exposure to UV-rays, rain, and
damaged.
outdoor elements may damage the enclosure
· Inspect the product frequently. Failure to
materials. Store the vehicle indoors when
inspect the product and to make repairs
not in use. Keep it away from sources of heat,
or adjustments, as necessary, can result in
such as stoves and heaters.
injury to the rider or to others. Make sure all · Keep the product clean and free of dirt, dust
parts are correctly assembled and adjusted and water. This will prolong the useful life of
as written in this manual and any “Special
the product.
Instructions”.
· Clean the vehicle with a soft, dry cloth. To
· Immediately replace any damaged, missing, restore shine to plastic parts, use a non-wax
or badly worn parts.
furniture polish. Do not use automotive wax,
· Make sure all fasteners are correctly tightened abrasive cleaners or wash the vehicle with
as written in this manual and any “Special
soap and water.
Instructions”. Parts that are not tight enough NOTE: If the instructions in this manual or any
can be lost or operate poorly. Over tightened “Special Instructions” are not sufficient for
parts can be damaged. Make sure any
you, please contact customer service.
replacement fasteners are the correct size and CAUTION: Self-locking nuts and other self-
type.
locking devices may lose their effectiveness
when re-used.
Torque Table – Recommended Torque:
Use of a torque wrench is recommended. owner’s manual) on each component as it is
Recommended torque for each fastener is tightened.
listed below. In addition to tightening to
the recommended torque, please ensure
NOTE: Please check that all fasteners on the
the parts of the product are sufficiently
product are torqued according to the table
tightened by performing the functional tests below:
(in the component assembly sections of the
Recommended Torque for clean, dry threads:
How to Measure:
Fastener Size
Torque (ft-lb / N·m)
Screw or bolt size is determined by the width at the THREADS as shown.
.157 in (4 mm)
3.1 ft-lbs (4.2 N·m)
.196 in (5 mm)
5 ft-lbs (6.8 N·m)
.236 in (6 mm)
7 ft-lb (9.5 N·m)
.275 in (7 mm)
12 ft-lbs (16.3 N·m)
.314 in (8 mm)
17 ft-lbs (23 N·m)
.393 in (10 mm)
33 ft-lbs (44.7 N·m)
13
Operation Assembly
Operation:
USAGE: · Turn ON Scooter power by holding down Power
A Button . Release Power Button to stop. B · Push Motor Engage-Lever DOWN to engage
motor and UP to disengage motor.
NOTE: Disengaging Motor allows scooter to be selfpropelled.
A TO USE BUBBLE MAKER:
CAUTION: Fill ONLY with solution designated on the product:
C · Pull out Fill Tray as shown (Drawer is not
removable), to fill with Bubble solution. Do Not Overfill.
D · Turn Switch ON to activate Bubble feature A when pressing Power Button . E is Bubble outlet – Keep clean and free of debris.
NOTE: With Motor disengaged, Bubble feature will
D continue to function if Switch is turned ON.
D
E
C
Installing Rear Wheels:
A
DCE F
BCD
STEPS:
A 1. Insert Rear Axle through Body as shown. B C D 2. Install right rear Wheel , one Washer and one Locknut onto Axle. E F 3. Install Drive Wheel onto Axle so that Drive Gear fits into Drive Motor. C D 4. Install Washer and Locknut .
5. Tighten both Locknuts fully and securely.
B
WARNING: Both hands must firmly grip the handlebar before pushing Power A 12 Button . Failure to follow this rule can result in personal injury or damage to the product.
9 SEE TORQUE TABLE FOR RECOMMENDED TORQUE
Assembly Assembly
Assembling the Front Wheel and Handlebar:
STEPS:
1. Ensure Power Button A and
B Wiring Connector are
facing BACK.
C 2. Insert Steering Rod down
through Neck frame.
3. Ensure top and bottom Neck
C
A
D Bushings are fully inserted
into Neck frame and sit fully in
Notches E.
F 4. Place Fender over Fork
B
G Assembly .
5. Insert this Fork Assembly up
C onto Steering Rod fully so
I
that Fork mounting holes line
up.
H 6. Install Fork Screw Set
D
through Fork assembly and
Steering Rod. Tighten securely.
7. With Front Wheel on the
I ground, tighten Clamp
securely.
E
NOTE: Ensure there is approx. 1/16″ (1.5mm) gap between
H
I D Clamp and top Bushing as
shown in view J.
NOTE: Ensure Handlebar turns
freely from left to right until it hits
the turn stops.
F
I
SEE TORQUE TABLE FOR RECOMMENDED TORQUE
G
10
1/16″
(1.5mm)
J
D
PROCEED TO NEXT STEP >>
Handlebar Connectors and Clamp Cover Assembly:
E A
D
B C
D STEPS: (TIP: Hand start screws before assembly) A 1. Connect Power Plugs firmly and completely. B 2. Tuck excess wire into Wire Slots – Check that Handlebar and fork turn fully from
left to right and that Wires are not pinched or stretched.
C 3. Place Clamp Covers around Steering Tube Clamp
NOTE: Ensure Clamp Supports fit INSIDE Clamp gap as shown in view E.
D 4. Install 4 Screws securely – Ensure Connector Wires are not pinched.
NOTE: Make sure Handlebar and Fork turn easily and completely from left to right.
11
ybikes.com/
