SP1000 Ambient CO2 Smart Probe
Product Information: SP1000 Ambient CO2 Smart Probe
The SP1000 Ambient CO2 Smart Probe is a product from Test
Products International, Inc. It uses NDIR CO2 sensor for accuracy,
and can connect to a smartphone using the TPI Smart Probe App or
TPI View app. The SP1000 is designed to perform ambient CO2 level
checks, and up to 6 smart probes can connect to a single mobile
device (most devices). The product comes with a 3-year limited
warranty.
Product Usage Instructions
Thank you for purchasing the SP1000 Ambient CO2 Smart Probe.
Below are the usage instructions:
- Download either the SmartProbe or the View app from either the
Apple App Store or the Google Play Store. - Ensure that the SP1000 is not attached to a hot surface or
exposed to damp environments for extended periods of time. - Press and hold the power key to turn on the instrument.
- The orange blinking LED indicator means Bluetooth is not
connected, green blinking LED indicates Bluetooth is connected, and
blinking red with either of the above indicates low battery. - The sensing area should be used to measure ambient CO2
levels. - Ensure that you do not breath directly into the SP1000 while
performing measurement checks as doing so will skew the actual
ambient air reading results. - To maintain the product, clean the surface of the instrument
with a damp cloth and replace the three AAA batteries when the low
battery indicator appears.
For troubleshooting, if CO2 seems inaccurate, ensure that the
device is working. If the SP1000 does not turn on, replace
batteries or contact customer support.
For warranty information, the product is warranted to the
purchaser against defects in material and workmanship for three
years from the date of purchase.
For more information, visit www.tpieurope.com.
SP1000 Ambient CO2 Smart Probe
Test Products International, Inc.
Uses NDIR CO2 sensor for accuracy Connects to smart phone and uses the TPI Smart Probe App or the TPI View app Perform ambient CO2 level checks Up to 6 SP1000 smart probes can connect to a single mobile device (most devices) 3 Year Limited Warranty
Test the TPI Advantage
Visit www.tpieurope.com
TABLEOFCONTENTS
A. Introduction………………………………………………………………………………….. 1 B. Safety Considerations…………………………………………………………………… 1 C. Specifications………………………………………………………………………………. 2 D. Instrument Overview…………………………………………………………………….. 3 E. Maintenance………………………………………………………………………………… 4 F. Trouble Shooting…………………………………………………………………………… 4 G. Accessories…………………………………………………………………………………. 4 H. Warranty……………………………………………………………………………………… 5 I. Replacing Batteries………………………………………………………………………… 5
A. INTRODUCTION
1. Congratulations: Thank you for purchasing TPI products. The SP1000 is easy to use and built to last. It is backed by a 3 year limited warranty.
2. Product Description: The SP100 is an Ambient CO2 IAQ “Smart Probe”. It connects to your mobile device and uses the TPI Smart Probe App or TPI View App to display ambient CO2 readings. Data can be displayed, saved, logged, allocated to a specific job, exported & e-mailed in either pdf or csv depending on which app the SP1000 is connected to.
3. Download either the SmartProbe or the View app from either the Apple App Store or the Google Play Store
SmartProbes App
View App
B. SAFETY CONSIDERATIONS
1. Never attach the SP1000 to a hot surface. 2. Never breath directly into the SP1000 while performing
measurement checks as doing so will skew the actual ambient air reading results. 3. Do not expose the unit to damp environments for extended periods of time.
1
C. SPECIFICATIONS
SP1000 Smart Probe Ambient Air CO2 Meter Specifications
Range
0 to 6,000 ppm
Resolution
1 ppm
Unit
ppm
Accuracy
+/- (50ppm+3% of measurement) at (0 to 5,000ppm Range) +/- (100ppm+7% of measurement) at (5,000 to 6,000ppm Range)
Operating Temperature -20C to 50C (-4F to 122F)
Storage Temperature
-20C to 60C (-4F to 140F)
Measurement Interval Communication Battery Type
2 seconds
Bluetooth version 4.2 (Use with TPI Smart Probe or View app) FCC ID: QOQBDM113 IC: 5123A-GBM113
209-J00204
AAA x 3 (4.5V)
Battery Life
30 hours typical
Weight
99.5 g (3.5 oz)
D. INSTRUMENTOVERVIEW
1. Sensing area. 2. SP1000 status LED indicator.
Orange and blinking = Bluetooth not connected Green and blinking = Bluetooth connected Blinking Red with either of the above = Low battery 3. Power Key. Press and hold to turn the instrument on. Press and hold to turn the instrument off.
4. Built-in magnet. Attach to metal surfaces for hands free operation. Ensure surface is not hot.
5. Serial number location. Last three digits are the product identification number and marked in bold. Use this number to distinguish between models when several SP1000’s are connected to a phone or tablet.
6. Screw to open battery compartment. Turn the screw counter clockwise until it is just above the compartment door. Lift on the screw to open the compartment.
3
E. MAINTENANCE
1. Clean the surface of the instrument with a damp cloth. 2. Replace the three AAA batteries when the low battery indicator appears.
F. TROUBLE ShOOTING
Symptom CO2 seems inaccurate.
Probable Cause
· Low battery. · Make sure not to breath into test area. · Ensure connection with smart
device is working.
SP1000 does not turn on.
· Dead or low batteries. · Not holding down power switch
until unit turns on. · Defective POWERONswitch.
SP1000 reads high all the time. · Make sure not to breath into test area.
G. ACCESSORIES
Included Accessories
Part Number Description
A1000SP
Soft pouch
Optional Accessories
Part Number A925
A926
Description Carrying case for 4 smart probes Carrying case for 1 or 2 smart probes
4
h. WARRANTY
This product is warranted to the purchaser against defects in material and workmanship for three years from the date of purchase.
Covered by Warranty: Repair parts and labor; or replacement of the product at company’s option. Normal transportation charges to the purchaser are also covered.
Not Covered by Warranty: Damages to the product which are the result of abuse, improper use or maintenance are not covered. Any other expense, consequential damages, incidental damages, or incidental expenses including damages to property are not covered. Transportation expenses to the company are not covered.
To Obtain Warranty Performance: Include with the product: your name, address, phone number, written description of the problem and proof of purchase date. Carefully package and return to:
TPI, Inc. 9615 SW Allen Blvd. Beaverton, OR 97005 USA 503-520-9197 www.testproductsintl.com
TPI Canada 342 Bronte Rd. S., Unit 6 Milton, Ontario L9T 5B7 Canada 905-693-8558 www.tpicanada.com
TPI, Europe Ltd.. Longley house, International Drive Southgate Crawley West Sussex Rh10 6AQ England 44(0) 1293 530196 www.tpieurope.com
Implied Warranties: Any implied warranties including implied warranties of merchantability and fitness for a particular purpose, are limited in duration to three years from date of purchase. To the extent any provision of this warranty is prohibited by federal or state law and cannot be preempted, it shall not be applicable. This warranty gives you specific legal rights, and you may also have other rights which vary from country to country.
I. REPLACING BATTERIES
1. Turn the battery compartment screw counter clockwise until it is just above the compartment door. Lift on the screw to open the compartment.
2. Replace the three AAA batteries.
3. Re-install the battery cover and tighten the screw by turning it clockwise.
5
