Heckler Design H602 Checkout Stand For Ipad Instruction Manual

H602 Checkout Stand for iPad

Product Information

The CHECKOUT STAND is a Point-of-Sale Stand designed
specifically for the iPad 10.2-inch 7th Generation, 8th Generation,
and 9th Generation models. It is compatible with these iPad
models.

The product comes with a limited warranty. Heckler Design
warrants the product to be free from defects in material and
workmanship for a period of two years from the original date of
purchase. Electronic components are warranted for one year. If any
defects are discovered, customers can contact
[email protected] for assistance. The company will repair
or replace the item at their discretion.

The assembly tool included in the package is an M3 Hex Key. It
is important to keep the tool in a safe place. If a replacement is
needed, customers can contact [email protected].

The CHECKOUT STAND can be assembled with or without the iDynamo
5 feature. Additional accessories such as the Right Angle Lighting
Cable, Counter Mounting, PivotTable, PivotTack, and Kensington
ClickSafe Cable Lock are sold separately.

Product Usage Instructions

1. Assembling with iDynamo 5:
   1. Loosen, but do not remove the F529 screw.
   2. Attach the iDynamo 5 to the stand.
   3. Tighten the F529 screw.
   4. If using a Right Angle Lighting Cable, connect it to the
      iPad.
   5. Mount the stand on the counter using Counter Mounting (sold
      separately) if desired.
2. Assembling without iDynamo 5:
   1. Loosen, but do not remove the F529 screw.
   2. If using a Right Angle Lighting Cable, connect it to the
      iPad.
   3. Mount the stand on the counter using Counter Mounting (sold
      separately) if desired.
3. Additional accessories:
   1. PivotTable (sold separately): Attach the PivotTable to the
      stand for adjustable viewing angles.
   2. PivotTack (sold separately): Use the PivotTack to secure the
      stand in place.
   3. Kensington ClickSafe Cable Lock (sold separately): Secure the
      iPad and stand with the cable lock for added security.

WindFall®
CHECKOUT STAND Point-of-Sale Stand for iPad 10.2-inch 7th Generation
Assembly & Installation

Compatible with:
iPad 10.2-inch 7th Generation iPad 10.2-inch 8th Generation iPad 10.2-inch 9th Generation

Limited Warranty
Heckler Design warrants your product to be free from defect in material and workmanship for a period of two years from the original date of purchase. Electronic components are warranted to be free from defect for a period of one year from the original date of purchase. If you discover a defect, please contact [email protected]. Heckler Design will repair, at our discretion, using new or refurbished components. If repair is not possible, Heckler Design will replace the item.
H602

1x
M3 Hex Key
F529

Keep your assembly tool in a safe place. To purchase a replacement, please contact [email protected].

Assemble With Or Without iDynamo 5 Features

With iDynamo 5

Without iDynamo 5

2

With iDynamo 5

1
F529

Loosen, but do not remove.
3

2 3
4

4
5
F529
5

Without iDynamo 5
1
F529
6

2
F529
3

Loosen, but do not remove.
Right Angle Lighting Cable (Sold Separately)
7

4
F529
8

Counter Mounting
2x
(Sold Separately)
PivotTable
(Sold Separately)
9

PivotTack
(Sold Separately)
Kensington ClickSafe Cable Lock
(Sold Separately)
10
