PS 600 ES+ Storage Tank
PS ES+ Thermal Stores
PS ES+ Thermal Stores are designed for storing and distributing
thermal energy from solid-fuel fired boilers. These tanks come in
three different models with capacities of 560, 860, and 1037
liters. The tanks are fitted with three side connections, one top
connection, and one connection for sensor sheath. You can install
230V or 3x230V/400V heating elements with 2-12 kW output directly
into the 6/4 connections. The tanks have no finish or
anti-corrosion protection on the inner surface, while the outer
surface is lacquered in gray.
Technical Data
- Total Tank Volume: Varies by model (560L, 860L, or 1037L)
- Max. Working Temperature in Tank: Not specified
- Max. Working Pressure in Tank: Not specified
- Tank Material: S235JR
- Tank Diameter: 650mm (without insulation), 850mm (with
insulation) - Tank Overall Height: Varies by model (1935mm, 2015mm, or
2335mm) - Heating Element Max. Length/Output: 700mm/8.2kW or 815mm/12kW
(depending on model) - Empty Weight: Varies by model (62kg, 84kg, or 123kg)
Installation and Commissioning
Installation of PS ES+ Thermal Stores should only be done by
qualified staff in accordance with valid rules. Improper
installation, use, or handling will void the warranty. After
installation, it is recommended to clean the entire heating system
using a suitable cleaning agent (e.g. BP 400) and apply an
anti-corrosion protective liquid (e.g. BP 100 Plus).
Operation
PS ES+ Thermal Stores can be heated by various types of
hot-water boilers or electric heating elements. Connect the thermal
store to the energy source using a G 6/4 connection fitting. The
individual tank outlets should be fitted according to the circuits
to be connected.
PS ES+
www.regulus.eu
Installation and Operation Manual EN
THERMAL STORES PS 600 ES+, PS 900 ES+, PS 1100 ES+
PS ES+
CONTENTS
1 Description …………………………………………………………………………………………………………………………………. 2 1.1 Models …………………………………………………………………………………………………………………………….. 2 1.2 Tank Protection …………………………………………………………………………………………………………………. 2 1.3 Thermal Insulation …………………………………………………………………………………………………………….. 2 1.4 Connection points on the tank …………………………………………………………………………………………….. 2 1.5 Packaging………………………………………………………………………………………………………………………… 2
2 General Information …………………………………………………………………………………………………………………….. 2 3 Dimensions and Other Technical Data ………………………………………………………………………………………….. 3 4 Operation…………………………………………………………………………………………………………………………………….. 5 5 Typical Layout Example with Thermal Store …………………………………………………………………………………. 5 6 Installation and Commissioning …………………………………………………………………………………………………… 6
6.1 Connection to heat sources ……………………………………………………………………………………………….. 6 6.2 El. heating element installation …………………………………………………………………………………………… 6 6.3 Commissioning …………………………………………………………………………………………………………………. 6 7 Installing Insulation on the Tank ………………………………………………………………………………………………….. 6 8 Maintenance………………………………………………………………………………………………………………………………… 8 9 Disposal ……………………………………………………………………………………………………………………………………… 8 10 Warranty ……………………………………………………………………………………………………………………………………… 8
1 – Description
PS ES+ Thermal Stores are intended for storing and subsequent distribution of thermal energy from solid-fuel fired boiler. 230V or 3x230V/400V heating elements (2-12 kW output) can be installed directly into the 6/4″ connections. Tanks are fitted with three side connections, one top connection and one connection for sensor sheath. A 100mm thick insulation for these tanks can be purchased as a separate item.
1.1 – Tank protection Three models of 560, 860 and 1037 l capacity.
1.2 – Tank protection The inner surface has no finish, no anticorrosion protection, the outer surface is lacquered in gray.
1.3 – Thermal Insulation Thermal insulation is available as a separate item. For easier handling, the insulation shall not be fitted on the tank until it reaches its definite place of installation. The insulation is made of fleece, 100 mm thick, with a hard polystyrene surface. It is closed by a quick lock.
1.4 – Connection points on the tank 3× side connections, G 6/4″ F thread 1× top connection, G 6/4″ F thread” 1× side connections for sensor sheaths, G 1/2″ F thread
1.5 – Packaging Thermal stores are delivered standing, each screwed to its separate pallet, packed in bubble wrap.
2
2 – General Information
This Manual is an integral and important part of the product and must be handed over to the User. Read carefully the instructions in this Manual as they contain important information concerning safety, installation, operation and maintenance. Keep this Manual for later reference. The appliance shall be installed by a qualified person according to valid rules and Manufacturer`s Instructions, otherwise the Warranty is null and void. This appliance is designed to accumulate thermal energy of heating water and distribute it subsequently. It must be connected to a heating system and heat sources. Using the thermal store for other purposes than above described is forbidden and the manufacturer accepts no responsibility for damage caused by improper or wrong use. The thermal store must not be used as a hot water storage tank!
3 – Dimensions and Other Technical Data
ØDe ØDi H1
U1 C1
U2
H2
3
V
Code Thermal store Tank code Insulation code (accessor.)
PS 600 ES+ 15527 19310
PS 900 ES+ 15530 19301
Application Storage and subsequent distribution of thermal energy from solid-fuel boilers.
Energy efficiency data (as per EC Regulation No. 813/2013)
PS 600 ES+ w. insulation
PS 900 ES+ w. insulation
Energy efficiency class
–
–
Standing loss
98 W
122 W
Storage volume
560 l
860 l
Technical data Total tank volume Max. working temperature in tank Max. working pressure in tank
560 l 95 °C 3 bar
860 l 95 °C 3 bar
Material Tank material
S235JR
S235JR
Dimensions, tipping height, weight
Tank diameter
650 mm
Tank diameter with insulation
850 mm
Tank overall height
1935 mm
Tipping height without insulation
1960 mm
Heating elem. max. length / output
700 mm / 8,2 kW
Empty weight
62 kg
790 mm 990 mm 1975 mm 2015 mm 815 mm / 12 kW
84 kg
Accessories Insulation (code) El. heating element
19310 models ETT-A, C, D, F, P, M
19301
PS 1100 ES+ 15956 19315
PS 1100 ES+ w.¨insulation
135 W 1037 l
1037 l 95 °C 4 bar
S235JR
850 mm 1050 mm 2080 mm 2335 mm 815 mm / 12 kW
123 kg
19315
Thermal store Tipping height without insulation Marking Heating system H1 H2 Control and safety C1 Universal inlet/outlet U1 U2 Tank dimensions [mm] V (tank height) Ø Di (tank diameter) Ø De (diam. w. insulation)
PS 600 ES+ 1960 mm
PS 900 ES+ 2015 mm
Connection Height [mm] Connection Height [mm]
PS 1100 ES+ 2335 mm
Pipojení Height [mm]
G 6/4″ G 6/4″
1935 235
G 6/4″ G 6/4″
1975 225
G 6/4″ G 6/4″
2080 255
G 1/2″
1510
G 1/2″
1530
G 1/2″
1620
G 6/4″ G 6/4″
1635 935
G 6/4″ G 6/4″
1655 955
G 6/4″ G 6/4″
1745 1045
1935 650 850
1975 790 990
2080 850 1050
4
4 – Operation
In a thermal store, heating water can be heated up by various types of hot-water boilers, or possibly also by electric heating elements. The thermal store is connected to the energy source using a G 6/4″ connection fitting. The individual tank outlets are fitted according to the circuits to be connected.
5 – Typical Layout Example with Thermal Store
Example Biomass boiler (fireplace insert/stove)
5
KEY
1 hot water storage tank 2 electric heating element with thermostat 3 thermal store for central heating – PS xxx E+ (ES+) 4 heating system expansion vessel 5 boiler load unit – thermostatic 6 biomass boiler (fireplace insert/stove) 7 pump station for heating system – CSE MIX 8 pump station for DHW heating CSE OTS ZV 9 pump station for DHW recirculation CSE TVMIX ZV 10 safety kit for HW storage tank 11 DHW expansion vessel SV cold water TV hot water CV hot water recirculation ÚT central heating (heating system)
KK ball valve ZV check valve AOV automatic air vent valve PTR pressure temperature relief valve REDV pressure reducing valve (optional) VK drain valve SVE expansion vessel service valve PV-ÚT safety valve for heating system MFB Magnet Filterball F filter BVTS safety relief valve of boiler cooling loop
6 – Installation and Commissioning
Installation shall meet valid rules and may be done by qualified staff only. Defects caused by improper installation, use or handling are not covered by warranty. After the tank is installed and connected to an existing heating system, it is recommended to clean the entire heating system using a suitable cleaning agent, e.g. BP 400. Anti-corrosion protective liquid should be also used, e.g. BP 100 Plus.
6.1 – Connection to heat sources Place the tank on the floor, as close to your heat source as possible. Fit the insulation, cf. Installing Insulation on the Tank. Connect the heating system according to the recommended connection layout – see Chap. 5.Install a drain valve at the lowest point of the tank. Install an air vent valve at the highest point of the system. Insulate all the connecting piping.
6.2 – El. heating element installation These thermal stores can be equipped with electric heating elements of output up to 12 kW depending on the volume of the thermal store – see the table of max. output of heating elements in hot water tanks and thermal stores. They can be connected either directly (elements with integrated thermostat) or via the controller of the entire heating system. All electric heating elements shall be protected by a safety thermostat. The electric heating element shall be wired by a professionally qualified person only.
6.3 – Commissioning Ground the tank before commissioning. This tank is not designed for DHW heating. The tank shall be filled up together with the heating system, respecting valid standards and rules. In order to minimize corrosion, special additives for heating systems should be used. The quality of heating water depends on the quality of filling water at commissioning, on the top-up water quality and on the frequency of topping up. This has a strong influence on the lifetime of heating systems. Poor quality of heating water may cause problems like corrosion or incrustation, esp. on heat transfer surfaces.
Fill the heating circuits with the appropriate fluids and air-bleed the entire system. Check all connections for leaks and verify the system pressure. Set the heating controller in compliance with the documentation and manufacturer’s recommendations. Check regularly proper function of all control and adjustment elements.
7 – Installing Insulation on the Tank
Product description Fleece insulation with a hard polystyrene surface, closed by a quick locks.
Warning Insulation installation shall be done in two or three persons, depending on its size. The PU leather surface coated fleece insulation must not be installed at temperatures below 20 °C. If this cannot be avoided, the insulation shall be pre-warmed in another room to at least 20 °C. It is impossible to install insulation of lower temperature, there is a risk of damage. Do not use any tools for installation. Keep away from open fire.
Installing insulation 1. Put the bottom insulation under the tank and place the tank following installation instructions. 2. Wrap the insulation around the tank carefully. Check that the insulation adheres to its body perfectly. This can be
reached by rubbing and patting the insulation by hand from its centre evenly in both directions until the insulation adheres to the tank’s surface completely and no bubbles are left. 3. Use the holes for connections as a rest during the insulation installation. 4. At least one person presses the insulation to the tank, pulling both ends together. The other person closes the quick lock from the side. 5. Put on the upper insulation and cover. 6. Push on the covering plastic rosettes depending on the size of connections, or put on the flange plug(s) with insulation. 7. Finish the tank installation in compliance with the respective instructions and valid standards and rules.
6
Warranty on insulation The insulation is covered by a 24-month warranty. This period starts the next day after the insulation is sold. Warranty shall become null and void if:
the procedure described in the Installation Manual was not respected, the product was used for other purposes than intended. Warranty does not cover: usual wear and tear, damage caused by fire, water, electricity or another natural disaster, defects caused by failure to use the product in compliance with its intended purpose, by improper use and
insufficient maintenance, defects caused by mechanical damage to the product, defects caused by tampering or incompetent repair.
7
8 – Maintenance
If the tank is fitted with a heating element, disconnect it from the mains first. Clean the exterior of the tank with a soft cloth and a mild detergent. Never use abrasive cleaners or solvents. Check all tank connections for leaks.
9 – Disposal
Packaging shall be disposed of in compliance with the valid rules. When the product reaches the end of its life, it shall not be disposed of as household waste. It shall be dropped off at a Local Waste Recycling Centre. Insulation shall be recycled as plastic and the steel vessel as scrap iron.
10 – Warranty
This product is covered by warranty according to the conditions described in this Manual and according to the Warranty Certificate. A Warranty Certificate is an integral part of the supply.
©2023 We reserve the right to errors, changes and improvements without prior notice.
REGULUS spol. s r.o. E-mail: [email protected] Web: www.regulus.eu
v1.2-01/2023
