3880-3 Pozi-Loc Tripods

Pozi-Loc Tripod by Vinten

Product Information

The Pozi-Loc tripod range is designed to meet the demands of
professional camera operators. It combines an innovative clamping
system with new advances in manufacturing technology. Pozi-Loc
tripods are available with aluminium or carbon fibre legs in
single- or two-stage configuration and with 75 mm, 100 mm, or 150
mm bowl mounting. The tripod is offered in different types and
models, each with varying technical data.

Features and Benefits

• Innovative clamping system
• New advances in manufacturing technology
• Available in aluminium or carbon fibre legs
• Single- or two-stage configuration
• 75 mm, 100 mm, or 150 mm bowl mounting

Technical Data

Product Usage Instructions

We recommend that you read the operators guide before using your
Pozi-Loc tripod to familiarize yourself with its features,
essential health and safety information, and maintenance
requirements. To register your product and receive additional
benefits, visit www.vinten.com/register or complete the
registration form.

To use your Pozi-Loc tripod, follow these steps:

1. Choose the appropriate type and model of Pozi-Loc tripod based
   on your camera and filming requirements.
2. Ensure that the tripod is set up on a stable and level
   surface.
3. Open the tripod legs and adjust the height of each leg
   according to your desired shooting angle.
4. If necessary, attach a spreader to the tripod to provide
   additional stability.
5. Mount your camera onto the tripod bowl mount and secure it
   using the innovative clamping system.
6. Adjust the camera position and angle as needed using the
   tripod’s pan and tilt controls.
7. When finished, remove the camera from the tripod and collapse
   the legs for storage.
8. Regularly check and maintain your Pozi-Loc tripod to ensure it
   remains in perfect condition for years of reliable
   performance.

Remember to pay attention to any WARNING symbols in the
operators guide, which indicate risks of personal injury, injury to
others, or damage to the tripod or associated equipment.

Operators Guide

Tripods

Pozi-Loc
Vinten
Camera Control Solutions

Vision
Pozi-Loc
Tripods
Publication Part No. 3770-8 Issue 3
Copyright © Vinten Broadcast Limited 2005 All rights reserved throughout the world. No part of this document may be stored in a retrieval system. transmitted, copied or reproduced in any way including, but not limited to, photocopy, photograph, magnetic or other record without the prior
agreement and permission in writing of Vinten Broadcast Limited.
Vinten and Vision are registered trademarks of Vinten Broadcast Limited.

Preface
Thank you and congratulations on your new Pozi-Loc tripod from Vinten
We want you to get the most from your new Pozi-Loc tripod, and therefore encourage you to read this operators guide to familiarise yourself with its many features, some of which may be new to you. It also covers essential health and safety information and a section on maintenance that will ensure you keep your new product in perfect condition. To receive additional benefits, register with Vinten now, on line by visiting www.vinten.com/register, or by completing the registration form.
Features and benefits of your new Pozi-Loc tripod
Designed to meet the demands of the professional camera operator, the Pozi-Loc tripod range combines an innovative clamping system with new advances in manufacturing technology. PoziLoc tripods are available with aluminium or carbon fibre legs in single-or two-stage configuration and with 75 mm, 100 mm or 150 mm bowl mounting.
· Cam-operated clamping system requires low effort with a 90° turn from on to off, providing the user with a positive indication that the tripod is securely locked.
· The profile of the knob ensures that camera cables cannot snag. · Lighter than earlier models and with an increased payload capacity of 25kg (55lb). · Extensive height range and unrivalled torsional stiffness.
Once again, thank you for choosing the Pozi-Loc tripod. We are confident it will give you many years of reliable
performance.
3

Safety – Read This First
Warning Symbols in this Operators Guide
Where there is a risk of personal injury, injury to others, or damage to the tripod or associated equipment, comments appear, highlighted by the word WARNING! and supported by the warning triangle symbol.

Technical data

Type
3880-3 Two-stage Aluminium
3881-3 Two-stage Carbon Fibre
3770-3 Two-stage Aluminium
3771-3 Single-stage Aluminium
3796-3 Single-stage Aluminium 2 metre
3883-3 Two-stage Aluminium EFP
3772-3 Two-stage Carbon Fibre
3773-3 Single-stage Carbon Fibre
3884-3 Two-stage Carbon Fibre EFP
3774-3 Two-stage Aluminium

Levelling Maximum Minimum

Bowl Height with Height with Recommended

Diameter Spreader Spreader Maximum Load Weight

150 mm 157.1 cm (61.9 in.)

52 cm (20.5 in.)

45 kg (99 lb)

5.8 kg (12.8 lb)

150 mm 157.1 cm (61.9 in.)

52 cm (20.5 in.)

45 kg (99 lb)

5.5 kg (12.1 lb)

100 mm 156.2 cm (61.5 in.)

100 mm 100 mm

145.5 cm (57.3 in.) 201.5 cm (79.3 in.)

41.6 cm (16.4 in.)
64.7 (25.5 in.) 98.5 (38.8 in.)

25 kg (55 lb)
25 kg (55 lb)
25 kg (55 lb)

3.2 kg (7.1 lb) 2.8 kg (6.2 lb) 3.7 kg (8.1 lb)

100 mm 157.1 cm (61.9 in.)

52 cm (20.5 in.)

45 kg (99 lb)

5.8 kg (12.8 lb)

100 mm 156.2 cm (61.5 in.)

100 mm 100 mm

145.5 cm (57.3 in.) 157.1 cm (61.9 in.)

41.6 cm (16.4 in.)
64.7 (25.5 in.) 52 cm (20.5 in.)

25 kg (55 lb)
25 kg (55 lb)
45 kg (99 lb)

2.6 kg (5.7 lb) 2.3 kg (5.0 lb) 5.5 kg (12.1 lb)

75 mm 156.2 cm (61.5 in.)

41.6 cm (16.4 in.)

25 kg (55 lb)

3.2 kg (7.0 lb)

Transport Length
76 cm (29.9 in.)
76 cm (29.9 in.)
71 cm (28.0 in.)
86.4 cm (34.0 in.) 115 cm (45.3 in.)
76 cm (29.9 in.)
71 cm (28.0 in.)
86.4 cm (34.0 in.) 76 cm (29.9 in.)
71 cm (28.0 in.)

4

Technical data

Type
3775-3 Single-stage Aluminium
3776-3 Two-stage Carbon Fibre
3777-3 Single-stage Carbon Fibre
3882-3 Two-stage Baby-Legs
3778-3 Two-stage Baby-Legs
3779-3 Two-stage Baby-Legs

Levelling Maximum Minimum

Bowl Height with Height with Recommended

Diameter Spreader Spreader Maximum Load Weight

75 mm

145.5 cm (57.3 in.)

64.7 (25.5 in.)

25 kg (55 lb)

2.8 kg (6.2 lb)

75 mm 156.2 cm (61.5 in.)

41.6 cm (16.4 in.)

25 kg (55 lb)

2.6 kg (5.64 lb)

75 mm 150 mm 100 mm 75 mm

145.5 cm (57.3 in.) 50 cm (19.7 in.) 51 cm (20.1 in.) 51 cm (20.1 in.)

64.7 (25.5 in.) 28 cm (11 in.) 23.7 cm (9.3 in.) 23.7 cm (9.3 in.)

25 kg (55 lb)
45 kg (99 lb)
25 kg (55 lb)
25 kg (55 lb)

2.3 kg (5.0 lb) 4 kg (8.8 lb) 2.1 kg (4.6 lb) 2.1 kg (4.6 lb)

Transport Length
86.4 cm (34.0 in.) 71 cm (28.0 in.)
86.4 cm (34.0 in.) 36.3 cm (14.3 in.) 32.7 cm (12.9 in.) 32.7 cm (12.9 in.)

Further information

For full details on maintenance and spare parts, please refer to Vision Pozi-Loc Tripods – Spares and Repairs (Publication Part No. 3770-9) This is obtainable from Vinten Broadcast Limited or your local Vinten distributor. For information on-line, visit our website at
www.vinten.com.

5

Contents
Page Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Safety – Read This First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Further information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Optional equipment
‘Spread-Loc’ mid-level spreader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Carrying strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Servicing General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Routine checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Adjusting `Pozi-Loc’ leg clamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Parts list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Associated publications
Vision Pozi-Loc Tripods – Spares and Repairs Publication Part No. 3770-9
Vision Spread-Loc Spreader – Operators Guide Publication Part No. 3781-8
Spreaders, Dollies and Skids – Spares and Repairs Publication Part No. 3313-9
6

(7)

(1)

(6)

(5)

(2)

(4)

(3)

Typical Vision Pozi-Loc Tripod

(1)

Tripod bowl

(2)

Clamp knob

(3)

Floor spreader

(4)

Floor spreader adjuster

(5)

Leg tie strap

(6)

Spread-Loc attachment point

(7)

Tie down hook

7

(7)

(1)

(2)

(8)

Typical Vision Pozi-Loc Baby-Legs Tripod

(1)

Tripod bowl

(2)

Clamp knob

(7)

Tie down hook

(8)

Cleat rope spreader

8

Introduction
The Vision Pozi-Loc range includes single- and two-stage tripods with either aluminium or carbon fibre legs, fitted with 75 mm, 100 mm or 150 mm levelling bowls (See table on page 4). All are fitted with the highly-efficient Pozi-Loc leg clamp, which provides quick set-up and easy adjustment. The tripods are designed for use with Vinten floor spreaders and dollies. An optional mid-level spreader may be used. Low-level `baby-legs’ versions are also available, fitted with a simple cleat rope spreader.
9

Operation

NOTE:

The following procedures refer to a two-stage tripod fitted with a Vision head and a floor spreader. The procedure for single-stage tripods is essentially similar. When using a two-stage tripod the bottom stages should be fully extended or fully retracted, unless conditions such as split levels prevent this.

Lift the complete tripod and head out of the case using the finger holes just below the top clamps.

NOTE: Keep the spreader attached to the tripod

Set the pan bar.
Release the leg tie strap (5).
Still holding the finger holes, open out the legs. Gentle foot or hand pressure on the spreader (3) will ensure that the legs are fully spread.

NOTE:

Always use the spreader where possible as this increases rigidity of the tripod. Being flexible, the spreader compensates for uneven ground. It can be removed and a dolly fitted. At the fullest extension of the spreader and with all legs fully retracted, the tripod can be used at its lowest operating height. Although the tripod can be set up lower than this without the spreader, it is NOT recommended as the tripod geometry becomes unstable

Adjust the operating height by undoing the leg clamps (2) and pulling the tripod up to the desired height. Adjust the spreader (4) if necessary. Level the head using the level bubble.
Tighten the clamps (2) until an audible click is heard and the knob is in the horizontal, locked position.
In the case of a `baby-legs’ tripod, tighten the cleat rope spreader (8).

NOTE: An optional, conventional floor spreader (3379-3) is available for the `baby-legs’ tripods.

WARNING! It is possible to set the tripod legs so that the centre-of-gravity of the tilted payload falls outside the footprint of the tripod, leading to instability. Use a mid-level or floor spreader to ensure that the tripod legs are spread sufficiently so that the centre-of-gravity of the tilted payload remains within the footprint of the tripod. Secure the tripod with the tie-down hook (7) or hang a suitable weight from the hook.

NOTE:

The Vision spreader protects floors and carpets as well as preventing the tripod legs sinking into soft ground and should be used at all times. If the floor spreader cannot be used, use Vision carpet feet and a `Spread-Loc’ mid-level spreader.

10

Optional equipment
‘Spread-Loc’ mid-level spreader
To install the spreader: Grip the ends of each spreader arm in turn between thumb and fore-finger and press in the attachment release buttons (9). Push the arm into the tripod attachment (6) until the release engages. Fit the carpet feet (10). To remove the spreader, press in the attachment release buttons (9) and free each arm in turn.

(6)

(9)

(10)
Spread-Loc’ mid-level spreader
11

Carrying strap
A carrying strap is available as an optional accessory and is installed as follows: 150 mm bowl tripods On the underside of the tripod bowl, identify the M6 tapped hole (18). Position the bowl strap anchor (17) on the underside of the tripod bowl, ensuring it is correctly oriented. Using Loctite 221, secure the bowl strap anchor with the 25 mm M6 screw (16) supplied with the strap. On the lower moulding of the corresponding leg, drive in the ‘knock-out’ (15) using a suitable tool. If possible, remove the blank from inside the moulding to prevent subsequent rattle. Push a blind captive nut (14) into the hole in the lower moulding. Using a suitable M5 screw, fully compress the blind captive nut. Remove the M5 screw. Install a washer (13) on the lower strap anchor (12) and screw into the captive nut (14). Ensure that the hole in the strap anchor is oriented so that the karabiner (11.1) can be attached Using the karabiners (11.1), clip the strap (11) to the strap anchors and adjust to length. 75 mm and 100 mm bowl tripods On the lower moulding of the leg with the strap (5), drive in the ‘knock-out’ (15) using a suitable tool. If possible, remove the blank from inside the moulding to prevent subsequent rattle. Push a blind captive nut (14) into the hole in the lower moulding. Using a suitable M5 screw, fully compress the blind captive nut. Remove the M5 screw. Install a washer (13) on the lower strap anchor (12) and screw into the captive nut (14). Ensure that the hole in the strap anchor is oriented so that the karabiner (11.1) can be attached On the underside of the tripod bowl, remove and discard the screw (16) securing the corresponding leg clamp (20). Do not remove the washer (19). Position the bowl strap anchor (17) on the leg clamp, ensuring it is correctly oriented. Using Loctite 221, secure the bowl strap anchor with the 25 mm M6 screw (16) supplied with the strap. Tighten screw to a torque of 4.5 Nm (40 lbf in.). Using the karabiners (11.1), clip the strap (11) to the strap anchors and adjust to length.
12

(11.1) (12) (13) (14) (15)

(16)

(11)

(17) (11.1)

(18)

150 mm

(16)

(17)

(19)

(11.1)

75/100 mm
(20)

Carrying strap
13

Servicing
General
Vision products are robustly made to high engineering standards and little attention is required to maintain serviceability save regular cleaning. Attention to the following points will ensure a long and useful service life with minimum need for repair.
Cleaning
During indoor use, the only cleaning required should be a regular wipe over with a lint-free cloth. Dirt accumulated during storage may be removed using a semi-stiff brush. Particular attention should be paid to the mounting bowl of the tripod. All tripod, spreader and dolly parts are weatherproof. However, use out-of-doors under adverse conditions will require special attention. Salt spray should be washed off with fresh water at the earliest opportunity. Sand and dirt acts as an abrasive and should be removed using a semi-stiff brush or vacuum cleaner.
NOTE: Use only detergent-based cleaners. DO NOT use solvent- or oil-based cleaners, abrasives or wire brushes to remove accumulations of dirt, as these damage the protective surfaces.
Routine checks
During normal use, check the effectiveness of the leg clamps and adjust as necessary.
Adjusting `Pozi-Loc’ leg clamps
Bedding-in occurs with `Pozi-Loc’ leg clamps, which may necessitate resetting the clamp. Check the effectiveness of each leg clamp as follows:
Extend all three tripod legs fully and apply the clamps (2). Position each leg in turn vertically on a set of weighing scales. Gradually apply body weight to the leg until either or both clamps begin to slip. Note the reading on the scales at which this occurs. A reading of less than 35 kg (77 lb) will necessitate adjustment.
14

(22)

(21)

(23)

Top clamp Top clamp
Adjust a top clamp as follows: Turn the clamp knob (21) to the vertical, `off’ position Remove screw (23). Using a suitable peg spanner, back off the threaded insert (22) slot by slot until the leg is free to move under its own weight. While sliding the leg in and out, gradually tighten the threaded insert (22) until the clamp begins to grip. If not aligned, back off the threaded insert (22) until a slot aligns with the hole for screw (23). Carbon fibre tripods (black legs) – back off the threaded insert (22) two slots. Aluminium tripods (grey legs) – back off the threaded insert (22) three slots Install screw (23) to secure the threaded insert (22).
15

(24)

(25)

(24)

(24.1)

POSITION 2

(26)

(27)

90°

(28)

POSITION 1

(29) (26)

Bottom clamp
Bottom clamp
Adjust a bottom clamp as follows: Tighten the clamp (26) until an audible click is heard and the knob is in the locked position (Position 1). Using a suitable instrument, such as a flat-bladed screwdriver, carefully remove the knob cap (29). Remove the retaining screw (28) and washer (27), and pull off the clamp knob (26). Examine the shaft (24). If there is an identifying groove (24.1) on the shaft, proceed as follows. Otherwise, consult Vision Pozi-Loc Tripods – Spares and Repairs (Publication Part No. 3770-9) or contact your local Vinten dealer. Replace the clamp knob (26) and turn it to Position 2. Using a 2.5 mm hexagonal wrench, slacken the grubscrew (24) until the leg is free to move under its own weight.
16

With the knob still in Position 2, slide the leg in and out and gradually tighten the grubscrew (24) until the clamp begins to grip. Back off the grubscrew (24) by a quarter-turn (90°). Secure the clamp knob (26) with the washer (27) and retaining screw (28). Refit the knob cap (29).
17

Parts list

The following lists include main assemblies and optional accessories. For further information regarding repair or spare parts, please contact Vinten Broadcast Ltd or your local distributor. For information on-line, visit our website at
www.vinten.com.

Tripods

Two-stage tripod, aluminium legs, 150 mm bowl Two-stage tripod, carbon fibre legs, 150 mm bowl Two-stage tripod, aluminium legs, 100 mm bowl Single-stage tripod, aluminium legs, 100 mm bowl Single-stage tripod, 2 metre, aluminium legs, 100 mm bowl Two-stage EFP tripod, aluminium legs, 100 mm bowl Two-stage tripod, carbon fibre legs, 100 mm bowl Single-stage tripod, carbon fibre legs, 100 mm bowl Two-stage EFP tripod, carbon fibre legs, 100 mm bowl Two-stage tripod, aluminium legs, 75 mm bowl Single-stage tripod, aluminium legs, 75 mm bowl Two-stage tripod, carbon fibre legs, 75 mm bowl Single-stage tripod, carbon fibre legs, 75 mm bowl Two-stage baby-legs tripod, aluminium legs, 150 mm bowl Two-stage baby-legs tripod, aluminium legs, 100 mm bowl Two-stage baby-legs tripod, aluminium legs, 75 mm bowl
Floor spreaders

3880-3 3881-3 3770-3 3771-3 3796-3 3883-3 3772-3 3773-3 3884-3 3774-3 3775-3 3776-3 3777-3 3882-3 3778-3 3779-3

Floor spreader, for tripods with aluminium legs Floor spreader, for tripods with carbon fibre legs Floor spreader, for Vision 3 systems Floor spreader, for baby-legs tripods
Mid-level spreader

3313-3 3363-3 3394-3 3379-3

`Spread-Loc’ mid-level spreader Set of three feet (for use with mid-level spreaders)

3781-3 3378-902SP

18

Dollies
ENG (OB) dolly ENG (Studio) dolly ENG (OB) dolly – small EFP (OB) dolly EFP (Studio) dolly
Optional accessories
Carrying strap

3319-3B 3319-3C 3319-3ST 3497-3E 3497-3G
3425-3P

19

References
