Nvent 60630-189_bet_01_d Varistar Cp Flat Top Cover User Manual

Product Information

• Product Name: VARISTAR CP Dach EMV 800 bis 1000T
• User Manual Language: German (Benutzeranleitung)
• Product Model: VARISTAR CP
• Top Cover Type: EMC
• Supported Sizes: 800 to 1000D
• Manufacturer Website: nVent.com
• Manufacturer Part Number: 60630-189_BET Rev.D

Product Usage Instructions

1. Step 1: Place the product on a flat surface.
2. Step 2: Insert one (1x) of the component labeled as “1”.
3. Step 3: Attach four (4x) components labeled as “2” and two (2x)
   components labeled as “4” to the product.
4. Step 4: Attach one (1x) component labeled as “3” to the
   product.
5. Step 5: Attach two (2x) components labeled as “6” and two (2x)
   components labeled as “5” to the product.
6. Step 6: Attach two (2x) components labeled as “7” to the
   product.
7. Step 7: Tighten the screws for components labeled as “5” with a
   torque of 8 Nm.
8. Step 8: Attach two (2x) components labeled as “2” to the
   product.
9. Step 9: Attach one (1x) component labeled as “6” to the
   product.
10. Step 10: Attach one (1x) component labeled as “3” to the
    product.
11. Step 11: Attach one (1x) component labeled as “7” to the
    product.
12. Step 12: Tighten the screws for components labeled as “6” and
    “7” with a torque of 5 Nm.
13. Step 13: Rotate the product by 90 degrees.
14. Step 14: Repeat steps 2-7 on the other side of the
    product.
15. Step 15: Tighten the screws for components labeled as “5” with
    a torque of 8 Nm.
16. Step 16: Repeat steps 8-13 on the other side of the
    product.
17. Step 17: Tighten the screws for components labeled as “6” and
    “7” with a torque of 5 Nm.
