RM-26-HC Refrigerated Merchandiser Reach In One Section

Product Information

The Glass Door Merchandiser Model RM-10-HC is a refrigeration
unit designed for commercial use. It features a glass door
assembly, evaporator assembly, condensing unit assembly, and a
lighting system. The product is manufactured by Hoshizaki and is
suitable for displaying and storing various items in a retail or
foodservice environment.

Main Assembly

The main assembly of the RM-10-HC includes various
components:

• Evaporator Assembly
• Condensing Unit Assembly
• Door Assembly
• Pilaster
• 30 Flat Shelf
• Shelf Clips
• Front Grill
• Back Grill
• Legs
• Thermometer
• Door Switch
• Door Switch Cover
• Key Set

Evaporator Assembly

The evaporator assembly includes components such as the
evaporator heat exchanger, control module, control module bracket,
shroud, drain pan, evaporator fan motor bracket, evaporator fan
motor & blade, fan guard, drain fitting, and cabinet
thermistor.

Condensing Unit Assembly

The condensing unit assembly consists of various parts,
including the compressor, external protector, PTC relay, electrical
box, start capacitor, run capacitor, condenser, condenser fan motor
& blade, condenser fan motor bracket, drier, drain pan, and
power cord.

Door Assembly

The door assembly includes a glass pane, magnetic gasket, upper
hinge assembly, lower hinge assembly, torsion mechanism, and door
handle. Please note that the door is not reversible.

Lighting System

The RM-10-HC is equipped with a lighting system to illuminate
the contents of the merchandiser. The specific components of the
lighting system are not mentioned in the provided text extract.

Product Usage Instructions

Follow these instructions for proper usage of the Glass Door
Merchandiser Model RM-10-HC:

1. Ensure that the merchandiser is placed on a flat, stable
   surface.
2. Connect the power cord to a suitable electrical outlet.
3. Open the door assembly by grasping the door handle and pulling
   it towards you.
4. Arrange the desired items to be displayed or stored on the
   shelves inside the merchandiser.
5. Close the door assembly securely to maintain proper temperature
   and energy efficiency.
6. Monitor the thermometer on the unit to ensure that the desired
   temperature is maintained.
7. Regularly clean the glass door, shelves, and interior of the
   merchandiser to maintain cleanliness and hygiene.
8. In case of any issues or malfunctions, refer to the user manual
   or contact Hoshizaki customer support for assistance.

It is important to follow all safety guidelines and instructions
provided in the complete user manual for optimal usage and
longevity of the product.

Parts List
Glass Door Merchandiser Model RM-10-HC

hoshizakiamerica.com

Number: RM-10-HC Issued: 07-27-2018 Revised: 11-04-2022

TABLE OF CONTENTS
MAIN ASSEMBLY ………………………………………………………………………………………………………………………………….. 3 EVAPORATOR ASSEMBLY …………………………………………………………………………………………………………………….. 5 CONDENSING UNIT ASSEMBLY…………………………………………………………………………………………………………….. 7 DOOR ASSEMBLY ………………………………………………………………………………………………………………………………… 9 LIGHTING SYSTEM……………………………………………………………………………………………………………………………….. 11 FRONT GRILL ASSEMBLY……………………………………………………………………………………………………………………… 13

NOTE: To order spare parts, always include the following information: · Model Number __________________________________ · Serial Number __________________________________

2

RM-10-HC

MAIN ASSEMBLY

5 12

7

6 11

3

10

2 9
13

4

1 8

RM-10-HC

3

MAIN ASSEMBLY

Item No.
1 2 3 4 5 6 7 8 9 10 11 12 13

Description
EVAPORATOR ASSEMBLY CONDENSING UNIT ASSEMBLY DOOR ASSEMBLY PILASTER 30″ FLAT SHELF SHELF CLIPS FRONT GRILL BACK GRILL LEGS THERMOMETER DOOR SWITCH DOOR SWITCH COVER KEY SET

Part No.
OT-EV-0153 OT-UN-0261
OT-PT-0631*
PI-73 SH-0503-HD-FE CL-51-SS-E
OT-CM-0519*
SH-0504-G-GR LG-27 TH-1-E EL-306 PL-662-BK HA-471-G

Quantity per cooler
1 1 1 4 3 12 1 1 4 1 1 1 1

ITEM No.
3

Description DOOR ASSEMBLY

*Parts Change With Serial Number Break

Interchange- Previous

able

Component

Hoshizaki Last Serial Current Number and Earlier Component

YES

OT-PT-0571

K-00852 (H)

OT-PT-0631

7

FRONT GRILL

YES

OT-CM-0346

K-00852 (H)

OT-CM-0519

4

RM-10-HC

Hoshizaki First Serial Number and Later L-00254 (E)
L-00254 (E)

EVAPORATOR ASSEMBLY
1
10 6

7 8 5
11

4
3 2
9

RM-10-HC

5

EVAPORATOR ASSEMBLY

Item No.
1 2 3 4 5 6 7 8 9 10 11

Description
EVAPORATOR HEAT EXCHANGER CONTROL MODULE CONTROL MODULE BRACKET SHROUD DRAIN PAN EVAPORATOR FAN MOTOR BRACKET EVAPORATOR FAN MOTOR & BLADE FAN GUARD DRAIN FITTING CABINET THERMISTOR (evaporator and cabinet sensors)

Part No.

Quantity per cooler

CO-325

1

TUB-1046

1

** CT-198-SOL-138 (K)

1

OT-20868

1

OT-22485

1

OT-20512

1

OT-20824

1

OT-FA-85-0396

1

FA-62

1

DR-1-P

1

CT-196-2-SOL

2

** THE PART NUMBER CT-198-SOL-138 (K) INCLUDES:
CONTROL MODULE CT-198-SOL-138
DOOR SWITCH HARNESS OT-AR-5022 CONTROL MODULE HARNESS OT-AR-5518 CABINET THERMISTOR CT-196-2-SOL

ITEM No.
3

Description CONTROL MODULE

*Parts Change With Serial Number Break

Interchange- Previous

able

Component

Hoshizaki Last Serial Current Number and Earlier Component

YES

CT-194-SOL-078 L-02681(H)

CT-198-SOL-138

Hoshizaki First Serial Number and Later
M-01122(A)

6

RM-10-HC

CONDENSING UNIT ASSEMBLY

5 3
2

8
9 6

4 12

1

10

7 11

RM-10-HC

7

CONDENSING UNIT ASSEMBLY

Item No.

Description

1

COMPRESSOR (1/5HP 115V/60HZ R-290)

2

EXTERNAL PROTECTOR (T0269)

3

PTC RELAY (2014 145)

4

ELECTRICAL BOX

5

START CAPACITOR (125F 160V)

6

RUN CAPACITOR (10F 250V)

7

CONDENSER

8

CONDENSER FAN MOTOR & BLADE

9

CONDENSER FAN MOTOR BRACKET

10

DRIER

11

DRAIN PAN

12

POWER CORD (9 ft)

Part No.
NUY45NRb EL-2123-R EL-2124-R EL-2125-R CAP-125-160 CAP-10-250 CO-459 OT-FA-86-0396 FA-82 DR-31 OT-TF-0605 OT-EL-1265-9-4784

Quantity per cooler
1 1 1 1 1 1 1 1 1 1 1 1

8

RM-10-HC

DOOR ASSEMBLY
3 2

5 6

4

1

RM-10-HC

9

DOOR ASSEMBLY

Item No.
1 2 3 4 5 6

Description
GLASS PANE MAGNETIC GASKET UPPER HINGE ASSEMBLY LOWER HINGE ASSEMBLY TORSION MECHANISM DOOR HANDLE

NOTE: NOT REVERSIBLE DOOR

Part No.
GL-721-AD-EA OT-GA-900-PT-0631 HA-496-R HA-535-R HA-479
HA-632-K*

Quantity per cooler
1 1 1 1 1 1

ITEM No.

Description

6

DOOR HANDLE

10

*Parts Change With Serial Number Break

Interchangeable

Previous Component

Hoshizaki Last Serial Current Number and Earlier Component

NO

HA-627-K

K-00852 (H)

HA-632-K

Hoshizaki First Serial Number and Later
L-00254 (E)

RM-10-HC

LIGHTING SYSTEM

3 4

1 1
2

RM-10-HC

11

LIGHTING SYSTEM

Item No.
1 2 3 4

Description
LED LAMP STRIP (29 1/2″ ) LED DRIVER (1.25 Amp.) LIGHT SWITCH LIGHT SWITCH BRACKET

Part No.
EL-147 OT-EL-151-T EL-305 OT-20877

Quantity per cooler
2 1 1 1

12

RM-10-HC

FRONT GRILL ASSEMBLY
6 4
1
2
7

5 1

3 6

RM-10-HC

13

FRONT GRILL ASSEMBLY

Item No.

Description

1

FRONT GRILL REINFORCEMENT

2

FRONT GRILL

3

FRONT GRILL RIGHT PROFILE

4

FRONT GRILL LEFT PROFILE

5

FRONT GRILL CORNER

6

FRONT GRILL CORNER

7

FRONT GRILL CORNER

Part No.
OT-20499 OT-24214 OT-PL-654-GREY-8-R OT-PL-654-GREY-8-L PL-652-B PL-653-C PL-652-C

Quantity per cooler
2 1 1 1 1 2 1

14

RM-10-HC
