Big Ass Fans 007180 Aireye Low Rider Pedestal Fan Installation Guide

007180 AirEye Low Rider Pedestal Fan

Product Information: – Fan Size: 20 in. (508 mm), 24 in.
(610 mm), 30 in. (762 mm), 36 in. (914 mm) – Fan Weight: 32 lb
(14.5 kg), 38 lb (17.2 kg), 45 lb (20.4 kg), 67.1 lb (30.4 kg) –
Input Power: 277 VAC, 1, 50/60 Hz – Max Amps: 5.1 A, 3.1 A, 3.0 A,
5.2 A, 3.0 A, 3.1 A, 9.7 A, 5.5 A, 4.5 A – Max Power: 386 W, 392 W,
508 W, 396 W, 400 W, 501 W, 384 W, 390 W, 508 W, 711 W, 669 W, 716
W Parts and Hardware: – Front Guard – Hinge Pin Eyelets –
Blade Assembly – Set Screws – Flange Nuts – Rear Guard – Motor
ThruBolts – Main Mounting Hardware – Blade Assembly Retainer –
Keyhole Mounting Slots – Angle Adjustment Hardware – Safety Hinge
Pins Usage Instructions: 1. MOTOR – Make sure the fan
mount has been installed as specified in the mounting instructions.
– To adjust the motor angle, loosen the main mounting bolt and
angle adjustment bolt. 2. HARMONICS FILTER (36 IN. [914 MM] FANS) – Install the harmonics filter if included with your fan.
3. REAR GUARD – Align the mounting slots and secure the
guard. 4. BLADE ASSEMBLY – Ensure the blade assembly is
fully seated onto the shoulder of the shaft. – Align the set screws
to the flats of the shaft. – Always install the retaining ring. 5.
FRONT GUARD – Align the eyelets and fasten the hinge pins
starting with the topmost hinge. 6. SAFETY CABLE – Do not
attach the safety cable to the fan mount under any circumstances.
7. HARMONICS FILTER (20, 24, AND 30 IN. [508, 610, AND 762 MM] FANS) – Install the harmonics filter if included with your fan.
Electrical Connections: – Fan Only: Connect the power cord
directly to the fan. – Fan with Occupancy Sensor*: Connect the
power cord to the occupancy sensor and then to the fan. – Fan with
Harmonics Filter: – 20, 24, and 30 in. (508, 610, and 762 mm) Fans:
Connect the power cord to the harmonics filter and then to the fan.
– 36 in. (914 mm) Fans: Connect the power cord to the harmonics
filter and then to the fan. – Fan with Occupancy Sensor* and
Harmonics Filter: – 20, 24, and 30 in. (508, 610, and 762 mm) Fans:
Connect the power cord to the harmonics filter, then to the
occupancy sensor, and then to the fan. – 36 in. (914 mm) Fans:
Connect the power cord to the harmonics filter, then to the
occupancy sensor, and then to the fan. – POWER WIRING: 277 V FANS:
– Single Phase (L1 + L2 + PE): Connect the supply power to L1/AC
Line, L2/AC Line, and Earth/PE. – Single Phase (L1 + N + PE):
Connect the supply power to L1/AC Line, AC Neutral, and Earth/PE.
Note: Occupancy sensor not applicable to 277 V fans. Product
Certification:
– Conforms to UL 507: Electric Fans – Certified
to CSA C22.2 No. 113: Fans & Ventilators

Quick Installation Guide AirEye®

READ AND SAVE THESE INSTRUCTIONS

Operating Instructions and Maintenance:
bigfans.com/support

CAUTION: To reduce risk of personal injury, use only with mounting assembly models 007180, 007262, 009182, 007265, and 008001 manufactured by Big Fans.
TECHNICAL SPECIFICATIONS

Fan Size

Fan Weight*

Input Power

Max Amps

Max Power

20 in. (508 mm)

32 lb (14.5 kg)

100­120 VAC, 1, 50/60 Hz 200­240 VAC, 1, 50/60 Hz
277 VAC, 1, 50/60 Hz

5.1 A 3.1 A 3.1 A

386 W 392 W 508 W

24 in. (610 mm)

38 lb (17.2 kg)

100­120 VAC, 1, 50/60 Hz 200­240 VAC, 1, 50/60 Hz
277 VAC, 1, 50/60 Hz

5.2 A 3.1 A 3.0 A

396 W 400 W 501 W

30 in. (762 mm)

45 lb (20.4 kg)

100­120 VAC, 1, 50/60 Hz 200­240 VAC, 1, 50/60 Hz
277 VAC, 1, 50/60 Hz

5.0 A 3.0 A 3.1 A

384 W 390 W 508 W

36 in. (914 mm)

67.1 lb (30.4 kg)

110­120 VAC, 1, 50/60 Hz 200­240 VAC, 1, 50/60 Hz
277 VAC, 1, 50/60 Hz

9.7 A 5.5 A 4.5 A

*Includes fan motor, blades, and cage assembly.

711 W 669 W 716 W

PARTS AND HARDWARE

Front Guard

Hinge Pin Eyelets Blade Assembly

(2) Set Screws*

(4) Flange Nuts**

Rear Guard

(4) Motor ThruBolts
Main Mounting Hardware

Blade Assembly Retainer

(4) Keyhole Mounting Slots

Angle Adjustment Hardware***

(4) Safety Hinge Pins

*Pre-mounted to blade assembly. **Pre-mounted to motor thru-bolts. ***Spare hardware included.
Harmonics filter not shown. Not included for all regions. Install if included.
Safety cable not shown.

1. MOTOR
Make sure fan mount has been installed as specified in the mounting instructions. To adjust motor angle, loosen main mounting bolt and angle adjustment bolt.

1/2-13 Flange Nylock Nut 1/4-20 Flange Nylock Nut

30 ft·lb (40.7 N·m) 1/2-13 x 1-1/4″ Main Mounting Bolt 1/4-20 x 7/8″ Angle Adjustment Bolt 7 ft·lb (9.5 N·m)

2. HARMONICS FILTER (36 IN. [914 MM] FANS)
Select regions only. Install if included with your fan.
Flange Nut

3. REAR GUARD
Align Mounting Slots

Secure Guard

2.5 ft·lb (3.4 N·m)

4. BLADE ASSEMBLY
Ensure blade assembly is fully seated onto shoulder of shaft and set screws are aligned to flats of shaft.
5/32″ (4 mm) 20 ft·lb (27.1 N·m)
IMPORTANT: Always install retaining ring.

5. FRONT GUARD
Align Eyelets
Fasten Hinge Pins Start with topmost hinge.

6. SAFETY CABLE
Do not attach safety cable to fan mount under any circumstances.
7. HARMONICS FILTER (20, 24, AND 30 IN. [508, 610, AND 762 MM] FANS)
Select regions only. Install if included with your fan.

ELECTRICAL CONNECTIONS
Fan Only

Fan with Occupancy Sensor*

Occupancy Sensor

Power Cord Controller or Automation and Multi-Fan Kit

Power Cord Controller or Automation and Multi-Fan Kit
*Occupancy sensor not applicable to 277 V fans.

ELECTRICAL CONNECTIONS: FAN WITH HARMONICS FILTER

20, 24, and 30 in. (508, 610, and 762 mm) Fans

36 in. (914 mm) Fans

Harmonics Filter

Power Cord

Harmonics Filter

Power Cord

Controller or Automation and Multi-Fan Kit

Controller or Automation and Multi-Fan Kit

ELECTRICAL CONNECTIONS: FAN WITH OCCUPANCY SENSOR* AND HARMONICS FILTER

20, 24, and 30 in. (508, 610, and 762 mm) Fans
Harmonics Filter
Power Cord

36 in. (914 mm) Fans Harmonics Filter

Power Cord

Occupancy Sensor

Controller or Automation and Multi-Fan Kit

*Occupancy sensor not applicable to 277 V fans.

POWER WIRING: 277 V FANS
Single Phase (L1 + L2 + PE)
Supply Power
L1/AC Line L2/AC Line
Earth/PE

Single Phase (L1 + N + PE)
Supply Power
L1/AC Line AC Neutral
Earth/PE

Occupancy Sensor

Controller or Automation and Multi-Fan Kit

Fan Power Cable
Black White Green
Fan Power Cable
Black White Green

AIE-INST-321-ENG-01 REV H 03/31/2022

Conforms to UL 507: Electric Fans Certified to CSA C22.2 No. 113: Fans & Ventilators
