AWV4-CO-4HDD Q5 High-End Video Wall Controller
Product Information: High-End Video Wall Controller
The High-End Video Wall Controller by ANGUSTOS is a
high-performance video processing equipment with a hardware
architecture design. It eliminates the need for high-end computer
specifications, graphic processing units (GPU Cards), licenses, and
the risk of blue screen OS crashes, viruses, and ransomware. The
controller supports up to 152 input x 144 output (20U Chassis) and
utilizes a dedicated Field Programmable Gate Array (FPGA) chipset
for efficient video processing.
The FPGA chipset allows for independent operation of each FPGA
chip, enabling seamless addition or replacement of input/output
cards without turning off the entire chassis. The module design
with hot swap feature offers multiple connection options such as
HDMI, DVI, VGA, HDBaseT, and IP Streaming, allowing users to
customize their system integration. This reduces the total cost of
investment in both pre and post-expansion phases. The chassis also
supports control of multiple video walls, simplifying connections
and management.
Product Usage Instructions:
To use the High-End Video Wall Controller effectively, follow
these steps:
- Connect the necessary input sources (HDMI, DVI, VGA, HDBaseT,
IP Streaming) to the corresponding input cards. - Connect the output devices (monitors or displays) to the HDMI
output card. - Power on the Video Wall Controller by connecting it to a
reliable power source. - Use the front panel touch screen to control various
settings:
- Control scene modes by selecting different presets.
- Save and recall profiles for quick configuration changes.
- Configure IP settings for network connectivity.
Drop feature:
- Click on the desired content or input source.
- Drag it to the desired position on the video wall.
- Drop the content to set its position.
features:
- Overlap: Overlay multiple content layers on the video
wall. - Roaming: Move content across different sections of the video
wall. - Stretching: Adjust content size to fit specific sections of the
video wall. - Zoom in/out: Enlarge or reduce the size of content on the video
wall. - Background Image & Scrolling Text: Set a static background
image and display scrolling text for additional visual
elements. - Scheduling: Configure scene mode scheduling for timed
transitions or advertising purposes.
For detailed specifications and compatibility information, refer
to the product documentation provided by ANGUSTOS.
For any further assistance or troubleshooting, visit the
official website at www.angustos.com or contact customer
support.
High-End
Video Wall Controller
ANGUSTOS
MULTIPLE LAYERS FPGA VIDEOWALL CONTROLLER
Hardware Based Design
High performance video processing equipment with hardware architecture design.
No more computer high-end specification. No more high-end Graphic Processing Unit (GPU Card). No more licenses. No more blue-screen OS crash. No more viruses and black screen. No more ransomwares, lost data. Support up to 152 input x 144 output (20U Chassis)
FPGA Dedicated Chipset
Dedicated Field Programmable Gate Array (FPGA) chipset is a combination of processing unit that dedicated in video processing. This eliminated the limitation of a CPU or a GPU from conventional Software or PC controller.
Without the use of PCI – Express card, the unit can work flawlessly when adding or editing the total layout of the videowall set up. As each of the FPGA chip is working independently, user can replace or add new input / output card without turning off the whole chassis.
Module design with Hot Swap
Multiple form of connections for client to custom fit their system. Client can now combine HDMI – DVI – VGA – HDBaseT – IP Streaming
in one total solution, maximizing system integration.
Reduce the total cost of investment in both pre & post phase of expansion. Chassis also support control multiple videowalls, further simplify
the complexity of connections and management.
Features
High-end Multi Layers MPiPTM – Cross Screen
Support up to 4 Layers Matrix Picture in Picture (MPiPTM) in each screen
Easy control with Drag & Drop
Customize complex layout with simple Click – Drag – Drop
High-end Video Wall Control
Support Overlap, Roaming, Stretching, Zoom in / out.
Front Panel Touch Screen
Control scene mode, save / recall profile, IP setting with just a touch
IP Camera Direct Stream (iDirect StreamTM)
IP input Card can support streaming video feed direct from IP CCTV Cameras.
Background Image – Scrolling Text – Scheduling
Support Static Background Image and Scrolling Text for Bank and Stock house Video Wall Support scene mode Scheduling – Cycle for advertising – digital signage Video Wall
21
1
2
WWW.ANGUSTOS.COM
ANGUSTOS
AWV4-CO-4HDD
VIDEO WALL INPUT CARD Multi Layers HDMI Output Card
Features
ASIC video chipset Modular Design – Hot swap Seamless Switching Bezel Compensation MPiPTM – Multiple Layers 1920 x 1200 @ 60Hz Image Cropping Character Superimpose CE / FCC / RoHS Complied Auto – Program EDID
SPECIFICATION
Protocol Input Card Interface Resolution Support Pixel Clock Compliance Control Data Rate Clock Jitter Rise time Fall time Max Delay Signal Strenght Singal Level Impedance EDID Maximum DC bias Signal Level HDCP
HDMI 1.3 4 x HDMI Female 1920 x 1200 @ 60Hz (Max) 165 / 340 MHz (Max) HDMI 3D – Deep Color – 4K – CEC Internal Bus with Chassis ASIC 10.2 Gbps (3.4Gbps per lane) <0.15 Tbit <0.3Tbit (20%-80%) <0.3Tbit (20%-80%) 5 nano Second (nS) ±1nS T.M.D.S. +/- 0.4Vpp T.M.D.S. 2.9V min /3.3V max 50 Default EDID – EDID Programming 15mV T.M.D.S 2.9V / 3.3V Support HDCP 1.3 / 1.4
Scaler Hot-swap Color Depth RGBA Multiple Layers Weight Power Consumption
ANGUSTOS
Built-in Scaler Support 8 bits per channel. Total 32bit/pixel Support – 4 layers MPiPTM About 500g About 15W
Website: http://www.angustos.com Email: [email protected]
