Serenelife Ipcamhd82eu 1080p Ip Camera User Manual

• In the app, go to “Device List” and click on the “+” icon at
  the top left corner.
• Scan the device ID QR code.

• Choose either Method 1 or Method 2 for setup.
• Method 1: Wired Setup
  • Connect the power and Ethernet cable to the camera.
  • Wait for the WiFi indicator on the front of the camera to flash
    green.
  • After scanning the QR code, select the Ethernet Connection
    option.
• Method 2: Wireless Setup
  • Wait for the WiFi indicator on the front of the camera to flash
    red and green alternating.
  • Click the Wi-Fi connection icon and follow the app instructions
    to connect to your network.

• After setting up your camera on the mobile phone, you can use
  your account username and password to access the cameras from any
  device with an internet browser.
• Log on to the website: http://cloud.serenelifehome.com/

• If you forget a camera’s individual password, you can reset it
  by performing a hardware reset using a pin to press and hold the
  reset switch for 12-15 seconds. The camera will reboot and run
  through pan and tilt.
• If you forget your account password, you will need to register
  a new account and pair the cameras again. Accounts are not
  associated with an email address for password recovery.

• The main screen is your device list, where you can see a
  thumbnail preview for all cameras added to your account.
• In the app settings, you can change your user admin and guest
  password and check the app software version.
• You can add your cloud camera to your account through the
  icon.
• The alarm messages section shows which cameras have detected
  motion.
• You can activate sound and microphone to hear and talk through
  your camera’s speaker, respectively.
• The “Snap Photo” option saves a photo to your phone’s local
  memory.

I PCAMHD8 2 EU
1080p IP Camer a
HD WiFi Cam, Remote Video Monitoring Surveillance Security, Built-In Speaker & Microphone, Smartphone App Control

TABLE OF CONTENTS:

PRODUCT STRUCTURE DIAGRAM

1

SETUP AN ACCOUNT USERNAME

2

ADD CAMERA TO APP

3

CONNECT TO YOUR NETWORK

4

WEB ACCESS

5

PASSWORDS

5

MOBILE APP LAYOUT

5

CAMERA VIEW PAGE

7

CAMERA RECORDINGS

8

DEVICE SETTINGS

9

RECORDING YOUR CAMERA

10

MOTION DETECTION

AND NOTIFICATION SETTINGS EXPLAINED

11

HOW TO IMPROVE PLAYBACK PERFORMANCE

12

DECREASE THEVIDEO STREAM QUALITY

13

HOW TO EVALUATE YOUR HOME WIRELESS NETWORK

14

HOW TO CHECK AND INSTALL FIRMWARE UPDATES

15

TROUBLESHOOTING

17

FEATURES AND TECHNICAL SPECS

19

www.SerenLifeHome.com

Product Structure Diagram
1
www.SerenLifeHome.com

Don’t forget to register your camera with us online to get a free 1 year manufacturer’s warranty! Just go to www.SereneLifeHome.com
`SereneViewer’ APP Installation
A. Scan ‘SereneViewer’ APP QR code or search to download the app.

iOS

Andriod

Setup an Account Username

Click “Sign Up”

Create your camera username – 6 characters min
– Do not use email address

Note:

This user name will be used to access all of your cameras from the app or PC.

2
www.SerenLifeHome.com

Create an account password – Click “Sign Up” Note: This will be used to log in to all of the cameras on your account and can be separate from the camera password
Add Camera to APP
1. Enter ‘Device List’ and click ‘+’ icon at the top of left corner. Then scan the device ID QR code.
3
www.SerenLifeHome.com

Connect to Your Network
Choose method 1 or 2 for setup Method 1: Wired Setup -Connect power, Ethernet cable as above. -Wait 50 seconds for ( ) indicator on the camera to flash green -After scanning QR code – select the “Ethernet Connection” option
Mo d e n /R o u te r

Method 2: Wi-Fi Connection · Make sure you are in the same room as your wireless router and plug camera into power. QR Code Method: · Wait 1-2 min for camera boot up, scanning QR Codewatch for the
WiFi indicator on the front of the camera to flash red and green alternating. Click the Wi-Fi connection icon,operate it under the APP instructions.
R outer
P ower

4
www.SerenLifeHome.com

P hone

Web Access: After setting up your camera on the mobile phone – you can use your account username and password to access the cameras from any device with an internet browser Log on to the website: http://cloud.serenelifehome.com/
Passwords Should you happen to forget a camera’s individual password you can reset it by performing a hardware reset. Just use a pin to press and hold the reset switch for 12 – 15 seconds. The camera will reboot and run through pan and tilt.
If you forget your account password you will need to register a new account and pair the cameras again.
Accounts are never associated with an email address for password recovery
5
www.SerenLifeHome.com

Mobile App Layout The main screen is your device list. You will see a thumbnail preview for all cameras added to your account.

Use this menu to · Switch between different cameras · Add new devices · Access and change app global settings

App Settings You can change your user admin and guest password and check the app software version.

Add Device Add your cloud camera to your account through the icon.

Alarm Messages Shows which cameras have detected motion.

6
www.SerenLifeHome.com

Camera View Page This page give you access to all camera specific actions and settings · Hold the phone vertically or horizontally to switch between full
screen mode · Swipe left and right on the video to reposition the camera · Spread two fingers apart to zoom in

Sound Activate to hear your cameras surroundings Microphone Activate to talk through your camera’s speaker. Snap Photo Saves a photo to your phone’s local memory
View the Video Records and alarm messages Click the icon to view the video recording and alarm message.

Image Settings Set color, contrast, image res and more.
Local Video Records the live video direct to phone memory. This feature only works
while app is open. See “SD recording” for background recording
options.

7
www.SerenLifeHome.com

Camera Recordings Enter into the interface of “information and video viewing” can see the alarm information and video of storage device (Micro SD or cloud box), users can quickly search the information and video by choose the time or category.

Records Shows photos and videos stored on the SD memory card. Drag the screen down to load.

Local Shows photos and videos recorded to the phone memory
Calendar Icon Skip to a specific
date and time..

8
www.SerenLifeHome.com

Device Settings This screen allows you to check and set camera specific settings. If you see the red dot icon – a firmware update is available. Install available firmware updates to ensure the camera features are working as intended.

About Check the camera’s software version and ID number.
Storage Device Connecting Cloud Box for storage
Schedule Recording Set the recording schedule start and end time.

Network Can set up the
camera Wi-Fi connection
Motion and Notification
Set the motion detection alarm.

9
www.SerenLifeHome.com

Recording Your Camera You can choose 3 options for storing recordings for your camera
1) Local storage This is the most simple method – just point and shoot. This only works while The phone app is open and running and will take up memory on your phone.
2) SD storage Install an SD card and open up a world of possibilities! Choose between scheduled recording, motion detection triggered recording or just let it run! The oldest videos will be overwritten to make room for the newest. You can download and save the videos from the mobile or website.
3) CloudBox storage Sometimes SD storage just doesn’t cut it. With a limit of 32g and the fact that the videos are stored directly in the camera – many people prefer the peace of mind the CloudBox can bring. Purchase the cloud box and back up 2TB of video storage from any device on a single network and check the videos from the same login. Find the CloudBox for sale on Amazon now! Search “SereneLife CloudBox”
10
www.SerenLifeHome.com

Motion Detection and Notification Settings Explained You can set notification settings separately for any camera in your account. To access the notification settings, select your camera, and go to the settings tap – then scroll down to “motion detection”
Slide the slider to enable motion detection You can then choose what actions you would like to occur when your camera detections motion. Recordwill record video to the SD card while the camera detects motion. You can also turn push notifications on and off by selecting “turn alert on” or “turn alert off”.
11
www.SerenLifeHome.com

If you are finding your camera is alerting you needlessly or failing to alert you if someone is moving, you can adjust the sensitivity for motion detection for the camera. Go to “settings” > “Motion Sensitivity” and adjust the sliders for day and night seperately How to Improve Playback Performance Choppy video? Try the following to ease up the demands for data on your camera… Decrease the Video Stream Quality You can drop the resolution setting for the camera to make it easier on your home network’s bandwidth.
12
www.SerenLifeHome.com

Just open up the setting here and adjust until you get the desired performance level.
Plug your camera into a wired data connection Do some tests before throwing in the towel for using the camera wirelessly But the facts remain – wires are still quicker… How to evaluate your home wireless network Evaluate your wireless network Cameras having trouble with wireless? You may want to consider upgrading your wireless network.
13
www.SerenLifeHome.com

Lets do a basic evaluation of your home wireless network. First, we recommend comparing your network speed with your wireless speed.
1. Run a speedtest from a laptop of desktop connected to your router with a wired connection. http://www.speedtest.net/
2. Compare this value to your wireless network apps like “Speed Test” to see if you have enough available data in the area you would like to set the camera.
3. Test your network range · What is your download speed in the same room as your wireless router? · What is the download speed in the location you are trying to install the camera? · Is there a significant drop?
What to upgrade? 1. If your wired connection is too slow to reach the bandwidth
requirements of the camera you may need to consider upgrading your internet service. 2. If you have a significant drop in data when testing a wireless connection in the same room as your router, you may want to consider upgrading to a router that can provide higher data transmission speeds 3. If you see a significant drop in data when testing in the area you want to install your camera you can either look for an upgraded router that will offer additional range or you can expand your router range with a signal booster.
How to check and install firmware updates Firmware updates ensure our new features will work 100% for your camera. It is a good idea to install them when you see they are available.
14
www.SerenLifeHome.com

It is reccomended that you install updates while on a wired connection to your router. This will ensure loss of bandwith is not an issue during updates
To check and install firmware updates

1. Tap the device preview image

2. Look for red dot indicating firmware update available – then enter settings

15
www.SerenLifeHome.com

3. Scroll down to “System Settings” 4. Select Upgrade – then confirm 5. Now wait for the upgrade to proceed · It can take 5 – 10 minutes · Do not quit the app or modify the camera hardware
16
www.SerenLifeHome.com

6. Once complete – the app will tell you to restart the camera · However it should automatically restart itself · Wait 2-3 minutes for the camera to restart before checking the camera feed or settings
7. Check if any additional updates are available · Sometimes there will be multiple updates available in a row. Repeat the process until no new updates are available
Desktop access link: http://cloud.serenelifehome.com/
Other issues? Check our FAQ resources and contact support online!
www.SereneLifeHome.com
Compatible Products:
You can add any number of SereneLife cameras to your account with us to monitor multiple locations!

IPCAMHD12 IPCAMHD15

IPCAMHD61

IPCAMHD82

Troubleshooting
Can’t connect to WiFi · Connect the ethernet cable and check connection is working · Go to “camera settings” > “network” Check the WiFi status is enabled and “List” displays your home network – doublecheck the password. · In the Ethernet tab – disable the ethernet connection to force the camera to look for available WiFi network

17
www.SerenLifeHome.com

Still having trouble? · Try deleting the camera entry from your account · Hardware rest the camera · Add the camera as a new device
SD Card is not recognized by the camera · Check the card is class 10 – 32g or less · Insert the card while the camera is powered down then power up · Try reformatting the card using your computer using “FAT32” · Test multiple SD cards
App is crashing – a feature is not working · Check for app updates · Check for camera firmware updates · Contact support with app version, mobile device model and OS version so we can update the app and fix the issue
Features:
· Full HD 1080p Video Camera Display Output · Ability to Snap Pictures and Record Video · Wi-Fi Wireless Network Connectivity · Connect with Your Smartphone, Tablet, Laptop, Computer, etc. · Monitor the Location Remotely and Control Via “SereneViewer” App · Built-In Microphone and Speaker for 2-Way Communication · Audio Record Schedule Timer: Video Recording While Away · Can be Hard-Wired & Mounted, LAN (Ethernet Cable) · Mountable for Safety/ Security Surveillance · Micro SD Memory Card Reader · Night Vision LED Illumination Lights · Motion Detector Recording Mode · Real-Time App Push Notification Alerts · P2P Technology: Plug and Play Setup · Image Adjustments Configuration Option · Lightweight and Compact Design
18
www.SerenLifeHome.com

· LED Indicator Status Lights · Perfect at Home or in the Office · Works for PC and Mac
The “SereneViewer” App:
· Free to Download & Easy-to-Use · Gives you Remote Access to Live or Recorded Video · Works with All of Today’s Latest Smartphones & Tablets · Camera Management: Control, View & Add Additional Cameras · Scheduled Recording: Set the Timer for Automatic Start Times · Configurable Picture Adjustment Settings
Technical Specs:
· Imaging Sensor: 1/4″ Color CMOS · Video Resolution: 1080p (1920 x 1080 Pixels @ 30 FPS) · Video File Format MJPEG, H.264 · Night Vision Distance 32″ + ft. (0.01 LUX) · Wi-Fi Wireless Network: IEEE802.11b/g/n · Protocols: TCP/IP, UDP/IP, HTTP, DHCP, RTMP, MUTP · Ethernet Network: 10/100Mbps, RJ-45 Interface · P2P Technology Plug and Play · Dynamic Code Rate Filtering Jitter Buffer · Maximum Micro SD Card Support Size: 64GB · Lighting Frequency: 50/60Hz · Video Compression: H.264 · Audio Compression: AAC (Advance Audio Coding) · Power Supply: DC 5V, 2 A · Dimensions (L x W x H): 3.3″ x 3.3″ x 4.7″ · Sold as: 1
19
www.SerenLifeHome.com
