BeNext
Panic Watch
SKU: BENEPANIC
Quickstart
This is a
Panic Button
for
Europe.
To run this device please insert fresh 1 * CR2450 3.0V batteries.
Please make sure the internal battery is fully charged.
To add this device to your network execute the following action:
Press and hold the SOS push button until the indicator light starts blinking. Then release the button to start the inclusion process.
(Note: Normally button should be pressed for 2 seconds but in case the product is already included it can take up to 12 seconds before the indicator light will start blinking.)
Important safety information
Please read this manual carefully. Failure to follow the recommendations in this manual may be dangerous or may violate the law.
The manufacturer, importer, distributor and seller shall not be liable for any loss or damage resulting from failure to comply with the instructions in this manual or any other material.
Use this equipment only for its intended purpose. Follow the disposal instructions.
Do not dispose of electronic equipment or batteries in a fire or near open heat sources.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This
device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way
communication) and every mains powered node can act as a repeater for other nodes
(meshed network) in case the receiver is not in direct wireless range of the
transmitter.
This device and every other certified Z-Wave device can be used together with any other
certified Z-Wave device regardless of brand and origin as long as both are suited for the
same frequency range.
If a device supports secure communication it will communicate with other devices
secure as long as this device provides the same or a higher level of security.
Otherwise it will automatically turn into a lower level of security to maintain
backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer
to www.z-wave.info.
Product Description
The Panic Watch is similar to the Panic Button, except for that this watch can be worn as a wristband. The Panic Watch is used within the Safety Services. With the Panic Watch you are able to send a message automatically to a preconfigured e-mail address. Actions from the Panic Watch can be programmed freely.” The Panic Watch will operate on a single built-in battery. The expected lifetime is four years and a low battery signal will be send automatically.
Prepare for Installation / Reset
Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default
state. Please make sure to reset the device into factory default. You can do this by
performing an Exclusion operation as described below in the manual. Every Z-Wave
controller is able to perform this operation however it is recommended to use the primary
controller of the previous network to make sure the very device is excluded properly
from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This
procedure should only be used when the primary controller is inoperable.
Set Parameter 1 to value 255
Safety Warning for Batteries
The product contains batteries. Please remove the batteries when the device is not used.
Do not mix batteries of different charging level or different brands.
Installation
Inclusion/Exclusion
On factory default the device does not belong to any Z-Wave network. The device needs
to be added to an existing wireless network to communicate with the devices of this network.
This process is called Inclusion.
Devices can also be removed from a network. This process is called Exclusion.
Both processes are initiated by the primary controller of the Z-Wave network. This
controller is turned into exclusion respective inclusion mode. Inclusion and Exclusion is
then performed doing a special manual action right on the device.
Inclusion
Press and hold the SOS push button until the indicator light starts blinking. Then release the button to start the inclusion process.
(Note: Normally button should be pressed for 2 seconds but in case the product is already included it can take up to 12 seconds before the indicator light will start blinking.)
Exclusion
Press and hold the SOS push button until the indicator light starts blinking. Then release the button to start the exclusion process.
(Note: Normally button should be pressed for 2 seconds but in case the product is already included it can take up to 12 seconds before the indicator light will start blinking.)
Product Usage
Basic operations
How it operates
Use
3. Don’t forget to update and syncronize your rules in the Internet Gateway.
7. No association is set: indicator light blinks 6 times rapidly
This mode is mainly used to notify a controller of an alarm or trigger an alarm on a Z-Wave supported alarm device.
When double pressed: quickly (within 500 msec.) double press the button.
Communication to a Sleeping device (Wakeup)
This device is battery operated and turned into deep sleep state most of the time
to save battery life time. Communication with the device is limited. In order to
communicate with the device, a static controller C is needed in the network.
This controller will maintain a mailbox for the battery operated devices and store
commands that can not be received during deep sleep state. Without such a controller,
communication may become impossible and/or the battery life time is significantly
decreased.
This device will wakeup regularly and announce the wakeup
state by sending out a so called Wakeup Notification. The controller can then
empty the mailbox. Therefore, the device needs to be configured with the desired
wakeup interval and the node ID of the controller. If the device was included by
a static controller this controller will usually perform all necessary
configurations. The wakeup interval is a tradeoff between maximal battery
life time and the desired responses of the device. To wakeup the device please perform
the following action:
Press and hold the Panic Watch for 14 seconds.
Quick trouble shooting
Here are a few hints for network installation if things dont work as expected.
- Make sure a device is in factory reset state before including. In doubt exclude before include.
- If inclusion still fails, check if both devices use the same frequency.
- Remove all dead devices from associations. Otherwise you will see severe delays.
- Never use sleeping battery devices without a central controller.
- Dont poll FLIRS devices.
- Make sure to have enough mains powered device to benefit from the meshing
Association – one device controls an other device
Z-Wave devices control other Z-Wave devices. The relationship between one device
controlling another device is called association. In order to control a different
device, the controlling device needs to maintain a list of devices that will receive
controlling commands. These lists are called association groups and they are always
related to certain events (e.g. button pressed, sensor triggers, …). In case
the event happens all devices stored in the respective association group will
receive the same wireless command wireless command, typically a ‘Basic Set’ Command.
Association Groups:
Group NumberMaximum NodesDescription
| 1 | 8 | If configuration parameter 4 configured with value 0 then this group is used” – SOS button: send ALARM_REPORT. If configuration parameter 4 configured with value other then 0 (1-255) then this group is used” – SOS button: send BASIC_SET, 0xFF. |
| 2 | 8 | Not used on application. |
Configuration Parameters
Z-Wave products are supposed to work out of the box after inclusion, however
certain configuration can adapt the function better to user needs or unlock further
enhanced features.
IMPORTANT: Controllers may only allow configuring
signed values. In order to set values in the range 128 … 255 the value sent in
the application shall be the desired value minus 256. For example: To set a
parameter to 200 it may be needed to set a value of 200 minus 256 = minus 56.
In case of a two byte value the same logic applies: Values greater than 32768 may
needed to be given as negative values too.
Parameter 1: Set to default
Set all configuration values to default values (factory settings).
Size: 1 Byte, Default Value: 0
SettingDescription
| 0 | disable |
| 255 | set to default |
Parameter 2: Time to press the Panic Watch
The time that the panic pushbutton must be pressed before a (panic) message is sent out to the controller.
Size: 1 Byte, Default Value: 1000
SettingDescription
| 0 | Send directly the panic message when pressed |
| 1 – 255 | Send a panic message after you keep holding the button pressed for this value x 10ms. |
Parameter 3: Min. led feedback time panic
Minimum time that led feedback is shown after a panic message.
Size: 1 Byte, Default Value: 100
SettingDescription
| 0 | Led only stays on during the ‘send time’. |
| 1 – 233 | Led stays on during send time + this value*10ms. |
With this config parameter you can map the buttons to send different Z-Wave messages.
Size: 1 Byte, Default Value: 255
SettingDescription
| 0 | SOS button sends an ALARM_REPORT to nodes group 1 |
| 1 – 255 | SOS button sends an BASIC_SET, 0xFF to nodes group 1 |
Technical Data
| Dimensions | 46 x 46 x 15 mm |
| Weight | 33.6 gr |
| EAN | 0632181493748 |
| IP Class | IP 21 |
| Voltage | 3V |
| Battery Type | 1 * CR2450 3.0V |
| Device Type | Panic Button |
| Generic Device Class | Binary Sensor |
| Firmware Version | 00.20 |
| Z-Wave Version | 03.2a |
| Z-Wave Product Id | 0x008a.0x0015.0x0101 |
| Frequency | Europe – 868,4 Mhz |
| Maximum transmission power | 5 mW |
Supported Command Classes
- Basic
- Sensor Binary
- Configuration
- Alarm
- Manufacturer Specific
- Battery
- Wake Up
- Association
- Version
Controlled Command Classes
- Basic
Explanation of Z-Wave specific terms
- Controller — is a Z-Wave device with capabilities to manage the network.
Controllers are typically Gateways,Remote Controls or battery operated wall controllers. - Slave — is a Z-Wave device without capabilities to manage the network.
Slaves can be sensors, actuators and even remote controls. - Primary Controller — is the central organizer of the network. It must be
a controller. There can be only one primary controller in a Z-Wave network. - Inclusion — is the process of adding new Z-Wave devices into a network.
- Exclusion — is the process of removing Z-Wave devices from the network.
- Association — is a control relationship between a controlling device and
a controlled device. - Wakeup Notification — is a special wireless message issued by a Z-Wave
device to announces that is able to communicate. - Node Information Frame — is a special wireless message issued by a
Z-Wave device to announce its capabilities and functions.
