GT2160HDR First 4K UHD Short-throw Cinema Gaming Projector

Product Information: Optoma GT2160HDR

The Optoma GT2160HDR is a 4K UHD short-throw cinema gaming
projector that provides an immersive gaming experience on a screen
of up to 300 inches. It offers different display options for
optimized performance in cinema mode, gaming mode, or 3D mode,
delivering images and motions with ultimate smoothness and
clarity.

Specifications:

• Display technology: DLPTM
• Resolution: UHD (3840×2160)
• Brightness: 4,000 lumens
• Contrast ratio: 1,200,000:1
• Native aspect ratio: 16:9
• Aspect ratio – compatible: 4:3,16:9,16:10
• Keystone correction horizontal
• Keystone correction – vertical: Horizontal scan rate
• Vertical scan rate: 24 ~ 120Hz
• Uniformity: 80%
• Screen size: 0.93m ~ 7.63m (36.43 ~ 300.53) diagonal
• Lamp info: Lamp
• Light source type: Lamp
• Lamp life hours (up to): 4000 (Bright), 15000 (Dynamic),10000
  (Eco)
• Optical Throw ratio: 0.49:1
• Projection distance: 0.4m – 3.3m
• Zoom: 1 Fixed
• Zoom type: 7.51mm Vertical +0% 116%
• Focal length
• Lens shift: Native offset
• Connectivity: 2 x HDMI 2.0 Inputs, 1 x Audio 3.5mm Output, 1 x
  S/PDIF Output, 1 x USB-A power Output (1.5A), 1 x RS232 Input, 1 x
  12V trigger Input
• Noise level (typical): 27dB
• Noise level (max): 28dB
• PC compatibility: UHD, WUXGA, FHD, UXGA, SXGA, WXGA, HD, XGA,
  SVGA, VGA, Mac
• 2D compatibility: 480i/p, 576i/p, 720p(50/60Hz),
  1080i(50/60Hz),1080p(50/60Hz), 2160p(50/60Hz)
• 3D compatibility: Frame
  Packing(1280×720@50Hz/60Hz,1920×[email protected]/24Hz), Frame
  Sequential(800×600@120Hz,1024×768@120Hz,1280×800@120Hz,1920×1080@120Hz),
  Side by Side(1920×1080@50(25)Hz,1920×1080@60(30)Hz)
• 3D Security: Security bar, Kensington Lock, Password protected
  interface
• OSD / display languages: 11 languages: Dutch, English, French,
  Italian, Japanese, Portuguese, Russian, Chinese (simplified),
  Spanish, Chinese (traditional)
• Operating conditions: humidity 85%
• Remote control: Backlit home remote
• Speaker count: 1
• Watts per speaker: 10W
• In the box: AC power cord, Remote control, Basic user
  manual
• Input lag: 4.00ms
• Power supply: 100 ~ 240V, 50 ~ 60Hz
• Power consumption (standby): 0.5W
• Power consumption (min): 210W
• Power consumption (max): 330W
• Weight and dimensions: Gross weight: 5 kg, Net weight: 3.8 kg,
  Dimensions (W x D x H): 315 x 270 x 118

Product Usage Instructions:

1. Connect the Optoma GT2160HDR projector to a power outlet using
   the provided AC power cord.
2. Connect the video source to the projector using an HDMI cable
   or other compatible cables.
3. Turn on the projector using the power button on the remote
   control or on the projector.
4. Use the remote control to navigate through the on-screen
   display (OSD) and select the desired input source.
5. To adjust the image size and focus, use the zoom and focus
   rings located on the lens of the projector.
6. To adjust the image position and shape, use the keystone
   correction feature on the OSD or on the remote control.
7. To switch between different display modes (cinema, gaming, or
   3D), use the display mode option on the OSD or on the remote
   control.
8. Enjoy your gaming or cinema experience on a screen of up to 300
   inches!

https://au.optoma.com
GT2160HDR
First 4K UHD Short-throw Cinema Gaming Projector
First 4K UHD Short-throw Cinema Gaming Projector Bright Room Design with Brightness 4,000 lumens & 1,200,000:1 Contrast HDR 10 & HLG Supported for Brightest Whites, Deepest Darks, and Lifelike Colors Ultimate Gaming Experience supporting lightingfast 240Hz refresh rate, and low 4ms Input Lag in Enhanced Gaming Mode Featuring the lightning-fast refresh rate and the low input lag, GT2160HDR is perfectly quenching your desire for the ultimate home entertainment, no matter in movie watching or gaming. With true 4K UHD resolution, GT2160HDR will bring the immersive cinema and
ff gaming experiences up to 300 screen. The di erent display options also allows optimized performance in cinema mode, gaming mode, or
3D mode, delivering images and motions with ultimate smoothness and clarity.

fi Speci cations
Display/image Display technology Resolution Brightness Contrast ratio Native aspect ratio Aspect ratio – compatible Keystone correction horizontal Keystone correction – vertical Horizontal scan rate Vertical scan rate Uniformity Screen size Lamp info Light source type Lamp life hours (up to) Optical Throw ratio Projection distance Zoom Zoom type Focal length Lens shift
ff Native o set
Connectivity Connections
General Noise level (typical) Noise level (max) PC compatibility
2D compatibility
3D compatibility
3D Security OSD / display languages
Operating conditions
Remote control Speaker count Watts per speaker In the box
Input lag Power Power supply Power consumption (standby) Power consumption (min) Power consumption (max) Weight and dimensions Dimensions (W x D x H) Gross weight Net weight

DLPTM
UHD (3840×2160) 4,000 lumens 1,200,000:1 16:9 4:3,16:9,16:10
+/-20°
+/-20°
31 ~ 135Khz 24 ~ 120Hz 80% 0.93m ~ 7.63m (36.43″ ~ 300.53″) diagonal
Lamp 4000 (Bright), 15000 (Dynamic), 10000 (Eco)
0.49:1 0.4m – 3.3m 1 Fixed 7.51mm Vertical +0% 116%
Inputs 2 x HDMI 2.0 Outputs 1 x Audio 3.5mm, 1 x S/PDIF, 1 x USB-A power 1.5A Control 1 x RS232, 1 x 12V trigger
27dB 28dB UHD, WUXGA, FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz), 2160p(50/60Hz) Frame Packing(1280×720@50Hz/60Hz, 1920×[email protected]/24Hz), Frame Sequential(800×600@120Hz, 1024×768@120Hz, 1280×800@120Hz, 1920×1080@120Hz) , Side by Side(1920×1080@50(25)Hz, 1920×1080@60(30)Hz) 3D ready Security bar, Kensington Lock, Password protected interface 11 languages: Dutch, English, French, Italian, Japanese,
fi Portuguese, Russian, Chinese (simpli ed), Spanish, Chinese
(traditional)
° ° ° ° 5 C~40 C/41 F~104 F, max altitude 3000M/9843ft, max
humidity 85% Backlit home remote 1 10W AC power cord Remote control Basic user manual 4.00ms
100 ~ 240V, 50 ~ 60Hz 0.5W 210W 330W
315 x 270 x 118 5 kg 3.8 kg

© Copyright 2023, Optoma and its logo is a registered trademark of Optoma Corporation. Optoma Europe Ltd is the licensee of the registered trademark. All other product names and company names used fi fi herein are for identi cation purposes only and may be trademarks or registered trademarks of their respective owners.Errors and omissions excepted, all speci cations are subject to change without notice.All
images are for representation purposes only and may be simulated. 03032023100524
