CL2290F10 Flexible PCB Memory Touch Switch Dimmer

Product Information

The Flexible PCB Memory Touch Switch Dimmer CL2290F10 is a
touch-sensitive switch that can be used to control the brightness
of LED lights. It is designed with a flexible printed circuit board
(PCB) that allows it to be bent and shaped to fit different
applications. The switch has a compact size, measuring 50mm in
length, 9.8mm in width, and 2.2mm in thickness.

The switch has a memory function that allows it to remember the
last brightness level set by the user. This means that when the
switch is turned off and then back on again, it will automatically
set the brightness to the last level used.

Product Usage Instructions

1. Connect the switch to the LED light circuit according to the
   wiring diagram provided in the user manual.
2. Ensure that the power supply is turned off before connecting
   the switch.
3. To turn the LED light on or off, simply touch the switch.
4. To adjust the brightness level, touch and hold the switch until
   the desired brightness is reached.
5. The switch will automatically remember the last brightness
   level set by the user and will set the brightness to that level
   when turned on again.
6. To reset the memory function, turn off the power supply and
   then touch and hold the switch for 5 seconds until the LED light
   blinks.

Flexible PCB Memory Touch Switch Dimmer CL2290F10

· Touch switch ON/OFF with dimming and memory. · Input Voltage: 12V-24V DC. · lnput wire outer diameter: 1.9mm MAX · Output Voltage: 12V-24V DC. · LED Strip Width: 10mm · lnput Current: 3A. · Load around 36W for 12V, and 72W for 24V. · Dimension: 50*10mm. · Height of Spring: 20mm.

50mm

9.8mm

2.2mm

10.1mm 11.5mm

4.2mm 10mm
