SPDS3002-105 Outdoor Enclosure for Samsung OH55F

Product Information

Product Name: SPDS3002-105 Outdoor Enclosure
for Samsung OH55F/OH55A/OH55A-S

Version: 1.0

Designed for: Outdoor use

Color: 105 (OUTDOOR – Paint powder 7011-S iron
grey with primer)

Item Net Weight: 144.05 kg | 317.639 lbs

Product Usage Instructions

1. Refer to the assembly instructions on page 2 of the user
   manual.
2. Start by assembling the vertical profiles for the outdoor
   enclosure. These profiles include the right and left sides.
3. Next, assemble the cover and door for the vertical profile
   outdoor enclosure.
4. Attach the reinforcement top plate to the base of the
   enclosure.
5. If you have OH55F/OH55A/OH55A-S screens, assemble the double
   screen enclosure using part number ODC4900560. If required, install
   the air grilles kit for the double enclosure using part number
   ODCB00781.
6. Use the provided installation template (P22-00349) to correctly
   position and mount the outdoor enclosure.
7. For detailed installation instructions, refer to the
   Installation Guide SPDS3002 Outdoor enclosure – Double
   (MK15-0374).

Note: This product is designed for outdoor use. Please ensure
that you follow all safety guidelines and precautions mentioned in
the user manual during installation and usage.

SPDS3002-105
Outdoor enclosure for Samsung
OH55F/OH55A/OH55A-S

Assembly instructions on page 2

Version: 1.0

DESIGNED FOR OUTDOOR USE

ADDITIONAL INFO:

QTY. of configs in master box:

Item Net Weight: 144.05 kg | 317.639 lbs

Colour: 105 (OUTDOOR – Paint powder 7011-S iron grey with primer)

Pallet Capacity:

COPYRIGHT © ERGONOMIC SOLUTIONS 2023

Page 1 of 2

Author: lvh (09-06-2022) | Last Update: Jannik.Jacobsen (05-01-2023)

SPDS3002-105
Outdoor enclosure for Samsung OH55F/OH55A/OH55A-S
Version: 1.0
DESIGNED FOR OUTDOOR USE

3

1

2

4

5

POS PARTS LIST

QTY. DESCRIPTION

BOX

1 ODCB00777

1

Vertical Profile for outdoor enclosure – Right and Left side

2 ODCB00778 3 ODCB00776

1

Cover and door for Vertical Profile outdoor enclosure

1

Reinforcement top plate for base

4 ODC4900560 5 ODCB00781

1

Double Screen enclosure for OH55F/OH55A/OH55A-S screens

2

Air grilles kit for double enclosure

P22-00349

1

Installation template for outdoor enclosure

MK15-0374

1

Installation Guide SPDS3002 Outdoor enclosure – Double

ADDITIONAL INFO:

QTY. of configs in master box:

Item Net Weight: 144.05 kg | 317.639 lbs

Colour: 105 (OUTDOOR – Paint powder 7011-S iron grey with primer)

Pallet Capacity:

COPYRIGHT © ERGONOMIC SOLUTIONS 2023

Page 2 of 2

Author: lvh (09-06-2022) | Last Update: Jannik.Jacobsen (05-01-2023)
