KLED-W-XL-80 KeloXL White LED Pool Light
Product Information
- Product Name: KeloXL LED Light
- Model Number: 99-15532-00
- Dimensions: 10.64 inches (outer diameter)
- Material: PC (Polycarbonate)
- Finish: Not applicable
- UL File Number: Not specified
Product Usage Instructions
- Ensure the excess cord wrap area is managed properly according
to the provided dimensions. - Position the top of the lens 1.25 inches from the pool
wall. - Review any revisions or updates indicated in the user
manual. - Make sure the slot length is 0.53 inches and the slot width is
0.20 inches. - Verify that the slot opening is also 0.53 inches.
- Mount the KeloXL LED Light on the specified application.
- Follow third angle projection guidelines for proper
installation. - Do not reproduce, transfer, disclose, or use any proprietary
information contained in this document without prior authorization
from S.R. Smith. - Refer to the next assembly and any additional instructions
provided. - Unless otherwise specified, all dimensions are in inches.
- Observe the mentioned tolerances during installation.
- This product is made of PC (Polycarbonate) material.
- This drawing should not be scaled.
- Check for any necessary approvals and their respective
dates. - Assembly views are available for reference.
EXCESS CORD WRAP AREA
1.55″
1.25″ TOP OF LENS TO POOL WALL
REVISIONS
REV NPR NO. ZONE DESCRIPTION
A0 901
RELEASE TO PRODUCTION.
DATE
APPROVED
03/11/22 WJS
.53″ SLOT LENGTH
.20″ SLOT WIDTH
.53″ SLOT OPENING
EXCESS CORD WRAP AREA
9.10″ 9.50″
10.64″ OD
THIRD ANGLE PROJECTION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION WHICH SHALL NOT BE REPRODUCED, TRANSFERRED TO OTHER DOCUMENTS, DISCLOSED TO OTHERS, USED FOR MANUFACTURING OR ANY OTHER PURPOSE WITHOUT PRIOR AUTHORIZATION OF S.R. SMITH
NEXT ASSY
USED ON
APPLICATION
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES. TOLERANCES ARE:
FRACTIONS ±
DECIMALS .XX ± .01 .XXX ± .001
ANGLES ±1 °
MATERIAL:
PC
FINISH:
N/A
DO NOT SCALE DRAWING
APPROVALS
DATES
KeloXL LED LIGHT, ASSEMBLY VIEWS
SIZE
B
UL FILE NO.:
–
DWG NO.:
REV.
99-15532-00 A0
SCALE=
NTS
MODIFIED BY:
MFAVORITO
03/11/22
SHEET 1 OF 1
