Angustos Ave-hu120i Hdmi Extender Over Ip User Manual (+ PDF)

Connect the Transmitter (TX) unit to the video source (e.g.,
DVD player, laptop) using an HDMI cable.
Connect the Transmitter (TX) unit to a network switch using a
CAT6 cable.
Connect the Receiver (RX) unit to the display device (e.g., TV,
projector) using an HDMI cable.
Connect the Receiver (RX) unit to a network switch using a CAT6
cable.
Connect the power adapter to both the Transmitter (TX) and
Receiver (RX) units.
Connect the power adapter to a power source (DC 5-12V).
Ensure that the HDMI input/output connections are properly
made.
For longer distances, use additional CAT6 cables and network
switches to extend the range.
Make sure all devices are powered on.
The system will automatically detect and adjust the source
signal.

View Fullscreen

PRO – AV
HI-END SERIES

ANGUSTOS
HIGH-END DIGITAL SIGNAGE SYSTEM

Why choose ANGUSTOS Pro-AV ?
We can provide you the best solution that suits your TVs, interactive screens, meeting room high-end projector, digital signage and videowall system. We do not just simply sell the equipments but also a smart solution that is just as well designed as it is functional. Solutions that guarantee and define our
brand:
·Ease-of-use
·Design
·Innovation
·Reliability
·Ease-of-installation. To help you find the exact solution you need, Angustos has an extensive product range that is possible to compose a solution for nearly every Pro AV application. Our highly skill solution teams are happy to help you to quickly find the best solution for your installation, saving you the time and effort and hassle for complex system.

ANGUSTOS PRO AV APPLICATIONS
Media – Telecom – Broadcast Education – Training Manufacturing – Quality Control Retail – Advertising Meeting Room – Conference Healthcare visual system Entertainment Government – Control Room

WWW.ANGUSTOS.COM

ANGUSTOS

AVE-HU120i

HDMI Extender Over IP – 120 meter over CAT6

Model : AVE-HU120i

FEATURES
HDMI extender up to 120m over single CAT6.

Resolution up to 1920 x 1080P@60Hz.

No compression – No latency

Support Over Ethernet Physical Layer Protocol

Compliance with HDMI 1.2 and HDCP 1.2

H.264 compression encoding

Support multi-cast set up, one TX to 253 RX units.

Simple to install, plug and play.

Auto-match source. Built-in auto adjustment system.

PACKAGE CONTENT
*Transmitter (TX) unit x 1
*Power Adapter x 2

*Receiver (RX) unit x 1

TCP/IP

FULL HD
1080P

120m

SPECIFICATION
Operating Temperature Operating Humidity Video Input Connectors Video Output Connectors
Data Rate / Pixel Clock Resolution Support HDCP Compliance HDMI Compliance

-5o to 70oC 5 to 90%RH 1 x HDMI Type A (TX) 1 x HDMI Type A (TX) 1 x HMDI Type A (RX) 4.95 Gbps / 165MHz 1920x1080p @60Hz HDCP 1.2 HDMI1.2, Deep color

Max Distance Impendance
UTP Compression Power consumtion Power adapter Size (mm)

120m 100
1 x RJ45 (TX) / (RX) H.264 2 W DC 5V – 12V 81 x 45 x 23

CONNECTION DIAGRAM
TX

NETWORK SWITCH

RX 253

Recorder

RX 1

Laptop

DVD

HDMI in

CAT6 60M

DIRECT 120M
