Solarv Es-abs 551 Abs Solar Panel Side Mounting Brackets Instruction Manual

ES-ABS 551 ABS Solar Panel Side Mounting Brackets

Product Information

Product Name: ES-ABS 551/552

Color: White / Black

Model Number: EN

Product Code: 5301550 (White), 5302550 (Black)

Dimensions: X2 (mm)

Product Usage Instructions

  1. Prepare for assembly:
  • Tools Required (not included):
  • Cordless screwdriver
  • Hexagonal screws ST6.3 (8pcs.)
  • Tips:
    • Ensure that the surfaces are clean, dry, and free from all
      traces of grease, oil, wax, and dust.
  • Assembly instructions:
    1. Mount the solar module on the brackets:
    • Method B: Fix the solar module with ST6.3
      hexagonal screws.
  • Glue onto the surface and done!

    ES-ABS 551/552

    White / Black

    EN

    5301550 5302550

    ES-ABS 551/552
    enjoysolar® ABS Mounting bracket 550mm
    Dimension(mm)
    X2
    Prepare for assembly
    Tools (not incl.)

    Or

    +

    Sikaflex® – 554 construction adhesive

    Cordless screwdriver and hexagonal screws ST6.3 (8pcs.)

    Tipps:
    Surfaces must be clean, dry and free from all traces of grease, oil, wax and dust.

    Copyright© 2022 SolarV GmbH All rights reserved.

    Assembly instructions
    1 Mount the solar module on the brackets:
    Method A: glue with Sikaflex®-554
    Copyright© 2022 SolarV GmbH All rights reserved.

    Method B: fix with ST6.3 hexagonal screws
    Copyright© 2022 SolarV GmbH All rights reserved.

    2 Apply the Sikaflex®-554 construction adhesive
    Copyright© 2022 SolarV GmbH All rights reserved.

    3 glue onto the surface and done!
    Copyright© 2022 SolarV GmbH All rights reserved.
