BE-FDFOCHBG3 Series Bass Enclosure
Product Information:
The BE-FDFOCHBG3-VS102 B.O.O.S.T. Series Bass Enclosure is
specifically designed for the 2012-2018 Ford Focus 5-Door
Hatchback. It features a NVX VSW 10 subwoofer and is internally
wired for a 2 ohm load at the speaker-wire connection terminal. The
enclosure is custom made for optimal performance in a
ready-to-install subwoofer system.
Product Usage Instructions:
- Bolt the included custom bracket to the floor of the trunk,
ensuring that it is positioned as seen in the photo. - Remove the 8 4mm allen key screws from the subwoofer enclosure,
then take out the subwoofer from the enclosure. - Connect the subwoofer wires to the connection terminal on your
BOOST box. It is recommended to use blue for positive (red) and
grey for negative (black). - Place the BOOST enclosure into position on the passenger side,
making sure that the back hole aligns with the threaded stud in the
trunk. - Secure the BOOST box to the side of the trunk using the
supplied nut. - Use the included hardware to secure the BOOST box into the
trunk, using the new screw location from the bracket in step
1. - Wire the subwoofer in parallel to achieve a final impedance of
2-Ohms. Connect the red wire to the red terminal and the black wire
to the black terminal. - Load the subwoofer back into the enclosure and fasten the 8
allen bolts.
Now you can enjoy your new BEFDFOCHBG3-VS102 B.O.O.S.T. Series
Bass Enclosure!
Note: Before using the product, please check if your amplifier
is optimized to drive a 2 ohm load.
Included in the box:
- Fabricated bracket
- M6-1.00 fender nut
- M6-1.00 x 30mm bolt
- M6 lock washer
- M6 flat washer
- (2) factory M6 10mm nuts
INSTALLATION GUIDE
BE-FDFOCHBG3-VS102 B.O.O.S.T. Series Bass Enclosure for the 2012-2018 Ford Focus 5-Door Hatchback
Step 1
Bolt the included custom bracket to the floor of the trunk. Making sure to position the bracket as seen in the photo.
Step 2
Remove the 8 4mm allen key screws from the subwoofer enclosure, then remove the subwoofer from the enclosure.
Step 3
Connect subwoofer wires to the connection terminal on your BOOST box. We generally use blue for positive (red) grey for negative (black).
Step 4
Place BOOST enclosure into position on the passenger side. Make sure the back hole lines up with the threaded stud in the trunk.
Step 5
Use the supplied nut to secure the BOOST box to the side of the trunk.
Step 6
Take included hardware and secure the BOOST box into the trunk using the new screw location from the bracket in step 1.
Step 7
Wire the subwoofer in parallel for a final impedance of 2-Ohms. Red wire goes to the red terminal and the black wire goes to the black terminal.
Step 8
Load the subwoofer back into the enclosure. Fasten the 8 allen bolts. Now it’s time to enjoy you’re new BEFDFOCHBG3-VS102!
We recommend the installation of the NVX BE-FDFOCHBG3-VS102 to be performed by a professional that will have the skills and tools to ensure the job is done correctly. Please follow the steps above to get the best performance out of the BE-HYDELAG6-VSW102. Installing and mounting NVX BEFDFOCHBG3-VS102 improperly can present a serious safety hazard in the event of a collision. If you have any questions regarding installation of this product or an amplifier in this vehicle please feel free to contact NVX directly for further guidance and installation techniques.
The BOOST subwoofer enclosures are internally wired for a 2 ohm load at the speaker-wire connection terminal. Check to see if your amplifier is optimized to drive this load. The BOOST enclosures feature a NVX VSW 10″ subwoofer and are custom made for optimal performance in a ready-to-install subwoofer system.
Included in the box:
Fabricated bracket M6-1.00 fender nut M6-1.00 x
30mm bolt M6 lock washer
M6 flat washer
(2) factory M6 10mm nuts
