OS08A10 8 Megapixel Product Brief

Product Information

The OS08A10 is an 8-megapixel camera that is designed to capture
high-quality video footage. It is capable of recording smooth 4K2K
video at 60 frames per second (fps) and 1080p video at 120 fps,
ensuring detailed wide-area coverage. The camera features a
11-degree chief ray angle (CRA), a two-exposure staggered high
dynamic range (HDR) mode, and low power requirements, making it
suitable for use in battery-powered drones and wireless devices.
Additionally, the OS08A10 is compatible with advanced compression
technology like high-efficiency video coding (HEVC), allowing for
the delivery of 4K video to mainstream displays.

Product Usage Instructions

1. Ensure that the OS08A10 camera is properly connected to the
   device you intend to use it with.
2. Power on the camera and wait for it to initialize.
3. Configure the camera settings according to your requirements.
   This may include adjusting the video resolution, frame rate, and
   HDR mode.
4. If using the camera with a battery-powered device, make sure
   the battery is fully charged before starting recording.
5. Position the camera in the desired location or attach it to a
   drone or wireless device securely.
6. Start recording by pressing the designated button or activating
   the recording function through the device’s interface.
7. Monitor the video feed or review the recorded footage in
   real-time, if applicable.
8. After recording, stop the recording by pressing the designated
   button or deactivating the recording function on the device.
9. Transfer the recorded video files to a computer or storage
   device for further processing or viewing.
10. When not in use, power off the camera to conserve battery life
    and protect the device.

For more detailed information on using the OS08A10 camera and
its features, please refer to the user manual available at www.ovt.com.

OS08A10
8-megapixel product brief

Low-Power 8-Megapixel PureCel® Sensor Brings 4K2K Video to Security and Consumer Applications

OMNIVISION’s OS08A10 is a low-power image sensor that brings 8-megapixel resolution to a variety of applications, including commercial surveillance, IoT, action cameras, drones, and augmented / virtual reality (AR/VR) systems. Built on OMNIVISION’s advanced PureCel® pixel architecture, the OS08A10 leverages backside illumination (BSI) technology with improved low-light sensitivity to deliver high-resolution images and capture ultra-high-resolution 4K2K video, even in challenging high-contrast lighting conditions.

The OS08A10 captures smooth, best-in-class 4K2K video at 60 frames per second (fps) and 1080p video at 120 fps, enabling detailed wide-area coverage.
The OS08A10 also features a 11-degree chief ray angle (CRA), a two-exposure staggered high dynamic range (HDR) mode, and low power requirements to enable a range of battery-powered drones and wireless devices. The OS08A10 is compatible with advanced compression technology such as high-efficiency video coding (HEVC) to deliver 4K video to mainstream displays.
Find out more at www.ovt.com.

OS08A10

Ordering Information
· OS08A10-H92A-1B (color, lead-free) 92-pin CSP

Applications
· security cameras · action cameras · high resolution consumer cameras

· digital still cameras (DSC) · digital video camcorders (DVC)

Technical Specifications

· active array size: 3840 x 2160
· maximum image transfer rate: – 4K2K: 60 fps – 2560 x 1440: 60 fps – 1080p: 120 fps
· power supply: – core: 1.2V – analog: 2.8V – I/O: 1.8V

· temperature range: – operating: -30°C to +85°C junction temperature – stable image: 0°C to +60°C junction temperature
· lens size: 1/1.8″
· lens chief ray angle: 11° linear
· scan mode: progressive

· power requirements: – active: 240 mA – XSHUTDOWN: <10 µA
· output formats: 10/12-bit RGB RAW

· pixel size: 2.0 µm x 2.0 µm
· image area: 7736.256 µm x 4379.616 µm

Product Features
· 2 µm x 2 µm pixel
· optical size of 1/1.8″
· programmable controls for: – frame rate – mirror and flip – cropping – windowing
· supports output formats: 10/12-bit RGB RAW
· supports image sizes: – 4K2K (3840 x 2160) – 2560 x 1440 – 1080p (1920 x 1080) – 720p (1280 x 720)

· supports 2×2 binning · standard serial SCCB interface · 12-bit ADC · up to 4-lane MIPI/LVDS serial output
interface (supports maximum speed up to 1500 Mbps/lane) · 2-exposure staggered HDR support · programmable I/O drive capability · light sensing mode (LSM) · PLL with SCC support · support for FSIN

row select ISP FIFO
MIPI/LVDS TX

Functional Block Diagram

OS08A10

image sensor core
column sample/hold

image sensor processor

image array

AMP

12-bit ADC

image interface

temperature sensor

gain control

MCP/N MDP/N[3:0]

control register bank

PLL PLL timing generator and system control logic

SCCB interface

XVCLK XSHUTDOWN2
XSHUTDOWN TM
GPIO[3:0] PWDNB STROBE VSYNC HREF SCL SID SDA

Version 1.6, June 2023
