SE8000H Home Wave Inverter

Product Information

The SolarEdge Home Wave Inverter is a single-phase inverter
designed for use in France, Spain, UK, and Hong Kong. It is
available in two models: SE8000H and SE10000H. The inverter comes
with a 12-25 year warranty and features HD-Wave technology for
optimized installation.

The SolarEdge Home Wave Inverter is specifically designed to
work with SolarEdge Power Optimizers. It offers industry-leading
efficiency with 200% DC oversizing, making it highly efficient in
converting solar energy into usable AC power. The inverter is
extremely compact, lightweight, and easy to install. It also has
built-in module-level monitoring, allowing users to monitor the
performance of individual solar panels.

This inverter is suitable for both outdoor and indoor
installation. It is a fixed voltage inverter, which means it can
accommodate longer strings of solar panels. The inverter can be
seamlessly connected to other system devices, such as the SolarEdge
Home Battery, via the optional SolarEdge Home Network platform.

For more detailed information, please refer to the
SolarEdge Energy Net Plug-In Datasheet.

Product Usage Instructions

To commission the SolarEdge Home Wave Inverter, follow these
steps:

Download and install the SolarEdge SetApp on your
smartphone.
Ensure that the inverter is properly installed and connected to
the solar panels and power grid.
Open the SolarEdge SetApp on your smartphone and follow the
on-screen instructions.
The app will guide you through the commissioning process,
allowing you to configure the inverter settings and connect it to
your solar energy system.
Once the commissioning is complete, the inverter will start
converting solar energy into AC power for use in your home.

It is important to note that the SolarEdge Home Wave Inverter
has a rated AC power output of either 8000 VA (SE8000H) or 10000 VA
(SE10000H). The maximum AC power output is also 8000 VA or 10000
VA, depending on the model. The inverter operates at an AC output
voltage of 220/230 Vac, with a voltage range of 184 – 264.5 Vac.
The nominal AC frequency is not specified in the provided
information.

The inverter has a maximum continuous output current of 36.5 A
(SE8000H) or 45.5 A (SE10000H). The total harmonic distortion (THD)
value is not mentioned in the user manual.

View Fullscreen

INVERTERS

SolarEdge Home Wave Inverter
Single Phase, for France, Spain, UK, and Hong Kong
SE8000H, SE10000H
12-25
YEAR WARRANTY

Optimized installation with HD-Wave technology

Specifically designed to work with SolarEdge Power Optimizers
Quick and easy inverter commissioning directly from a smartphone using the SolarEdge SetApp
Industry leading efficiency with 200% DC oversizing

Extremely compact, lightweight and easy to install Built-in module-level monitoring Suitable for outdoor and indoor installation Fixed voltage inverter for longer strings

Seamless wireless connectivity with system devices such as the SolarEdge Home Battery, via optional SolarEdge Home Network platform

(1) For more information, refer to: https://www.solaredge.com/sites/default/files/se-energy-net-plug-in-datasheet.pdf

solaredge.com

SolarEdge Home Wave Inverter
Single Phase, for France, Spain, UK and Hong Kong (8 10 kW)
SE8000H, SE10000H

SE8000H

SE10000H

APPLICABLE TO INVERTERS WITH PART NUMBER

SEXXXXH-XXXXXBXX4 (Inverters with SetApp Configuration)

OUTPUT

Rated AC Power Output

8000

10000

Maximum AC Power Output

8000

10000

AC Output Voltage (Nominal)

220/230

Vac

AC Output Voltage Range

184 – 264.5

Vac

AC Frequency (Nominal)

50/60 ± 5

Maximum Continuous Output Current

36.5

45.5

Total Harmonic Distortion (THD)

Power Factor

1, adjustable -0.8 to 0.8

Utility Monitoring, Islanding Protection, Configurable Power Factor, Country Configurable Thresholds

Yes

INPUT
Maximum DC Power Transformer-less, Ungrounded Maximum Input Voltage Nominal DC Input Voltage Maximum Input Current Reverse-Polarity Protection Ground-Fault Isolation Detection Maximum Inverter Efficiency European Weighted Efficiency Nighttime Power Consumption

16000

20000

Yes

480

Vdc

400

Vdc

20.5

25.5

Adc

Yes

600k Sensitivity per Unit

99.2

< 2.5

ADDITIONAL FEATURES
Supported Communication Interfaces
Smart Energy Management Arc Fault Protection Inverter Commissioning Compatible Batteries
STANDARD COMPLIANCE
Safety Grid Connection Standards Electromagnetic Compatibility (EMC)
INSTALLATION SPECIFICATIONS
AC Output – Supported Cable Diameter AC – Supported Wire Cross Section DC Input Dimensions (H x W x D) Weight Noise Cooling Operating Temperature Range Protection Rating

RS485, Ethernet, ZigBee (optional), wireless SolarEdge Home Network (optional)(1), Wi-Fi (optional), Cellular (optional)
Export Limitation
Integrated, User Configurable (According to UL1699B) With the SetApp mobile application using built in Wi-Fi access point for local connection
SolarEdge Energy Bank(2)

IEC62109
G83/1, G83/2, G59/3, RD661, RD1699, UTE C15-712 EN/IEC 61000-6-1, EN/IEC 61000-6-2, EN/IEC 61000-6-3, EN/IEC 61000-6-4, EN 55011, FCC Part 15,
EN/IEC 61000-3-2, EN/IEC 61000-3-3, EN/IEC 61000-3-11, EN/IEC 61000-3-12

9-16

1-13

mm2

3 x MC4 pair

360 x 370 x 185

16.5

< 50

dBA

Natural Convection

-40 to +60(3)

°C

IP65 — Outdoor and Indoor

(1) For more information, refer to: https://www.solaredge.com/sites/default/files/se-energy-net-plug-in-datasheet.pdf (2) Pending inverter firmware support (3) Full power up to at least 50°C. For power de-rating information refer to: https://www.solaredge.com/sites/default/files/se-temperature-derating-note.pdf
