GSD Gen 2 Electric Bike
Product Information
The Clubhouse+TM is a bike accessory designed to safely carry
rear passengers on your bike. It includes various components such
as the Child Seat Expansion Bar, Flat Bar, Clubhouse Frame, Bolt
Sets, Seatpad, Seatpad Strap, and Bar Tape. The installation and
assembly instructions are provided in the user manual.
What’s Included:
- Child Seat Expansion Bar x 1
- Flat Bar x 2
- Clubhouse Frame x 2
- Bolt Set for Clubhouse Assembly
- Bolt Set for Clubhouse Installation
- Seatpad
- Seatpad Strap x 4
- Bar Tape x 2
Installation:
To assemble the Clubhouse+TM, follow these steps:
- Apply anti-seize lubricant or any standard lubricant to the tip
of the bolts before securing the nuts. This helps reduce friction
and prevent thread galling. - Refer to the user manual for the specific bolt sizes and
quantities required for assembly. - Use the provided tools to tighten the bolts and ensure a secure
assembly.
To install the Seatpad, follow these steps:
- Refer to the user manual for the specific bolt sizes and
quantities required for installation. - Use the provided tools to attach the Seatpad to the
Clubhouse+TM.
Product Usage Instructions:
In order to safely transport rear passengers using the
Clubhouse+TM, please follow these guidelines:
- Check local regulations to ensure carrying passengers on a bike
is legal in your area. - Check your bike’s manual for the maximum gross vehicle weight
limit, and ensure you do not exceed it. Most riders can comfortably
carry 80% of their weight. - Rider and rear passenger(s) are strongly advised to wear an
approved helmet. - Do not allow children to climb onto the bike or leave them
unattended on the bike, as it may affect the bike’s balance and
result in injuries. - Install purpose-built rear seating and handholds for passengers
to ensure their safety and comfort. - Ensure the bike has foot support and proper foot and leg
protection to prevent accidents. - Check that all accessories are correctly installed and securely
fastened before riding. - Use the accessories strictly for their intended purposes and
avoid using them to lift the bike, as it may damage the frame and
accessories.
For more information on safely carrying passengers on your bike,
visit ternbicycles.com/support.
Clubhouse+TM
What’s Included
1. Child Seat Expansion Bar x 1
3
2. Flat Bar x 2
3. Clubhouse Frame x 2
4. Bolt Set for Clubhouse Assembly
1
2
5. Bolt Set for Clubhouse Installation
6. Seatpad
3
7. Seatpad Strap x 4
8. Bar Tape x 2
Installation
Tools Required (Not Included) · 3 mm and 4 mm Allen Wrench with Ball End · 8 mm and 10 mm Open-End Wrench
How to Assemble the Clubhouse+
8 mm 3 mm
4
M5 x 15 Bolt (8) M5 Washer (16) M5 Nylon Nut (8)
5
6 2
M6 x 40 Bolt (4) M6 x 45 Bolt (2) M6 x 12 Washer (4) M6 x 16 Washer (4) M6 Nylon Nut (4) M6 Custom Bushing (2)
7
6 8
Add anti-seize lubricant to the tip of the bolts before securing the nuts. If anti-seize lubricant is not available, apply any standard lubricant to reduce friction and prevent thread galling.
How to Install the Seatpad
4
Tighten Bolts to a torque of 4 Nm 5 Nm
How to Install the Clubhouse+
10 mm 4 mm
M6 x 40 Bolt (4) M6 x 12 Washer (4) M6 x 16 Washer (4) M6 Nylon Nut (4) GSD Gen 2
M6 x 45 Bolt (2) M6 x 40 Bolt (2) M6 x 12 Washer (4) M6 Custom Bushing (2) M6 x 16 Washer (4) M6 Nylon Nut (4)
GSD Gen 1
ternbicycles.com
Tighten Bolts to a torque of 9 Nm 10 Nm
SidekickTM Wide Decks
Carrying Rear Passengers
In order to safely transport rear passengers, please check the following points and ensure your bike is equipped with the proper accessories.
Check Local Regulations
It may be illegal to carry passengers on a bike in your area even if it has been designed or configured to do so. Check your local regulations before carrying passengers.
Check Max Gross Vehicle Weight Limits
Please follow and check your bike’s manual for information about maximum gross vehicle weight. (Maximum gross vehicle weight is the total weight of the bike, rider, passenger, accessories, and cargo.) Most riders can comfortably carry 80% of their weight. You should determine if you are comfortable carrying that much weight.
Wear a Helmet
Rider and rear passenger(s) are strongly advised to wear an approved helmet.
Do NOT Leave Children Unattended
Do not allow your children to climb onto the bike nor leave your children unattended on the bike, even if it is on the kickstand. Wriggling children can upset the balance of the bike and a fall may result in serious injuries.
Use Proper Equipment
The bike needs to have the following accessories installed in order to safely transport rear passenger(s).
1. Seating. Purpose-built rear seating, chosen according to the 3. Foot support. Fixed platforms or dedicated foot pegs on
passenger’s needs
both sides of the bike
2. Handhold. Something for the passenger to hold on to, other 4. Foot and leg protection. Something to prevent feet and
than the bike itself
legs from getting caught in the spinning wheel
Transporting One or Two Children Carrying Cargo
2 1
4 3
1
2
4 3
The illustrations above show a mix of suggested gear to safely carry passengers. Your combination of passenger accessories may differ depending on your needs. To learn more about to safely carry passengers on your bike, visit ternbicycles.com/support.
Follow Installation Procedures Check to ensure accessories have been correctly installed and securely fastened before riding.
Use Accessories Properly Our seating accessories are strictly for sitting. Using them to lift the bike will damage the frame and accessory.
Our rear handhold accessories are strictly for passengers to hold. Adding substantial weight on the top of or using the rear passenger handlebars to lift the bike will cause undue stress on the seatpost and handlebar.
Our foot support accessories are strictly for passenger use when SEATED. Standing on them is unsafe and may permanently damage the frame.
Scan to view available passenger seating accessories
ternbicycles.com
Installing a Bottle Cage or Lock
Tighten Bolts to a torque of 4 Nm 5 Nm
GSD Gen 1
The Clubhouse+ is not intended to provide protection in the event of an accident or if the GSD falls over. It is solely intended to keep passengers or cargo centered while riding.
LIMITED PRODUCT WARRANTY INFORMATION: This Product comes with a ONE (1) YEAR Limited Warranty from the date of retail purchase by the original end-user. If a material or workmanship defect arises and a valid claim is received within the Warranty Period, this Product will be replaced. Mobility Holdings cannot be held liable for damages to personal property due to misuse or improper care and maintenance. This Product Warranty does not, under any circumstance, cover the replacement or cost of any third party product used with or connected to the Product.
Tern, the Tern Werd (logotype), the Tern Berd (device), and Clubhouse used alone or in combination are trade names, trade devices or registered trademarks of Mobility Holdings, Ltd.
© 2022. Tern is a trademark of Mobility Holdings, Ltd. All Rights Reserved.
