TD20031CEL 2 Light Ceiling Lighting

Product Information

The TD20031CEL 2-Light Ceiling Lighting is a product designed
for ceiling mounting. It includes a fixture body, acrylic board,
mounting strap, screws, wire nuts, and an instruction manual. The
product has an input voltage of 120V and a rated power of 60W. It
requires two E26 bulbs, which are not included in the
packaging.

Product Usage Instructions

1. Fix the mounting strap (F) to the outlet box with Screw
   (E).
2. Connect the wires according to the wiring instruction provided
   in the manual. Make sure to connect the ground wire to the green
   grounding screw and never connect it to black or white power supply
   wires.
3. Place fixture body (A) onto the outlet box and secure it with
   Screw nut (D).
4. Install two E26 bulbs (not included).
5. Peel off the protective cover on acrylic board (C).
6. Gently bend acrylic board (C) a little bit and insert it into
   the bottom of the fixture. Then release it and adjust it to make it
   well positioned.

Wiring Instruction

1. Insert the green grounding screw into the hole with two raised
   dimples on the mounting bar. Wrap the ground wire from the fixture
   (if supplied) around the green grounding screw, then connect it to
   ground wire from the outlet box (if not fixed on the outlet box)
   using a wire connector (not supplied). If ground wire from the
   fixture is not supplied, wrap the ground wire (if not fixed on the
   outlet box) from the outlet box around the green grounding screw
   and tighten it.
2. Identify the color of the wire(s) on your fixture and connect
   them according to the directions provided in the manual.
3. Place the fixture wire(s) from [Group A] evenly against the
   black wire from the outlet box. Do NOT twist wires together before
   using wire connectors.
4. Fit a wire connector over the wires and screw the connector
   clockwise until you feel firmness.
5. Try gently to pull the connector off the wires. If you can pull
   the connector off, carefully re-do steps 3 and 4 as above, and
   check again for a firm connection.
6. Connect the fixture wire from [Group B] to the white wire from
   the outlet box in the same manner. Make sure no bare wires can be
   seen outside wire connectors.

Cleaning Instructions

To clean, wipe fixture with a soft cloth. Clean glass with a
mild soap. Do not use abrasive materials such as scouring pads or
powders, steel wool or abrasive paper.

Safety Information

Always switch off the electricity supply and allow to cool for
10 minutes before changing the light bulbs.

Contact Information

If you have any questions or concerns, please contact us at
[email protected].

Instructions Manual 2-Light Ceiling Lighting

TD20031CEL

Overview

Outlet box
[GROUP] Black
Wire nuts Smooth
Screw(E)

Green(Ground)

Mounting strap(F)

White Ribbed

Bare copper wire(Ground)

Fixture body(A)

(not IBnucllubd(eBd))
Screw nut (D) Acrylic board (C)

Assembly Instruction
1. Fix Mounting strap (F) to outlet box with Screw (E). 2. Connect the wires according to the picture above.(Please refer to the
wiring instruction for details ) 3. Place Fixture body (A) onto the outlet box, secure with Screw nut (D). 4. Install Bulbs (not included), need two E26 bulbs. 5. Peel off the protective cover on acrylic board( C ) 6. Gently bend acrylic board( C ) a little bit and insert it into the bottom
of the fixture and then release it. Adjust it to make it well positioned.

Wiring Instruction
1.Insert the green grounding screw into the hole with two raised dimples on the mounting bar. Wrap the ground wire from the fixture (if supplied) around the green grounding screw, then connect it to ground wire from the outlet box (if not fixed on the outlet box) using a wire connector (not supplied).If ground wire from the fixture is not supplied, wrap the ground wire (if not fixed on the outlet box) from the outlet box around the green grounding screw and tighten it.
NEVER CONNECT GROUND WIRE TO BLACK OR WHITE POWER SUPPLY WIRES.
2.Take note for the color of the wire(s) on your fixture. Identify which group your fixture wire(s) falls into and connect the wires according to the directions below:

BLACK

WHITE

*PARALLEL WIRE (round & smooth) *PARALLEL WIRE (square & ridged)

WHITE OR GREY WITE TRACER

WHITE OR GREY WITHOUT TRACER

BROWN, GOLD OR BLACK WITHOUT TRACER

BROWN, GOLD OR BLACK WITH TRACER

3.Take your fixture wire(s) from [Group A] and place evenly against the black wire from the outlet box. Do NOT twist wires together before using wire connectors.
4. Fit a wire connector over the wires and screw the connector clockwise until you feel firmness.
5.Try gently to pull the connector off the wires. If you can pull the connector off, carefully re-do steps3 and4 as above, and check again for a firm connection.
6. Connect the fixture wire from [Group B] to the white wire from the outlet box in the same manner. Make sure no bare wires can be seen outside wire connectors.

Product Specifications
Input Voltage 120V Rated Power 60W Max Lamp Socket E26
Product Packaging
Fixture body x 1 Screw x 2 & wire nut x 3 Acrylic board x 1 Lamp instruction x 1

Cleaning
To clean,wipe fixture with a soft cloth. Clean glass with a mild soap.Do not use abrasive materials such as scouring pads or powders, steel wool or abrasive paper.
Safety Information
Always switch off the electricity supply and allow to cool for 10 minutes before changing the light bulbs.
CONTACT US
E-mail:service @24h-reply.com

Print in china
