PRO 5 Mission Specialist ROV Robot

Product Information: PRO 5 Quick Reference Guide

The PRO 5 is a remotely operated underwater vehicle (ROV) used
for exploring underwater environments. The system consists of an
ROV, an Operator Control Console (OCC), a tether, and related power
and communication cables. The ROV is equipped with thrusters,
propellers, a camera, LED lights, and other sensors to allow for
navigation, observation, and data collection in underwater
environments.

Visually Inspect the System

Before using the PRO 5, visually inspect the system for any
signs of damage or wear. Check the thrusters, propellers, camera
housing, and all connectors. Ensure that all parts are securely
connected and free to move.

Checking the Thrusters

Inspect the propellers to verify that each has three unworn
blades and is free to spin. Also, check the thruster telltales and
look for signs of oil leakage.

Inspecting the Camera Housing

Inspect the camera housing for any signs of water inside. If
there is any water inside the camera housing, do not use the system
until the issue is resolved.

Inspecting the Entire System

Inspect the entire system for signs of damage, loose or worn
parts. If any parts are damaged or worn out, they must be replaced
before using the system.

Connecting and Powering On

Follow these steps to connect and power on the PRO 5:

Connecting the System

1. Remove the tether caps and connect the female end of the tether
   and strain relief to the ROV. Store caps in a secure location.
2. If not already connected, connect the male end of the
   double-ended connector 26A to the OCC.
3. Connect the male end of the tether to the female end of the
   double-ended connector 26B.
4. Remove the ROV float block bolts and remove the float
   block.
5. Inspect all 5-pin and 9-pin connectors to ensure they are
   seated and then replace and secure the float block. If the
   connectors are not fully seated, clean, lubricate, and reseat
   them.
6. Connect the hand controller to the OCC controller USB port. Do
   not connect more than one hand controller to the system at a
   time.
7. Connect the keyboard to the OCC keyboard USB port.
8. Confirm that the ROV POWER MAINS is fully depressed.
9. Connect the OCC power cord to the OCC and a power source.

Powering On

10. Turn on the OCC.
11. Turn on the ROV POWER MAINS by twisting the Red Power Mains
    button clockwise.
12. Start the Pro 5 control software.

Do not connect or disconnect cables while the system is powered
on. All ROV submerged connections must be terminated. Follow these
steps in order when starting the system.

Pre Dive Check List

Before diving, perform a pre-dive check list:

1. Verify all thrusters respond to the controller inputs as
   expected.
2. Verify main camera tilts all the way up and all the way
   down.
3. Verify main camera focus – in and out.
4. Verify LED light function. Both LED modules dim until off and
   increase until full illumination.
5. Deploy Vehicle and adjust ballast. To ballast the ROV: Add or
   remove ballast weights until the ROV is slightly positively
   buoyant. Typically, this is achieved when the top of the float
   block is even with the water surface.
6. Enable auto controls (they will turn green when enabled):
   Auto-Depth, Auto-Heading.
7. Begin operations and recording.

Using the Controller / Testing the System

The controller is used to navigate and control the ROV. Use the
following instructions to test the system:

1. Verify all thrusters respond to the controller inputs as
   expected.
2. Verify main camera tilts all the way up and all the way
   down.
3. Verify main camera focus – in and out.
4. Verify LED light function. Both LED modules dim until off and
   increase until full illumination.
5. Deploy Vehicle and adjust ballast.
6. Enable auto controls (they will turn green when enabled):
   Auto-Depth, Auto-Heading.

Propeller Reference

The PRO 5 contains two propellers, one on each side of the ROV.
The correct propeller type for each location is as follows:

To show/hide tabs, use the left arrow button on the controller.
Use the views button to switch between Nav/Sonar/Video, Video,
Sonar, and Nav. Use the thruster/propeller reference to identify
the correct propeller for each location.

PRO 5

Quick Reference Guide

1 Visually Inspect the System 1A Check the thrusters.

GOOD

Inspect the propellers, verifying that each has 3 WORN blades and they are free to spin.

1B
Inspect for water inside the camera housing.

Inspect the thruster telltales and look for signs of oil leakage.
1C
Inspect the entire system for signs of damage, loose,
or worn parts.

VideoRay Part Number 72281 rev 5.01.00 2021-09

2

Connecting & Powering On
WARNING: Do not connect or disconnect cables while system is powered. CAUTION: ALL ROV submerged connections must be terminated. CAUTION: Follow these steps in order when starting the system.

Connecting the System
1. Remove the tether caps and connect the female end of the tether and strain relief to the ROV. See figure 2B. (Store caps in a secure location)

2. If not already connected, connect the male end of the double ended connector 26A to the Operator Control Console (OCC). 26

3. Connect the male end of the tether to the female end of the double ended connector. 26B
4. Remove the ROV float block bolts and remove the float block.

5. Inspect all 5-pin and 9-pin connectors to ensure they are seated and then Replace and secure the float block. See figure 2C. CAUTION: If the connectors are
not fully seated, clean, lubricate, and reseat them.

6. Connect the hand controller to the OCC controller USB port. 24 CAUTION: Do not connect more than one hand controller to the system at a time.

7. Connect the keyboard to the OCC keyboard USB port. 25 8. Confirm that the ROV POWER MAINS is fully depressed.

9. Connect the OCC power cord to the OCC and a power source. 18

ON

10. Turn on the OCC.

19

11. Turn on the ROV POWER MAINS.

20

Twist the Red Power Mains button clockwise.

12. Start the Pro 5 control software. Pro 5

2A

Attach the strain relief bolt through the eye hole of the strain relief cable. 34
2B

Test the strain relief to verify the stress is on the cable not the tether or connector. 35

2C
If the connectors are separated, do not place the system in water. Clean, lubricate and reseat the connectors.
BAD GOOD

3 Pre Dive Check List

Using the Controller / Testing the System:

1. Verify all thrusters respond to the controller inputs as expected. M J 2. Verify main camera tilts all the way up and all the way down. F G

3. Verify main camera focus – in and out. H I 4. Verify LED light function. Both LED modules dim until off and increase until full
illumination. E

5. Deploy Vehicle and adjust ballast. NOTE: It is okay to lower the vehicle using the tether
To ballast the ROV: Add or remove ballast weights 12 until the ROV is slightly positively buoyant. Typically, this is achieved when the top of the float block is even with the water surface.
6. Enable auto controls (they will turn green when enabled).

Auto-Depth

Auto-Heading

7. Begin operations and recording.

Views

Nav/Sonar/Video

Video

Sonar

Nav

Sonar/Video

Thruster / Propeller Reference
Propeller Identification

Show/Hide Tabs

LEFT The LEFT propeller has a
black plastic base

RIGHT
The RIGHT propeller has a stainless band at its base

Correct Propeller Type for each Location

PORT

VERTICAL

STARBOARD

LEFT

RIGHT

RIGHT

Vertical (looking down on the vehicle from the rear) Horizontal (looking from behind the vehicle)

4 Hand Controller Input Identification NOTE: XBox Elite hand controller compatibility coming soon

A

B

C

K

D

F

J

M

H

I

G E L

N

O

P

A. All Autos Off B. Open Manipulator Jaws C. Close Manipulator Jaws D. Rotate Manipulator Jaws E. Lights Intensity F. Camera Tilt Up G. Camera Tilt Down H. Focus In

I. Focus Out J. Vehicle Horizontal Control
K. Camera Snapshot
L. Camera Record M. Vehicle Vertical Control N. Sonar Frequency Selection
O. Increase Sonar Range P. Decrease Sonar Range

5 Recovering the System Post Dive Check List

1. Navigate the vehicle back to the deployment site.

2. Disable auto controls and stop recording.

Auto-Depth

Auto-Heading

3. Retrieve the ROV. NOTE: It is okay to lift it by the tether.
4. Close the Greensea EOD Workspace by clicking on the red X on the top right corner of the EOD Workspace window.
5. Press the ROV Mains Power Switch. ON
6. Turn off the Operator Control Console using the Power Switch. OFF
7. Disconnect the tether from the ROV.

8. Disconnect the tether from the OCC whip. 9. Replace the tether caps on all tether connections.

10. Visually inspect the system for damage that might have occurred during your operation.

11. Rinse the salt water from the system and soak the submersible for 30 minutes in fresh water.
12. Return all components to their storage cases after they have dried.

Verify System Connectivity
13. Heading – The Compass Bar will turn green when connected. 29 14. Depth – The Depth Tracker will turn green when connected. 30 15. Sonar – Imagery will display in the sonar window
when the sonar has connected. 31 16. Video – Imagery will appear in the video window
when the camera has connected. 32
USBL Installation
NOTE: The USBL is an optional accessory NOTE: If not using the USBL, make sure the ROV connector port is sealed
17. Remove the float block. 1 18. Feed the USBL accessory cable through the GPS hole in the float block. 19. Connect the accessory cable to the power / communications module port. 20. Replace the float block and secure the USBL beacon using the rear float block
screw. 14 21. Connect the Topside GPS Antenna to one of the Accessory USB Ports on the OCC. 28 22. Connect the USBL Topside Station to the OCC by plugging it into the Auxiliary 12 V
Port for power 27 and the Accessory USB Port for communications. 28 23. Deploy the USBL Topside Station in the water.
The OCC

16

17

22 18

23 19

24 25

26A

20

26

21

26B

27

28

15

Greensea Software
33

29 31

30 32

Pro 5 Component Identification
2 14

14

3 5

14

11

6

3

4

1
1. Float part number 70779 2. USBL Beac1on –(optional) part number 70693 3. LED Lighting Module part number 70023 (QTY 2) 4. Rotating Manipulator part number 70824 5. HD Camera Module part number 70044 6. Multibeam 750D Sonar part number 71047 7. Vertical Thruster part number 70503 8. Port Thruster part number 70503 9. Starboard Thruster part number 70503 10. Pro 5 Power and Comms Module part number 71006 11. AHRS Module part number 70273 12. Ballast part number 71044 13. Serial Number Plate 14. Float Block Screw 15. Operator Control Console (OCC) part number 70218 16. High Definition Display 17. Display Brightness 18. Universal Power Plug 100-124 volts AC 19. OCC Power On|Off Switch 20. ROV Power Mains/Emergency Stop 21. Line Insulation Monitor 22. HDMI Ports

23. Auxiliary Ethernet Port

24. Controller USB Port 25. Keyboard USB Port

9

26. Tether Whip Connection

12

26A-26B. Tether Double Ended Connector

27. Auxiliary 12 Volts (5 amp max) 28. Accessory USB Ports

29. Compass Bar 30. Depth and Altitude Tracker

31. Sonar feed

32. Video feed 33. Record button

34. Strain relief bolt

35. Test strain relief

8 12 10
Bottom view

9 11
7 10
13 8
Top view
