Slid Up Nmsu1600-02 Sliding Door Fitting Angle Pack Instruction Manual

Product Information:

The product is the SLID’UP 1600, a sliding door system designed
for assembly and installation. It comes with a set of instructions
for assembly in multiple languages, including French, German,
English, Spanish, and Polish. The product code is NMSU1600-02 A and
the manual was last updated in April 2020.

Product Usage Instructions:

1. Assembly Instructions:

   To assemble the SLID’UP 1600, follow these steps:

   1. Take 2 pieces labeled as “1” and connect them together.
   2. Take the piece labeled as “H” and connect it to the assembled
      pieces from step a).
   3. Take 2 more pieces labeled as “1” and connect them to the
      assembled structure from step b).
   4. Take the piece labeled as “H” and attach it to the assembled
      pieces from step c).
   5. Take the piece labeled as “2” and attach it to the structure
      assembled so far.
   6. Take the piece labeled as “3” and attach it to the structure
      assembled so far.

2. Mounting Instructions:

   To mount the SLID’UP 1600, follow these steps:

   1. Refer to the provided mounting instructions in the manual for
      detailed guidance.

3. Additional Information:

   For any further assistance or troubleshooting, please visit our
   website at www.slidup.net.
