ECM19TD2U Tie-Down Bracket

Product Information

• Product Name: Tie-Down Bracket
• Model Number: P/N 87791229
• Revision: B
• Part Numbers: 87791229, 87791492

Product Usage Instructions

1. Identify the Tie-Down Bracket in your product package. It
   should be labeled as “1”.
2. Check if you have the following screws:
   • 12-24x.625 screws (typically used for open frame rack
     mounting)
   • 10-32x.625 screws (typically used for cabinet mounting)

   Note: Select the appropriate screws based on your rack or cabinet
   mounting requirements. Only one type of screw may be supplied.

3. You should have four 10-32x.625 screws, labeled as “3”. These
   are used for mounting the Tie-Down Bracket.
4. You should have four additional screws, labeled as “4”. These
   are not specifically mentioned in the instructions, but they might
   be required for certain installations.

Tie-Down Bracket De Cravate Support Vers le bas
Del Lazo Escuadra Abajo

1

(1x)

2

12-24x.625

Note: Select screws to match rack angle thread pattern, typically 12-24 screws for open frame rack mounting or 10-32 screws for cabinet mounting. Only one type of screw may be supplied.
Note: Les vis choisies pour assortir le modèle de fil d’angle de support, en général 12-24 baise pour le support de chassis ouvert d’armature ou 10-32 vis pour le support de coffret. Seulement un type de vis peut être assuré.
Nota: Los tornillos selectos para emparejar el patrón del hilo de rosca del ángulo del estante, típicamente 12-24 atornillan para el montaje de estante abierto del marco o 10-32 tornillos para el montaje del gabinete. Solamente un tipo de tornillo puede ser provisto.

(4x)

3

10-32x.625

(4x) 4

(10x)

Rev. B

© 2018 Hoffman Enclosures Inc.

PH 763 422 2211 · nVent.com/HOFFMAN

P/N 87791229

87791492
