SRG0430C RGB Series Display
Product Information
Manufacturer: SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
Product Name: SRG0430C RGB Series Display
Model Number: SRG0430C-480800-CTP
LCD Display Size (Diagonal): 4.3 inch
Module Structure: LCD Display + CTP Touch + PCB
LCD Display Type: TFT
Recommended Viewing Direction: 6 o’clock
Number of Pixels (Resolution): 480(RGB)X800 pixels
Color Pixel Arrangement: RGB Stripe
Module Interface Type:
- LCD 16-bit RGB interface
- CTP I2C interface
Module Input Voltage: 5.0V
Color Numbers: 16.7M
Backlight Type: White LED
Operating Temperature: -20°C to 70°C
Storage Temperature: -30°C to 80°C
Product Usage Instructions
- Ensure the operating voltage of the PCB is within the range of
5.0V. - Connect the LCD module to the PCB using the 16-bit RGB
interface. - Connect the CTP touch to the PCB using the I2C interface.
- Apply power to the module.
- The display will show a resolution of 480(RGB)X800 pixels in
RGB stripe format. - The recommended viewing direction is 6 o’clock.
- The backlight is a white LED.
- The operating temperature range is -20°C to 70°C.
- The storage temperature range is -30°C to 80°C.
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
SRG0430C RGB Series Display
Model No.: SRG0430C-480800-CTP
RGB Interface TFT/IPS LCD Module USER MANUAL
Please click the following image to buy the sample
6KHQ¼KHQ6XUHQRR7HFKQR¹RJ»&R/WG ºººVXUHQRRFRP 6¸»SH·6X UHQRR
Reference Controller Datasheet
RGB Interface LCD Module Selection Guide
www.surenoo.com
P 01
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
CONTENTS
1GENERAL INFORMATION 2EXTERNAL DIMENSIONS 3ABSOLUTE MAXIMUM RATINGS 4ELECTRICAL CHARACTERISTICS 5BACKLIGHT CHARACTERISTICS 6CTP CHARACTERISTICS 7ELECTRO-OPTICAL CHARACTERISTICS 8INTERFACE DESCRIPTION 9INPUT TIMING 10RELIABILITY TEST CONDITIONS 11INSPECTION CRITERION
www.surenoo.com
P 02
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
1GENERAL INFORMATION
Item of general information
Contents
LCD Display Size (Diagonal)
4.3
Module Structure
LCD Display + CTP Touch + PCB
LCD Display Type
TFT
LCD Display Mode
Normally White
Recommended Viewing Direction
6
Gray inversion Direction
12
Module size (W×H×T)
62.26×117.5×6.2
Active area (W×H)
56.16×93.6
Number of pixels (Resolution)
480RGB×800
Pixel pitch (W×H)
0.117×0.117
Color Pixel Arrangement
RGB Stripe
LCD Driver IC
–
Module Interface Type
LCD
16-bit RGB interface
CTP
I2C interface
Module Input voltage
5.0V
Module Power Consumption
–
Color Numbers
16.7M
Backlight Type
White LED
Unit inch
o’clock o’clock mm mm pixel mm V mW –
www.surenoo.com
P 03
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
2EXTERNAL DIMENSIONS
www.surenoo.com
Customer Approved
REV NO. V0
Contents New issue
Date 2020-04-03
RGB
Pull tape
1 2
(
)
(
)
(
)
39 40
CON1
1
40
J1
40
J2
1 81
J3
:
RGB
Pixels Detail SCALE 50:1
Display Type:
4.3”TFT+CTP+PCB
Driver IC:
NT35510
Pixel Pitch:
Display Mode:
Transmissive
Operating Temperature:
-20°C TO +70°C
LCM Brightness:
Viewing Direction: (Gray Inversion)
Display Resolution:
12 o’clock 480(RGB)X800 pixels
Storage Temperature: Structure:
-30°C TO +80°C LCD+FPC+BL+CTP+PCB
Backlight: Material Note:
THIS DRAWING IS PROPERTY OF SURENOO TECHNOLOGY CO. LTD, IT CANNOT BE REPRODUCED WITHOUT PERMISSION.
0.117mmx0.117mm 200 cd/m^2 8 * LED
ROHS Request
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
Product NO:
SUR43WV016-WCT
Parts NO:
CTP Module APPD
Henry
REV:
V0 Unit: mm CHKD
Jason
Date: 2020-04-03 Scale: 1:1 Unmarked Tolerance: ±0.2mm
DWN Sheet:
Ljune 1 OF 1
A3 Model No.: SRG0430C-A3480800
P 04
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
3ABSOLUTE MAXIMUM RATINGS
Parameter of absolute
Symbol
Min
maximum ratings
Max
Unit
Operating temperature
Top
-20
70
Storage temperature
Tst
-30
80
Humidity
RH
–
90%(Max 60) RH
Note: Absolute maximum ratings means the product can withstand short-term, not more than
120 hours. If the product is a long time to withstand these conditions, the life time would be
shorter.
4ELECTRICAL CHARACTERISTICS(DC CHARACTERISTICS)
Parameter of DC characteristics
Symbol
Min.
Typ.
Max.
Unit
PCB operating voltage
VCC5V
–
5.0
–
V
LCD I/O operating voltage VDD
2.7
3.3
3.6
V
Input voltage `H’ level
VIH
0.7*VDD
–
VDD
V
Input voltage `L’ level
VIL
VSS
–
0.3*VDD V
Output voltage `H’ level
VOH VDD-0.4
–
VDD
V
Output voltage `L’ level
VOL
VSS
–
VSS+0.4
V
www.surenoo.com
P 05
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
5BACKLIGHT CHARACTERISTICS
Item of backlight
Symbol Min.
Typ.
characteristics
Max. Unit Remark
Forward Voltage
Vf 22.4
25.6
26.4
V
Note1
Forward Current
If
–
20
–
mA
–
Number of LED
–
–
8
–
Piece
–
LED Connection mode S/P
–
Serial
–
–
–
Note:
Note1: The LED Supply Voltage is defined by the number of LED at Ta=25 and
If=20mA.
Backlight control via the BL_CTR pin or PWM signal. Backlight circuit:
www.surenoo.com
P 06
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
6CTP CHARACTERISTICS
Item of CTP characteristics
Specification
Panel Type
Glass Cover + Glass Sensor
Resolution
480× 800
Surface Hardness
6H
Transparency
82%
Driver IC
–
Interface Type
I2C
Support Points
5
Sampling Rate
20~100
Supply voltage
3.3
A3 Model No.: SRG0430C-A3480800
Unit
Remark
–
–
pixel
–
–
–
–
–
–
–
–
–
–
–
Hz
–
V
–
www.surenoo.com
P 07
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
7ELECTRO-OPTICAL CHARACTERISTICS
Item of
electro-optical Symbol Condition Min. Typ. Max. Unit Remark Note
characteristics
Response time Contrast Ratio
Tr+Tf CR
=0 =0
–
30
40
ms
FIG 1.
4
–
500
–
–
FIG 2.
1
Luminance uniformity WHITE Ta=25
–
80
–
%
FIG 2.
3
Surface Luminance
Lv
–
250
– cd/m2 FIG 2.
2
White x White White y
0.266 0.296 0.326 0.295 0.325 0.355
Red x
0.617 0.647 0.677
CIE (x, y) chromaticity
Red Green
Red y Green x
=0 =0
Ta=25
0.299 0.329 0.359 0.247 0.277 0.307
–
FIG 2.
5
Green y
0.519 0.549 0.579
Blue Blue x Blue y
0.104 0.134 0.164 0.093 0.123 0.152
=90(12 o’clock)
60
70
–
deg
Viewing =270(6 o’clock) angle range =0(3 o’clock)
CR 10
60 60
70 70
–
deg FIG 3.
deg
6
=180(9 o’clock)
40
60
–
deg
NTSC ratio
–
–
–
50
–
%
–
–
Note 1. Contrast Ratio(CR) is defined mathematically by the following formula. For more
information see FIG 2.:
Note 2. Surface luminance is the LCD surface from the surface with all pixels displaying white. For more information see FIG 2.
Lv=Average Surface Luminance with all white pixels (P1,P2,P3,P4,P5,P6,P7,P8,P9) Note 3. The uniformity in surface luminanceWHITEis determined by measuring
www.surenoo.com
P 08
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
luminance at each test position 1 through 9, and then dividing the maximum luminance of 9points luminance by minimum luminance of 9 points luminance. For more information see FIG 2.
Note 4. Response time is the time required for the display to transition from White to black(Rise Time, Tr) and from black to white(Decay Time, Tf). For additional information see FIG 1. Note 5. CIE (x, y) chromaticity ,The x,y value is determined by screen active area position 5. For more information see FIG 2. Note 6. Viewing angle is the angle at which the contrast ratio is greater than a specific value. For TFT module, the specific value of contrast ratio is 10.The angles are determined for the horizontal or x axis and the vertical or y axis with respect to the z axis which is normal to the LCD surface. For more information see FIG 3. Note 7. For Viewing angle and response time testing, the testing data is base on Autronic-Melchers’s ConoScope. Series Instruments. For contrast ratio, Surface Luminance, Luminance uniformity and CIEthe testing data is base on BM-7 photo detector. Note 8. For TN type TFT transmissive module, Gray scale reverse occurs in the direction of panel viewing angle. FIG.1. The definition of Response Time
www.surenoo.com
P 09
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
FIG.2. Measuring method for Contrast ratio, surface luminance, Luminance uniformity,
CIE (x , y) chromaticity
A : H/6 ; B : V/6 ; H,V : Active Area(AA) size Measurement instrument: BM-7; Light spot size=5mm, 350mm distance from the LCD surface to detector lens.
FIG.3. The definition of viewing angle
www.surenoo.com
P 10
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
8INTERFACE DESCRIPTION
This RGB Display Support 16-Bit or 18-Bit RGB Interface only. 8.1: 16-Bit RGB Interface: R0, R1, R2, G0, G1, B0, B1, B2 Signal connect to GND or VDD. 8.2: 18-Bit RGB Interface: R0, R1, G0, G1, B0, B1 Signal connect to GND or VDD.
NO. Symbol
I/O
DESCRIPTION
1~2 VCC5V Power supply
Module Power supply (5V Typ.)
3~10 R0~R7
I
8bit digital Red data input(R0:LSB; R7:MSB)
11
GND
Power supply
Power ground
12~19 G0~G7
I
8bit digital Green data input(G0:LSB; G7:MSB)
20
GND
Power supply
Power ground
21~28 B0~B7
I
8bit digital Blue data input(B0:LSB; B7:MSB)
29
GND
Power supply
Power ground
30
DCLK
I
Clock signal.
31
HSYNC
I
Horizontal Sync input.
32
VSYNC
I
Vertical Sync input.
33
DEN
I
Data input Enable.
34 BL_CTR
I
Backlight control pin
35 CTP_RST
I
CTP external reset signal, Low is active
36 CTP_SDA
I/O
CTP I2C data input and output
37
NC
–
No connection
38 CTP_SCL
I
CTP I2C clock input
39 CTP_INT
I
CTP External interrupt to the host
40
NC
–
No connection
www.surenoo.com
P 11
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
9INPUT TIMING
A3 Model No.: SRG0430C-A3480800
Parallel RGB input Timing table
www.surenoo.com
P 12
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
10RELIABILITY TEST CONDITIONS
No.
Test Item
Test Condition
1 High Temperature Storage
80/120 hours
2
Low Temperature Storage
-30/120 hours
3 High Temperature Operating
70/120 hours
4 Low Temperature Operating
-20/120 hours
5 Temperature Cycle Storage -20(30min.)~25(5min.)~70(30min.)×10cycles
AInspection after test:
Inspection after 2~4 hours storage at room temperature, the sample shall be free from
defects:
Air bubble in the LCD;
Sealleak; Non-display;
Missing segments; Glass crack;
Current is twice higher than initial value.
BRemark:
The test samples should be applied to only one test item.
Sample size for each test item is 5~10pcs.
Failure Judgment Criterion: Basic Specification, Electrical Characteristic, Mechanical
Characteristic, Optical Characteristic.
www.surenoo.com
P 13
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
11INSPECTION CRITERION
This specification is made to be used as the standard of acceptance/rejection criteria for TFT-LCD/IPS TFT-LCD module product, and this specification is applicable only in the case that the size of module equal to or exceed than 3.5 inch. 11. 1 Sample plan Sampling plan according to GB/T2828.1-2003/ISO 2859-11999 and ANSI/ASQC Z1.4-1993,normal level 2 and based on: Major defect: AQL 0.65 Minor defect: AQL 1.5 11.2 Inspection condition Viewing distance for cosmetic inspection is about 30cm with bare eyes, and under an environment of 20~40W light intensity, all directions for inspecting the sample should be within 45°against perpendicular line. (Normal temperature 20~25and normal humidity 60 ±15%RH ) 11.3 Definition of Inspection Item A Definition of inspection zone in LCD.
www.surenoo.com
P 14
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
Zone A: character/Digit area
Zone B: viewing area except Zone A (Zone A + Zone B=minimum Viewing area)
Zone C: Outside viewing area (invisible area after assembly in customer’s product)
Fig.1 Inspection zones in an LCD
Note: As a general rule, visual defects in Zone C are permissible, when it is no trouble for
quality and assembly of customer’s product. B Definition of some visual defect
Because of losing all or part function, bad pixel dots appear bright and the
Bright dot size is more than 50% of one dot in which LCD panel is displaying under
black pattern.
Dark dot
Dots appear dark and unchanged in size in which LCD panel is displaying under pure red, green, blue picture, or pure whiter picture.
11.4 Major Defect
Item
Items to be
No.
inspected
Inspection standard
Classification of defects
1) No display
2) Display abnormally
3) Missing vertical, horizontal segment
1
Functional defects 4) Short circuit
5) Excess power consumption 6)Backlight no lighting, flickering and abnormal
major
lighting
2
Missing
Missing component
3
Outline dimension
Overall outline dimension beyond the drawing is not allowed
www.surenoo.com
P 15
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
11.5 Minor Defect
Item No.
1
2
Items to be inspected
Bright dot /dark dot
defect
Inspection standard
Zone
Acceptable Qty
A+B
3.5″ 710.1″ 10.1″
C
7″
Bright pixel dot
1
2
3
Acceptable
Dark pixel dot
4
4
4
2bright dots adjacent
0
0
0
2dark dots adjacent
0
0
0
Total bright and dark
5
6
7
dots
Note: Minimum distance between defective dots is more than 5mm;
Pixel dots’ function is normal, but bright dots caused by foreign
material and other reasons are judged by the dot defect of 5.2.
Zone
Acceptable Qty
A+B
Size(mm)
0.2
3.5″7″
710.1″
10.1″
C
Acceptable Acceptable Acceptable
Classification of defects
Minor
Acceptable
0.20.5
4
5
6
0.5
0
0
0
Note: 1. Minimum distance between defective dots is more than 5 mm; 2. The quantity of defect is zero in operating condition.
Minor
Zone
Acceptable Qty
Size (mm)
A+B
3
Linear defect
Length Width 3.5″7″ 710.1″
10.1″
C
Ignore W0.05 Acceptable Acceptable Acceptable
Minor
Acceptable
L5.0
0.05 W0.1
4
5
6
L5.0 W0.1
0
0
0
www.surenoo.com
P 16
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
5.4.1 Polarizer Position
( i) Shifting in position should not exceed the glass outline
dimension.
( ii ) Incomplete covering of the viewing area due to shifting is not
allowed.
5.4.2 Dirt on polarizer
Dirt which can be wiped easily should be acceptable.
5.4.3 Polarizer Dent & Air bubble
Zone
Acceptable Qty
A+B
Size(mm)
3.5″7″
710.1″
10.1″
C
0.2
Acceptable Acceptable Acceptable
Acceptable
0.20.5
4
5
6
4
Polarizer defect
0.5
0
5.4.4 Polarizer scratch
0
0
Minor
(i) If the polarizer scratch can be seen after cover assembling
or in the operating condition, judge by the linear defect of 5.3.
( ii )If the polarizer scratch can be seen only in non-operating
condition or some special angle, judge by the following:
Zone
Acceptable Qty
Size (mm)
A+B
Length Width 3.5″7″ 710.1″
10.1″
C
Acceptable
Ignore
1.0L 5.0 L5.0
W0.05 0.05 W0.20 W0.2
Acceptable
4 0
Acceptable
5 0
Acceptable
6 0
MURA
Using 3% ND filter, it’s NG if it can be seen in R,G,B picture.
5
White/Black dotMURA
Visible underND3%D0.15mm, Acceptable 0.15mm<D0.5mm, N4D>0.5mm, Not allowable.
Minor
www.surenoo.com
P 17
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
(i) Crack Cracks are not allowed.
(ii) TFT chips on corner
A3 Model No.: SRG0430C-A3480800
Minor
Minor
6
Glass defect
X 3.0
Y 3.0
Z Not more than the thickness of glass
Acceptable N3
Chips on the corner of terminal shall not be allowed to extend
into the ITO pad or expose perimeter seal.
(iii) Usual surface crack
X
Y
Z
Acceptable
1.5
1.5
Not more than the thickness of glass
N4
It is only applicable to the upper glass of LCD.
Minor
www.surenoo.com
P 18
SHENZHEN SURENOO TECHNOLOGY CO.,LTD.
A3 Model No.: SRG0430C-A3480800
11.6 Module Cosmetic Criteria
Item No.
1 2
3
4 5 6
7
8 9 10
Items to be inspected
Difference in Spec. Pattern peeling
Soldering defects
Resist flaw on PCB FPC gold finger Backlight plastic frame
Marking printing effect Accretion of metallic Foreign matter Stain Plate discoloring
Inspection Standard
Not allowable No substrate pattern peeling and floating No soldering missing No soldering bridge No cold soldering Visible copper foil (0.5 mm or more) on substrate pattern is not allowed No dirt, breaking, oxidation lead to black No deformation, crack, breaking, backlight positioning column breaking, obvious nick. No dark marking, incomplete, deformation lead to unable to judge
No accretion of metallic foreign matter (Not exceed 0.2mm)
No stain to spoil cosmetic badly No plate fading, rusting and discoloring
Classification of defects
Major Major Major Major Minor
Minor
Major
Minor
Minor
Minor
Minor Minor
1. Lead parts
a. Soldering side of PCB Solder to form a `Filet’ all around the lead. Solder should not hide the lead form perfectly.
b. Components side(In case of `Through Hole PCB’) Solder to reach the Components side of PCB.
Minor Minor
2. Flat packages
Either `Toe'(A) or `Seal'(B)of the lead to be covered by “Filet”. Lead form to be assume over Solder.
Minor
11 3. Chips
(3/2) H h (1/2) H
4. Solder ball/Solder splash
a. The spacing between solder ball and the conductor or solder pad h 0.13 mm. The diameter of solder ball d0.15 mm. b. The quantity of solder balls or solder splashes isn’t beyond 5 in 600 mm2.
c. Solder balls/Solder splashes do not violate minimum electrical clearance.
www.surenoo.com
Minor Minor Minor Major
P 19
Surenoo Tech: Professional LCD Module Supplier Since 2005
