500550 Dante 2-Channel USB Audio Encoder-Decoder

Dante 2-Channel USB Audio Encoder/Decoder

The Dante 2-Channel USB Audio Encoder/Decoder (Model: 500550) is
a versatile device that can encode 2-channel USB audio to a Dante
digital signal and decode a Dante digital signal to 2-channel USB
audio. It is designed for easy plug & play use and can be
powered either through PoE from any PoE network switch or via 5V
from a USB device. The compact size of the product makes it
portable and convenient to carry.

Features:

Compliant with USB 2.0 Full Speed Operation
Compliant with USB Audio Device Class Specification V1.0
Analog sound card, supporting MIC input and SPK output
Audio sampling rate supports 44.1kHz, 48kHz, and 96kHz
(24bit)
Dante solution supports AES67 RTP audio transmission
Supports USB 5V power supply and PoE function (IEEE802.3af
Class0)

Package Contents:

One (1) Dante 2-Channel USB Audio Encoder/Decoder
One (1) USB Cable (6FT USB A to USB B)
One (1) User manual (available via download)

Specifications:

Technical	Video Network Bandwidth	Audio Formats	Transmission Distance	Control Method
	100M PCM 2.0	44.1kHz/48kHz/96kHz up to 24bit	100m (CAT6/6A)	Dante Controller

Operation Controls and Functions:

No	Name	Function Description
1	USB (From PC)	(1) 2-channel USB digital audio signal port: L/R stereo input and L/R stereo output. (2) USB 5V power input port.
2	Dante PoE	Dante digital audio input and output port. Connect to the Network Switch through RJ45 line, supporting PD power supply. The green LINK LED is flashing when there is data transmission. The yellow DATA LED is always on after normal connection.

Application Diagram:

For more information and updates, follow us on social media.

View Fullscreen

Dante 2-Channel USB Audio Encoder/Decoder
User Manual
500550

94-001003-A/SE-001003-A

Dante 2-Channel USB Audio Encoder/Decoder
Table of Contents
1. Safety Precautions………………………………………………………………………………………………………………………………….3 2. Introduction…………………………………………………………………………………………………………………………………………….4 3. Features…………………………………………………………………………………………………………………………………………………..4 4. Package Contents…………………………………………………………………………………………………………………………………4 5. Specifications…………………………………………………………………………………………………………………………………………5 6. Operation Controls and Functions……………………………………………………………………………………………………..6 8. Application Diagram……………………………………………………………………………………………………………………………..7

94-001003-A/SE-001003-A

Dante 2-Channel USB Audio Encoder/Decoder
1. Safety Precautions
To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for future reference.
Follow basic safety precautions to reduce the risk of fire, electrical shock, and injury. Do not dismantle the housing or modify the module. It may result in electrical shock or burns. Do not open or remove the housing of the device as you may be exposed to dangerous voltage or other hazards. To prevent fire or shock hazard, do not expose the unit to rain, moisture and do not install this product near water. Keep the product away from liquids. Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on the housing, unplug the module immediately. Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning. Using supplies or parts not meeting the product specifications may cause damage, deterioration or malfunction. Refer all servicing to qualified service personnel. Install the device in a place with adequate ventilation to avoid damage caused by overheat. Unplug the power when left unused for a long period of time. Information on disposal of devices: do not burn or mix with general household waste, please treat them as normal electrical waste.

Copyright Notice
All contents in this manual are copyrighted, and cannot be cloned, copied, or translated without the express permission of MuxLab Inc. Product specifications and information in this document are for reference only, and the content may be updated from time to time without prior notice.

94-001003-A/SE-001003-A

2. Introduction

Dante 2-Channel USB Audio Encoder/Decoder

The Dante 2-Channel USB Audio Encoder/Decoder (Model: 500550) is designed to both encode 2ch USB audio to a Dante digital signal, and decode a Dante digital signal to 2ch USB audio. The unit is plug & play and can be powered using either PoE from any PoE network switch or via 5V from the USB device; In addition, the product is compact and easy to carry.

3. Features
Compliant with USB 2.0 Full Speed Operation Compliant with USB Audio Device Class Specification V1.0 Analog sound card, supporting MIC input and SPK output Audio sampling rate supports 44.1kHz, 48kHz and 96kHz (24bit) Dante solution supports AES67 RTP audio transmission Support USB 5V power supply and PoE function (IEEE802.3af Class0)
4. Package Contents
One (1) Dante 2-Channel USB Audio Encoder/Decoder One (1) USB Cable (6FT USB A to USB B) One (1) User manual (available via download)

Notes Confirm that the product and accessories are all included. If not, please contact the
supplier from which you purchased the unit.

94-001003-A/SE-001003-A

5. Specifications

Dante 2-Channel USB Audio Encoder/Decoder

Technical
Video Network Bandwidth Audio Formats Transmission Distance Control Method
Connection
Input & Output
Mechanical
Housing Color Dimensions (WxDxH) Weight Power Supply Power Consumption Operation Temperature Storage temperature Relative Humidity

100M PCM 2.0 44.1kHz/48kHz/96kHz up to 24bit 100m (CAT6/6A) Dante Controller
1 x USB-B 1 x DANTE [RJ45 connector, PoE] Metal Enclosure Black 120mm[W] x 47mm[D] x 26mm[H] 186g USB input: 5V-500MA PoE input: IEEE802.3af Class 0 1W 32 – 104°F / 0 – 40°C -4 – 140°F / -20 – 60°C 20 – 90% RH (no condensation)

Warranty Order Information

2 years 500550 Dante 2 Channel USB Audio Encoder/Decoder (UPC: 627699005507)

94-001003-A/SE-001003-A

Dante 2-Channel USB Audio Encoder/Decoder
6. Operation Controls and Functions

Name

1 USB (From PC)

2 Dante PoE

Function Description
(1) 2-channel USB digital audio signal port: L/R stereo input and L/R stereo output. (2) USB 5V power input port. Dante digital audio input and output port. Connect to the Network Switch through RJ45 line, supporting PD power supply. The green LINK LED is flashing when there is data transmission. The yellow DATA LED is always on after normal connection.

94-001003-A/SE-001003-A

7. Application Diagram

Dante 2-Channel USB Audio Encoder/Decoder

Dante 2-Channel USB Audio Encoder/Decoder 500550
